ENGLISH 1

INTRODUCTION

Thank you for purchasing a Honda lawnmower!

This manual covers the operation and maintenance of the Honda

HRS536C5 VKEA lawnmower.

We want to help you get the best results from your new lawnmower

and to operate it safely. This manual contains the information on how

to do that; please read it carefully.

This manual should be considered a permanent part of the

lawnmower and should remain with it if it is resold.

If you have a problem or questions concerning the lawnmower,

contact your supplying dealer.

We recommend that you read the warranty policy to fully understand

its coverage and your responsibilities of ownership.

Honda Power Equipment Mfg., Inc. reserves the right to make

changes at any time without notice and without incurring any

obligation.

No part of this publication may be reproduced without written

permission.

SAFETY MESSAGES

Pay special attention to statements preceded by the following words:

Each message tells you what the hazard is, what can happen, and

what you can do to avoid or reduce injury.

DAMAGE PREVENTION MESSAGES

You will also see other important messages that are preceded by the

following word:

The purpose of these messages is to help prevent damage to your

lawnmower, other property, or the environment.

CONTENTS

 DANGER You WILL be KILLED or SERIOUSLY

HURT if you don’t follow instructions.

 WARNING You CAN be KILLED or SERIOUSLY

HURT if you don't follow instructions.

 CAUTION You CAN be HURT if you don't follow

instructions.

NOTICE

Your lawnmower, other property, or the

environment can be damaged if you don’t

follow instructions.

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

SAFETY MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

COMPONENT IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SET-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PRE-OPERATION CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

TRANSPORTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Honda Warranty Conditions,

“EC Declaration of Conformity” CONTENT OUTLINE,

Major Honda Distributor Locations . . . . . . . . . . . . . . . . . . . .Last pages

OWNER’S MANUAL

(Original instructions)

HRS536C5VKEA

PEDESTRIAN CONTROLLED

LAWNMOWER

ENGLISHFRANÇAISESPAÑOL

ITALIANONEDERLANDS DEUTSCH

00X39VG3 6561

HPE.2017.09

PRINTED IN U.S.A.

2ENGLISH

SAFETY INSTRUCTIONS

To ensure safe operation –

• Read instructions carefully, become familiar with controls and

proper use of equipment.

• Never allow children or people unfamiliar with these

instructions to use the lawnmower. Local regulations may

restrict the age of the operator.

• Never mow when:

– People, especially children, or pets are nearby.

– There is a risk of adverse weather such as lightning or a

storm.

• Keep in mind that the operator or user is responsible for

injuries, property damage, or hazards occurring to other

people or their property.

• While mowing, always wear substantial footwear and long

trousers. Do not operate the equipment when barefoot or

wearing open sandals.

• Thoroughly inspect the area where the equipment is to be

used, and remove all objects which may be thrown by the

machine.

• WARNING - Petrol is highly flammable:

– Store fuel in containers specifically designed for this

purpose.

– Refuel outdoors only and do not smoke while refueling.

– Add fuel before starting the engine. Never remove the cap of

the fuel tank or add petrol while the engine is running or

when the engine is hot.

– If petrol is spilled, do not attempt to start the engine, but

move the machine away from the area of spillage, and avoid

creating any source of ignition until the petrol vapors have

dissipated.

– Install fuel caps securely.

• Replace faulty mufflers.

• Before using, always visually inspect to see that the cutting

means, cutting means bolts, and cutting-means enclosure are

not worn or damaged. Replace a worn or damaged cutting

means and cutting-means bolts in sets to preserve balance.

• Check grass catchers frequently for wear or deterioration.

• Do not operate the engine in a confined space where

dangerous carbon monoxide fumes can collect.

• Mow only in daylight or good artificial light.

• Avoid operating the equipment in wet grass, where feasible.

• Mowing stability:

– Always be sure of your footing on slopes.

– Mow across slopes, never up and down.

– Walk, never run.

– Exercise extreme caution when changing direction on

slopes.

– Do not mow excessively steep slopes.

• Use extreme caution when pulling the lawnmower toward you.

• Stop the cutting means if the lawnmower has to be tilted for

transporting, when crossing surfaces other than grass, and

when transporting the lawnmower to and from the area to be

mowed.

• Never operate the lawnmower with defective guards or

shields, or without safety devices (for example, discharge

guards and/or grass catchers in place).

• Do not attempt to make wheel height adjustments while the

machine is running.

• Do not change the engine governor setting or over-speed the

engine.

• Disengage the Smart Drive control before starting the

machine.

• Start the engine carefully according to the instructions and

with feet well away from the cutting means.

• Do not start the engine when standing in front of the discharge

chute.

• Do not tilt the lawnmower when starting the engine.

• Do not put hands or feet near or under rotating parts. Keep

clear of the discharge opening at all times.

• Never pick up or carry a lawnmower while the engine is

running.

• Stop the engine and disconnect the spark plug wire:

– Before clearing a blockage or unclogging the lawnmower.

– Before checking, cleaning, or working on the lawnmower.

– After striking a foreign object. Inspect the lawnmower for

damage and make repairs before restarting and operating

the lawnmower.

– If lawnmower starts to vibrate abnormally, stop the engine

immediately.

• Stop the engine:

– Whenever you leave the lawnmower.

– Before refueling the lawnmower.

– Before removing the side discharge guard.

• Turn the fuel valve off at the conclusion of mowing.

• Keep all nuts, bolts, and screws tight to be sure the equipment

is in safe working condition.

• Never store the equipment with petrol in the tank inside a

building where fumes may reach an open flame or spark.

• Allow the engine to cool before storing in any enclosure.

• To reduce the fire hazard, keep the petrol storage area, engine,

muffler, and battery compartment (if applicable) free of grass,

leaves, or excessive grease.

• Replace worn or damaged parts for safety.

• If the fuel tank has to be drained, this should be done

outdoors.

• Wear eye protection.

 WARNING

• Honda lawnmowers are designed

to give safe and dependable service if

operated according to instructions.

Read and understand the Owner’s

Manual before operating the mower.

Failure to do so could result in

personal injury or equipment damage.

Disposal

To protect the environment, do not dispose of this product,

battery, engine oil, etc. carelessly by leaving them in the

waste. Observe the local laws and regulations or consult

your authorized Honda dealer for disposal.

ENGLISH 3

SAFETY LABEL LOCATION

The labels shown here contain important safety information. Carefully

read their meaning. These labels are considered permanent parts of

your Honda mower. If a label comes off or becomes hard to read,

contact your Honda dealer for a replacement.

PRODUCT IDENTIFICATION PLATE

COMPONENT IDENTIFICATION

Record the frame and engine serial numbers in the space below. You

will need these numbers when ordering parts and when making

technical or warranty inquires.

Frame serial number:___________________________

Engine serial number:___________________________

Date of purchase:______/______/______

Letter Meaning

1. Read the owner’s manual before using the mower.

2. Risk of projections: Keep third persons away from the area

during use.

3. Risk of cuts. Rotating cutting means: Do not put hands or feet

inside the cutting-means enclosure. Disconnect the spark plug

cap before performing any operation of maintenance or repairs.

4. Do not operate without either discharge guard or grass

catcher in place.

5. Read the owner’s manual before using the mower.

6. The engine emits toxic carbon monoxide. Do not run in an

enclosed area.

7. Petrol is highly flammable. Stop the engine before refueling.

8. Risk of projections: Keep third persons away from the area

during use.

9. Do not operate without either discharge guard or grass

catcher in place.

Letter Meaning

1. Sound power level

guaranteed according to

directive 2000/14/EC

2. Conformity mark according to

EC directive

3. Conformity mark optional

4. Nominal power in kilowatts

5. Maximum operating engine

speed

6. Year of manufacture

7. Weight in kilograms

8. Serial number

9. Model

10.Name and address of

authorized representative

11.Name and address of

Manufacturer

Name and address of manufacturer and authorized representative are

written in the “EC Declaration of Conformity” CONTENT OUTLINE in this

Owner’s Manual.

567

8 9

31 4 5

Smart Drive control

(Transmission control which

drives the rear wheels)

8 Engine serial number

2 Handlebar 9 Recoil starter grip

3Cutting-means control (Starts and

stops the cutting means)10 Handlebar adjust knob (2)

4Cutting height adjustment

levers (4)

11 Fuel tank cap

12 Fuel valve

5 Muffler 13 Air cleaner

6 Discharge guard 14 Carburetor

7 Oil filler cap 15 Spark plug cap

[2]

D [LABEL]

[4] (2)

[5]

[7]

[4]

[10] (2)

[9]

[13]

B [LABEL]

[15]

[14]

[6]

[1]

[12]

[3]

[11]

A [LABEL]

C [LABEL]

[8]

Produktspezifikationen

Marke:	Honda
Kategorie:	Rasenmäher
Modell:	HRS 536 C5 VK

Brauchst du Hilfe?

Wenn Sie Hilfe mit Honda HRS 536 C5 VK benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Rasenmäher Honda

Honda izy Bedienungsanleitung

9 September 2024

Honda HRS 536 C5 VK Bedienungsanleitung

31 August 2024

Honda HRG466C1 Bedienungsanleitung

31 August 2024

Honda IZY HRG 466C1 PKEH Bedienungsanleitung

31 August 2024

Honda IZY HRG-416SK Bedienungsanleitung

31 August 2024

Honda IZY HRG 466C1 Bedienungsanleitung

31 August 2024

Honda IZY HRG-416PK Bedienungsanleitung

31 August 2024

Honda Buffalo Buck HRU19K1 Bedienungsanleitung

17 August 2024

Honda Buffalo Buck HRU19R1 Bedienungsanleitung

13 August 2024

Honda HRX217HXA Bedienungsanleitung

12 August 2024

Bedienungsanleitung Rasenmäher

Neueste Bedienungsanleitung für -Kategorien-

Troy-Bilt TB410 XP Bedienungsanleitung

15 Oktober 2024

AL-KO Classic 4.64 SP-S Bedienungsanleitung

15 Oktober 2024

Gardena PowerMax 36 A Li Bedienungsanleitung

15 Oktober 2024

Einhell BG-PM 46 Bedienungsanleitung

15 Oktober 2024

Powerplus POWXQG7556 Bedienungsanleitung

14 Oktober 2024

Rover Regal SP Mulch N Catch 51m Bedienungsanleitung

14 Oktober 2024

Solo 546-RS Bedienungsanleitung

14 Oktober 2024

Einhell GE-SC 35 Li Bedienungsanleitung

13 Oktober 2024

Masport President 4000ST Genius Bedienungsanleitung

12 Oktober 2024

Dolmar EM-460 Bedienungsanleitung

12 Oktober 2024
