INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation de cet outil motorisé peut entraîner laINCORRECTE OU DANGEREUSE
mort ou de sérieuses blessures corporelles !
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce
produit. Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil
motorisé. Garder ce mode d’emploi à la disponibilité des autres utilisateurs et
propriétaires avant qu’ils utilisent l’outil motorisé. Ce mode d’emploi doit être conservé
dans un endroit sûr.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
available for other users and owners before they use the power tool. This manual should
be stored in safe place.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización de esta herramienta eléctrica puede resultarINAPROPIADA O PELIGROSA
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual
para que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este
manual debe ser guardado en un lugar seguro.
M 12VC • M 12SC
KM 12VC • KM 12SC
Model Router
Modèle Toupie
Modelo Fresadora
M12VC
English
Page
IMPORTANT SAFETY INFORMATION ................ 3
MEANINGS OF SIGNAL WORDS ........................ 3
SAFETY ...................................................................... 4
GENERAL SAFETY RULES ................................... 4
SPECIFIC SAFETY RULES AND SYMBOLS ......... 5
USE OF EXTENSION CORD ................................. 7
FUNCTIONAL DESCRIPTION .................................... 8
NAME OF PARTS .................................................. 8
SPECIFICATIONS .................................................. 8
Page
ASSEMBLY AND OPERATION ................................. 9
APPLICATIONS ..................................................... 9
PRIOR TO OPERATION ......................................... 9
INSTALLING AND REMOVING BITS ................. 10
INSTALLING THE MOTOR HOUSING ............... 11
HOW TO USE THE ROOTER ............................... 11
MAINTENANCE AND INSPECTION ....................... 15
ACCESSORIES ......................................................... 17
STANDARD ACCESSORIES ............................... 17
OPTIONAL ACCESSORIES ................................. 18
PARTS LIST .............................................................. 53
TABLE DES MATIERES
Français
Page
INFORMATIONS IMPORTANTES
DE SÉCURITÉ ............................................... 19
SIGNIFICATION DES MOTS
D’AVERTISSEMENT .................................... 19
SECURITE ................................................................ 20
REGLES GENERALE DE SECURITE
...................... 20
REGLES DE SECURITE SPECIFIQUES
ET SYMBOLES ............................................. 22
UTILISATION D’UN CORDON DE RALLONGE ...
24
DESCRIPTION FONCTIONNELLE ........................... 25
NOM DES PARTIES ............................................ 25
SPECIFICATIONS ................................................ 25
Page
ASSEMBLAGE ET FONCTIONNEMENT ................ 26
APPLICATIONS ................................................... 26
AVANT L’UTILISATION ...................................... 26
INSTALLATION ET RETRAIT DE LA MECHE ..... 27
INSTALLATION DU CARTER MOTEUR ............. 28
UTILISATION DE LA TOUPIE ............................. 28
ENTRETIEN ET INSPECTION .................................. 32
ACCESSOIRES ......................................................... 34
ACCESSOIRES STANDARD ............................... 34
ACCESSOIRES SUR OPTION ............................. 35
LISTE DES PIÈCES ................................................... 53
ÍNDICE
Español
Página
INFORMACIÓN IMPORTANTE
SOBRE SEGURIDAD .................................... 36
SIGNIFICADO DE LAS PALABRAS
DE SEÑALIZACIÓN ...................................... 36
SEGURIDAD ............................................................. 37
NORMAS GENERALES DE SEGURIDAD........... 37
NORMAS Y SÍMBOLOS
ESPECÍFICOS DE SEGURIDAD ................... 39
UTILIZACIÓN DE UN CABLE PROLONGADOR ...
41
DESCRIPCIÓN FUNCIONAL .................................... 42
NOMENCLATURA ............................................... 42
SPECIFICATIONS ................................................ 42
Página
MONTAJE Y OPERACIÓN ...................................... 43
APLICACIONES ................................................... 43
ANTES DE LA OPERACIÓN ................................ 43
INSTALACIÓN Y EXTRACCIÓN DE
LAS BROCAS ............................................... 44
INSTALACIÓN DE LA CARCASA
DEL MOTOR ................................................. 45
CÓMO USAR LA FRESADORA .......................... 45
MANTENIMIENTO E INSPECCIÓN ........................ 49
ACCESORIOS ........................................................... 51
ACCESORIOS ESTÁNDAR ................................. 51
ACCESORIOS OPCIONALES .............................. 52
LISTA DE PIEZAS .................................................... 53
CONTENTS
English
3
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in
the Instruction Manual before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the
failure to observe basic safety rules or precautions. An accident can often be avoided by
recognizing a potentially hazardous situation before it occurs, and by observing appropriate
safety procedures.
Basic safety precautions are outlined in the section of this Instruction Manual“ ”SAFETY
and in the sections which contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by
WARNINGS on the power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by
HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in
death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in
minor or moderate injury, or may cause machine damage.
NOTE emphasizes essential information.
English
4
SAFETY
GENERAL SAFETY RULES
WARNING: Read and understand all instructions.
Failure to follow all instructions listed below, may result in electric shock,
fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
1. Work Area
(1) Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
(2) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust. Power tools create sparks which may ignite the
dust of fumes.
(3) Keep bystanders children, and visitors away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical Safety
(1) Grounded tools must be plugged into an outlet properly installed and grounded in
accordance with all codes and ordinances. Never remove the grounding prong or
modify the plug in any way. Do not use any adaptor plugs. Check with a qualified
electrician if you are in doubt as to whether the outlet is properly grounded. If the
tools should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user.
(2) Avoid body contact with grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is grounded.
(3) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
(4) Do not abuse the cord. Never use the cord to carry the tools or pull the plug from
a receptacle. Keep cord away from heat, oil, sharp edges or moving parts. Replace
damaged cords immediately. Damaged cords increase the risk of electric shock.
(5) When operating a power tool outside, use an outdoor extension cord marked “W-
A W .” or “ ” These cords are rated for outdoor use and reduce the risk of electric
shock.
3. Personal Safety
(1) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use tool while tires or under the influence of drugs, alcohol,
or medication. A moment of inattention while operating power tools may result in
serious personal injury.
(2) Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep
your hair, clothing and gloves away from moving parts. Loose clothes, jewelry, or
long hair can be caught in moving parts.
(3) Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools
with your finger on the switch or plugging in tools that have the switch on invites
accidents.
English
5
(4) Remove adjusting keys or wrenches before turning the tool on. A wrench or a key
that is left attached to a rotating part of the tool may result in personal injury.
(5) Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the tool in unexpected situations.
(6) Use safety equipment. Always wear eye protection. Dust mask, non-skid safety
shoes, hard hat, or hearing protection must be used for appropriate conditions.
4. Tool Use and Care
(1) Use clamps or other practical way to secure and support the workpiece to a stable
platform. Holding the work by hand or against your body is unstable and may lead
to loss of control.
(2) Do not force tool. Use the correct tool for your application. The correct tool will do
the job better and safer at the rate for which it is designed.
(3) Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
(4) Disconnect the plug form the power source before making any adjustments,
changing accessories, or storing the tool. Such preventive safety measures reduce
the risk of starting the tool accidentally.
(5) Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
(6) Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained
tools, with sharp cutting edges are less likely to bind and are easier to control.
(7) Check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the tool's operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly maintained tools.
(8) Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used
with another tool.
5. Service
(1) Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
(2) When servicing a tool, use only identical replacement parts. Follow instructions in
the Maintenance section of this manual. Use of unauthorized parts or failure to
follow Maintenance Instruction may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES AND SYMBOLS
1. Hold tools by insulated gripping surfaces when performing an operation where the
cutting tool may contact hidden wiring or its own cord.
Contact with a and shock“ ”live wire will make exposed metal parts of the tool “ ”live
the operator.
2. ALWAYS wear ear protectors when using the tool for extended periods.
Prolonged exposure to high intensity noise can cause hearing loss.
Produktspezifikationen
| Marke: | Hitachi |
| Kategorie: | Sander |
| Modell: | KM12VC |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Hitachi KM12VC benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Sander Hitachi
24 August 2024
24 August 2024
24 August 2024
24 August 2024
24 August 2024
6 August 2024
4 August 2024
31 Juli 2024
29 Juli 2024
29 Juli 2024
Bedienungsanleitung Sander
- Sander Makita
- Sander Bosch
- Sander Flex
- Sander Parkside
- Sander Vonroc
- Sander AEG
- Sander Arendo
- Sander Gastroback
- Sander Black And Decker
- Sander Cocraft
- Sander FERM
- Sander Ryobi
- Sander Skil
- Sander Topcraft
- Sander Trotec
- Sander Hilti
- Sander Bort
- Sander DeWalt
- Sander Einhell
- Sander Elu
- Sander Festool
- Sander Mafell
- Sander Maktec
- Sander Worx
- Sander Tacklife
- Sander Hikoki
- Sander Hyundai
- Sander Hazet
- Sander Kinzo
- Sander Kress
- Sander Max
- Sander Metabo
- Sander Stanley
- Sander Güde
- Sander Power Craft
- Sander Scheppach
- Sander Probuilder
- Sander Workzone
- Sander Biltema
- Sander Meec Tools
- Sander Dremel
- Sander Fieldmann
- Sander King Craft
- Sander Proxxon
- Sander Westfalia
- Sander Dedra
- Sander DURO
- Sander Far Tools
- Sander Silverline
- Sander Holzmann
- Sander Stomer
- Sander Batavia
- Sander Matrix
- Sander Bavaria
- Sander Brüder Mannesmann
- Sander Milwaukee
- Sander Toolcraft
- Sander Fein
- Sander Craftsman
- Sander Powerplus
- Sander Rupes
- Sander Alpha Tools
- Sander Toledo
- Sander Ozito
- Sander Ridgid
- Sander Porter-Cable
- Sander VARO
- Sander Duro Pro
- Sander Gamma
- Sander Global
- Sander Protool
- Sander Toolson
- Sander Wagner SprayTech
- Sander Meister Craft
- Sander Truper
- Sander RIKON
- Sander Einhell Bavaria
- Sander Tryton
- Sander FIXIT
- Sander Ribimex
- Sander Black Decker
- Sander Pevec
- Sander Handwerk
- Sander TAURUS Titanium
- Sander Stalco
Neueste Bedienungsanleitung für -Kategorien-
15 Oktober 2024
8 Oktober 2024
7 Oktober 2024
5 Oktober 2024
5 Oktober 2024
4 Oktober 2024
4 Oktober 2024
4 Oktober 2024
3 Oktober 2024
1 Oktober 2024
