Lesen Sie kostenlos die đ deutsche Bedienungsanleitung fĂŒr Hitachi GP3V (41 Seiten) in der Kategorie Schleifmaschine. Dieser Bedienungsanleitung war fĂŒr 15 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/41
GP 3V âą GP 5V
DOUBLE INSULATION
DOUBLE ISOLATION
AISLAMIENTO DOBLE
INSTRUCTIONS DE SECURITE ET MODE DâEMPLOI
AVERTISSEMENT
Une utilisation de cet outil motorisé peut entraßner laINCORRECTE OU DANGEREUSE
mort ou de sérieuses blessures corporelles !
Ce mode dâemploi contient dâimportantes informations Ă propos de la sĂ©curitĂ© de ce
produit. PriĂšre de lire et de comprendre ce mode dâemploi AVANT dâutiliser lâoutil
motorisĂ©. Garder ce mode dâemploi Ă la disponibilitĂ© des autres utilisateurs et
propriĂ©taires avant quâils utilisent lâoutil motorisĂ©.
Ce mode dâemploi doit ĂȘtre conservĂ© dans un endroit sĂ»r.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¥La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene informaciĂłn importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual
para que puedan leerlo otras personas antes de utilizar la herramienta eléctrica.
Este manual debe ser guardado en un lugar seguro.
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read and
understand this manual BEFORE operating the power tool. Please keep this manual
available for other users and owners before they use the power tool.
This manual should be stored in safe place.
GP3V GP5V
Model Electronic Hand Grinder
ModĂšle Meuleuse droite Ă©lectronique
Modelo Amoladora recta electrĂłnica
CONTENTS
English Page
IMPORTANT SAFETY INSTRUCTIONS ....
3
MEANINGS OF SIGNAL WORDS .......... 3
SAFETY ................................................... 3
GENERAL POWER TOOL SAFETY WARNINGS ....
3
SAFETY WARNINGS COMMON
FOR GRINDING OPERATIONS ....... 4
KICKBACK AND RELATED WARNINGS ...........
5
SAFETY WARNINGS SPECIFIC
FOR GRINDING OPERATIONS ....... 5
GENERAL SAFETY INSTRUCTIONS
FOR GRINDERS ............................... 6
SPECIFIC SAFETY RULES AND SYMBOLS
..... 6
DOUBLE INSULATION FOR SAFER OPERATION
... 7
Page
FUNCTIONAL DESCRIPTION ................ 9
NAME OF PARTS ................................ 9
SPECIFICATIONS ................................ 9
ASSEMBLY AND OPERATION ............ 10
APPLICATIONS ................................. 10
PRIOR TO OPERATION..................... 10
GRINDER OPERATION ..................... 11
MAINTENANCE AND INSPECTION .... 12
ACCESSORIES ...................................... 13
STANDARD ACCESSORIES ............. 13
OPTIONAL ACCESSORIES ............... 13
PARTS LIST .......................................... 38
TABLE DES MATIERES
Français Page
CONSIGNES DE SĂCURITĂ IMPORTANTES ......
14
SIGNIFICATION DES MOTS
DâAVERTISSEMENT ...................... 14
SECURITE ............................................. 14
AVERTISSEMENTS DE SĂCURITĂ GĂNĂRAUX
CONCERNANT LES OUTILS ĂLECTRIQUES ...
14
AVERTISSEMENTS DE SĂCURITĂ COURANTS
AUX OPĂRATIONS DE MEULAGE ..................
16
RECUL DE L'APPAREIL ET
AVERTISSEMENTS ASSOCIĂS..... 16
AVERTISSEMENTS DE SĂCURITĂ SPĂCIFIQUES
AUX OPĂRATIONS DE MEULAGE ..................
17
CONSIGNES DE SECURITE GENERALES
RELATIVES AUX MEULEUSES DROITES .......
17
REGLES DE SECURITE SPECIFIQUES
ET SYMBOLES ..................................................
18
Page
DOUBLE ISOLATION POUR UN
FONCTIONNEMENT PLUS SUR ... 19
DESCRIPTION FONCTIONNELLE ........ 20
NOM DES PARTIES .......................... 20
SPECIFICATIONS .............................. 20
ASSEMBLAGE ET FONCTIONNEMENT ....
21
APPLICATIONS ................................. 21
AVANT LâUTILISATION .................... 21
FONCTIONNEMENT DE LA MEULEUSE....
22
ENTRETIEN ET INSPECTION ............... 24
ACCESSOIRES...................................... 25
ACCESSOIRES STANDARD ............. 25
ACCESSOIRES SUR OPTION ........... 25
LISTA DES PIĂCES ............................... 38
ĂNDICE
Español Pågina
INSTRUCCIONES IMPORTANTES
SOBRE SEGURIDAD ......................... 26
SIGNIFICADO DE LAS PALABRAS DE
SEĂALIZACIĂN................................. 26
SEGURIDAD ......................................... 26
ADVERTENCIAS DE SEGURIDAD GENERAL
DE LA HERRAMIENTA ELĂCTRICA .............
26
ADVERTENCIAS COMUNES DE SEGURIDAD
PARA LAS OPERACIONES DE MOLIDO ...
28
REBOTE Y ADVERTENCIAS
RELACIONADAS ............................ 29
ADVERTENCIAS DE SEGURIDAD ESPECĂFICAS
PARA LAS OPERACIONES DE MOLIDO .........
29
INSTRUCCIONES GENERALES DE
SEGURIDAD PARA AMOLADORAS .....
29
NORMAS Y SĂMBOLOS
ESPECĂFICOS DE SEGURIDAD .... 30
PĂĄgina
AISLAMIENTO DOBLE PARA
OFRECER UNA OPERACIĂN
MĂS SEGURA ............................... 31
DESCRIPCIĂN FUNCIONAL ................ 32
NOMENCLATURA ............................. 32
ESPECIFICACIONES .......................... 32
MONTAJE Y OPERACIĂN ................... 33
APLICACIONES ................................. 33
ANTES DE LA OPERACIĂN .............. 33
OPERACIĂN DE LA AMOLADORA .. 34
MANTENIMIENTO E INSPECCIĂN ..... 36
ACCESORIOS ....................................... 37
ACCESORIOS ESTĂNDAR ............... 37
ACCESORIOS OPCIONALES ............ 37
LISTA DE PIEZAS ................................. 38
3
English
IMPORTANT SAFETY INSTRUCTIONS
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual
before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic
safety rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation
before it occurs, and by observing appropriate safety procedures.
Basic safety precautions are outlined in the âSAFETYâ section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the
power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate
injury, or may cause machine damage.
NOTE emphasizes essential information.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING:
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term âpower toolâ in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite
the dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts.
Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
