SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand this manual
BEFORE operating the power tool. Please keep this manual available for other users and owners before they
use the power tool. This manual should be stored in safe place.
WARRANTY: CG22EAP2(SLB) is NOT intended for commercial use, and therefore, NO warranty is provided
to their commercial applications and rental applications.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation de cet outil motorisé peut entraîner la mort ou de INCORRECTE OU DANGEREUSE
sérieuses blessures corporelles !
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit. Prière de
lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce mode d’emploi à la
disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent l’outil motorisé. Ce mode d’emploi
doit être conservé dans un endroit sûr.
GARANTIE : Le modèle CG22EAP2(SLB) n’est PAS destiné à un usage commercial; par conséquent,
AUCUNE garantie n’est fournie concernant toute utilisation commerciale ou locative.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización de esta herramienta eléctrica puede provocar lesiones INAPROPIADA O PELIGROSA
graves o la muerte!
Este manual contiene informaciĂłn importante sobre la seguridad del producto. Lea y comprenda este manual
ANTES de utilizar la herramienta eléctrica. Guarde este manual para que puedan leerlo otras personas
antes de utilizar la herramienta eléctrica. Este manual debe ser guardado en un lugar seguro.
GARANTÍA: El modelo CG22EAP(SLB) NO está diseñado para el uso comercial, y por lo tanto, NO se
brinda ninguna garantĂ­a para su uso comercial y alquiler.
CG 22EAP2 (SL)/CG 22EAP2 (SLD)
CG 22EAP2 (SLB)
Grass Trimmer
Coupe-Herbes
Motoguadañas
CG 22EAP2 (SL)
Designed for operating in USA & Canada only.
When this product is used in areas other than the USA & Canada,
we cannot guarantee the product quality and performance.
2
English
MEANINGS OF SYMBOLS
NOTE: Some units do not carry them.
Symbols
WARNING
The following show symbols used for the machine. Be sure that you understand
their meaning before use.
It is important that you read, fully
understand and observe the
following safety precautions and
warnings. Careless or improper
use of the unit may cause serious
or fatal injury.
Choke - Run position (Open)
Choke - Start position
(Closed)
Read, understand and follow all
warnings and instructions in this
manual and on the unit.
On/Start
Always wear eye, head and ear
protectors when using this unit. Off /Stop
Do not use metal/rigid blades
when this sign is shown on the
unit.
Emergency stop
Keep all children, bystanders
and helpers 15 m away from
the unit. If anyone approaches
you, stop the engine and cutting
attachment immediately.
Fuel and oil mixture
Idle speed adjustment
Be careful of thrown objects. Priming pump
min -1
Shows maximum shaft speed. Do
not use the cutting attachment
whose max rpm is below the
shaft rpm.
Hot surface – Contact with
hot surface can cause serious
burns.
Gloves should be worn
when necessary, e.g., when
assembling cutting equipment.
Indicate handle location.
Arrows which show limits for
handle positioning.
Use anti-slip and sturdy footwear.
Indicates cutting attachment
guard location for a trimmer
head or semi-auto cutting
head.
Before using your machine
• Read the manual carefully.
• Check that the cutting equipment is correctly assembled and adjusted.
• Start the unit and check the carburetor adjustment. See “MAINTENANCE”.
3
English
10
16 17
3
11
1
12 21
19 20
18
Contents
WHAT IS WHAT .................................................... 3
WARNINGS AND SAFETY INSTRUCTIONS ........ 4
WARRANTY .......................................................... 6
SPECIFICATIONS ................................................. 7
ASSEMBLY PROCEDURES ................................. 8
OPERATING PROCEDURES .............................. 11
MAINTENANCE .................................................. 14
WHAT IS WHAT
Since this manual covers several models, there may
be some diff erence between pictures and your unit.
Use the instructions that apply to your unit.
1. Fuel cap
2. Throttle trigger
3. Starter handle
4. Cutting attachment guard
5. Cutting attachment
6. Drive shaft tube
7. Handle
8. Hanger
9. Ignition switch
10. Harness (if so equipped)
11. Choke lever
12. Engine
13. Gear case
14. Cutter case
15. Joint case
16. Combi box spanner
17. Handling instructions
18. Swivel cap
19. Goggles
20. Hex. bar wrench
21. Muffl er cover
12
9
7
6
54
2
14
CG 22EAP2 (SLB)
12
9
7
6
13
5
4
2
CG 22EAP2 (SL)
12
97
15
6
13
5
4
2
8
CG 22EAP2 (SLD)
