Seite 1/28
©2019 Hestan Commercial Corporation
1
EN
OUTDOOR LIVING
SUITE
INSTALLATION INSTRUCTIONS
IMPORTANT - READ ALL INSTRUCTIONS BEFORE YOU BEGIN
THE INSTALLATION HEREIN SHOULD BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN
OR PROFESSIONAL OUTDOOR EQUIPMENT INSTALLER. MANY COMPONENTS ARE HEAVY AND
REQUIRE 2 OR 3 PERSONS TO UN-PACK AND SETUP THIS SUITE. FAILURE TO DO SO MAY RESULT
IN PERSONAL INJURY.
THE ELECTRICAL COMPONENTS SUPPLIED WITH THIS SUITE MUST BE INSTALLED BY A
LICENSED ELECTRICIAN AND CONNECTED IN ACCORDANCE WITH LOCAL CODES. THE SUITE
SHOULD BE CONNECTED TO A DEDICATED CIRCUIT BREAKER. ALL OUTLETS SUPPLIED WITH
THIS SUITE ARE GROUND FAULT CIRCUIT INTERRUPTER OUTLETS AND MUST BE PROPERLY
INSTALLED AND GROUNDED BY A LICENSED ELECTRICIAN TO GUARANTEE SAFE AND RELIABLE
OPERATION.
SOME PARTS INSIDE THE SUITE HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING
THE VARIOUS COMPONENTS TO AVOID PERSONAL INJURY. WEAR GLOVES WHEN HANDLING.
TOOLS REQUIRED:
Work gloves
Safety glasses
Power drill with masonry bits
Concrete / masonry anchors & hardware
Flat and Phillips screwdrivers
Socket wrench with 7/16” & 9/16” sockets and short extensions
Combination wrenches of 7/16” & 9/16” sizes
3/32 Allen wrench
Level
IF THE INFORMATION IN THE GAS-FIRED APPLIANCE MANUALS
ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
Flammable Gas - disconnect all propane or natural gas supplies to this unit
before servicing.
Electrical Parts & Components – disconnect all power supplies and
batteries before servicing.
AFTER INSTALLATION OF YOUR GRILL AND OTHER GAS-FIRED EQUIPMENT IN THIS
SUITE, READ THE MANUAL(S) PROVIDED WITH THOSE PRODUCTS CAREFULLY AND
COMPLETELY BEFORE USING THEM TO REDUCE THE RISK OF FIRE, BURN HAZARD,
OR OTHER INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE.
GESS08 GESS12 GESSP12 GESSK12
GESD08 GESD12 GESDP12 GESDK12
GESSB08 GESSB12 GESSBP12 GESSBK12
GESDB08 GESDB12 GESDBP12 GESDBK12
©2019 Hestan Commercial Corporation
2
EN
SUITE MODELS WITH STAINLESS STEEL TOP
Suite GESS08 shown with:
GABR36 Built-In Gas Grill
ABG122 Double Side Burner
AGAD36 Double Access Doors
GRSR24 Outdoor Fridge
ALL ITEMS PURCHASED SEPARATELY
Below are representations of some Hestan Outdoor Living Suites covered in this manual.
Suite GESDB12 shown with:
GABR42 Built-In Gas Grill
ABG122 Double Side Burner
AGTC Trash Chute
AGAD42 Double Access Doors
AGDR16 Double Drawers
AGTRC20 Trash & Recycling Center
GFDSR241 Outdoor Single Faucet Beer Dispenser
ALL ITEMS PURCHASED SEPARATELY
MODEL # D IPT NESCR IO
G 08 GRILL UTD R LIVIN SUITE CO TERTOP 8 F TESS , O OO G , SS UN , OO
G D08 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R 8 F TES , O OO G , SS UN / BEE SPE SE , OO
G 08 GRILL UTD R LIVIN SUITE CO TERTOP & R 8 F TESSB , O OO G , SS UN BA , OO
G DB08 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R & R 8 F TES , O OO G , SS UN / BEE SPE SE BA , OO
G 12 GRILL UTD R LIVIN SUITE CO TERTOP 12 FOOTESS , O OO G , SS UN ,
G D12 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R 12 FOOTES , O OO G , SS UN / BEE SPE SE ,
G 12 GRILL UTD R LIVIN SUITE CO TERTOP & R 12 FOOTESSB , O OO G , SS UN BA ,
G DB12 GRILL UTD R LIVIN SUITE CO TERTOP w RES , O OO G , SS UN / BEE DISPEN R & R 12 FOOTSE BA ,
G 12 GRILL UTD R LIVIN SUITE CO TERTOP POWER B ER 12 FOOTESSP , O OO G , SS UN , URN ,
G DP12 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R POWER B ERES , O OO G , SS UN / BEE SPE SE , URN , 12 FOOT
G 12 GRILL UTD R LIVIN SUITE CO TERTOP & R POWER B ER 12 FOOTESSBP , O OO G , SS UN BA , URN ,
G D 12 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R & R POWER B ERES BP , O OO G , SS UN / BEE SPE SE BA , URN , 12 FOOT
G 12 GRILL UTD R LIVIN SUITE CO TERTOP MAD RILL 12 FOOTESSK , O OO G , SS UN , KA O G ,
G DK12 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R MAD RILL 12 FOOTES , O OO G , SS UN / BEE SPE SE , KA O G ,
G 12 GRILESSBK L, OUTD R LIVIN SUITE CO TERTOP & R MAD RILL 12 FOOTOO G , SS UN BA , KA O G ,
G D 12 GRILL UTD R LIVIN SUITE CO TERTOP w R DI N R & R MAD RILL 12 FOOTES BK , O OO G , SS UN / BEE SPE SE BA , KA O G ,
HESTAN OUTDOOR LIVING SUITES
©2019 Hestan Commercial Corporation
3
EN
LOCATING THE SUITE
LOCATION
When determining a suitable location for your grill and suite, take into account concerns such as exposure to
wind, rain, sprinklers, proximity to traffic paths, and keeping any gas supply line runs as short as possible.
Locate the grill only in a well-ventilated area. Never locate the grill in a building, garage, breezeway, shed or
other such enclosed areas without an approved ventilation system. Never locate the grill over, under, or next
to unprotected combustible construction.
AIRFLOW / WINDY AREAS
During heavy use, the grill will produce a lot of heat and smoke. The grill is designed to take in cool air at the
front control panel area, and send the combustion products and smoke out the exhaust gap at the rear of the
hood. IT IS IMPORTANT TO MAINTAIN THIS FLOW AT ALL TIMES.
Using the grill in windy areas can disrupt the proper flow and cause damage to your grill, or result in burn
hazards to the user. Initial indications of this situation are very hot control knobs. Using an oven mitt or
other protection, and while keeping your face away, immediately open the hood to release the built up
heat inside the grill. Turn down the burners to a lower setting. It is very important that the suite & grill is
oriented so the prevailing wind is toward the front of the grill as seen below in Fig. 1.
For built-in grill installations which consistently receive wind at the rear of the grill, a Wind Screen accessory
is available from Hestan. Contact your Hestan dealer for details.
Damage caused from use in windy conditions, such as melted knobs
and/or wiring, discoloration of the control panel, etc., is excluded from
warranty coverage.
The Hestan Outdoor Living suite features ventilation openings (louvers) on each end. These
openings must be clear to avoid accumulation of gas should there be a leak. These openings are
further described later in this manual.
Figure 1
