User Manual
Haier Solar Water Heater
Models
GV100REMB
GV150REMB
GV200REMB
GV300REMB
GV100RNF
GV150RNF
GV200RNF
GV300RNF
Table of Contents
Safety cautions ..........................2
Product features ........................3
Techinical parameters ...............3
Installation instructions ..........3-8
Troubleshooting ........................8
Operation instructions ...............9
Packing list ................................9
Guarantee ..........................10-11
Please read through the manual before use.
Please keep the manual for future reference.
Safety cautions (please read the cautions before use)
Prohibit
Behaviors that
are prohibited Warning
Directions that
must be followed Caution
Directions that
must be noted
Description of symbols
Warning! Improper operation of the following may lead to personal injury or even death!
Do not touch glass vacuum tube,
pipes and valves for supplying hot
water during use to avoid being
burned.
Please feel the water temperature by
hand before use to make sure of
proper water temperature while in use
Personnel other than professional
maintenance staff are prohibited from
repairing, maintenance, dismantling
or altering the water heater without
authorization.
Warning
Prohibit
Prohibit Prohibit
Caution! Improper operation of the following may lead to personal injury or even death
or property loss!
The glass vacuum tube shall not be
exposed for a long period without
water inside after installation to avoid
the shortening of the service life. If it
cannot be used immediately, it shall
be covered.
The water heater is equipped with a
special venting pipe and overflow
pipe. To ensure normal operation,
never refit or plug their outlets.
Otherwise the water tank will shrink.
Water shall be fed in early morning or
at night when the sunligth is
insufficient. The water feeding after
sunlight exposure of the glass
vacuum tube will cause an explosion
of the pipe.
The source of the energy for the water
heater is solar energy. So it may be
incapable of being used normally
under cloudy, rainy and snowy
weather conditions due to the failure
to reach desired water temperature
because of the insufficient sunlight
exposure. If there is no electric
heating as an auxiliary energy source,
it may be unable to be used normally.
Please do not use the hot water in
the heater for drinking or similar
purposes.
To guarantee effectiveness, do not
feed water to the heater several times
within one day in case of insufficient
sunlight exposure.
Caution
Warning
The glass vacuum tubes can
withstand a low temperature of -70
oC
when they are not filled with water.
When the auxiliary heating device is
not to be used, on continuous cloudy
days in winter or when the tubes are
covered by snow, be sure to keep the
water tank full of water and replace
the cold water in the tank frequently
(every 2 days). Otherwise the water
retained in the tank will cause the
vacuum tubes to break.
When the heater with auxiliary electric
heating function is used, ensure the
auxiliary electric heater and electric
heating accompanying strap are in
OFF state.
Prohibit
Caution
Warning
Warning
Warning
This is a zero pressure system and care has to be taken that there is no pressure
builtup inside the tank. Install a vent pipe as indibated earlier.
Maximum water head of the overhead tank should be 4 meters.
When there is no water inside the system or when the system is not in use for more
than 2-3 days, cover the vacuum tubes with an opaque cover, so that light will not pass
to the tubes.
The vacuum tubes, being fragile, should be handled with care and should be protected
from any object falling on the tubes after installation.
- Suggestions -
2
30 16 22 3012
Product features
Product features Technical parameters Installation instructions
1. Inner cylinder made of 445 J1M stainless steel
The inner cylinder of the water tank adopts sanitary 445 J1M stainless steel, featuring
strong corrosive resistance and durability.
2. High efficiency & energy-saving thermal insulation
With intergrated polyurethane foam insulation for solar water heaters, realize good heat
preservation and minimize heat loss.
3. PCM color steel plate outer shell of water tank
PCM color steel plate sheet boasting outstanding corrosion resistance, oxidation
resistance and weather ability is the first choice for outdoor protective materials.
4. Tower type frame
The tower type frame, made of carbon steel by means of spray processing, has the
advantages of a stable structure, attractive apperance and corrosion resistance.
Technical parameters
Model
Specifications of the
glass vacuum tubes
GV100REMB
Frame form
Number of the
glass vacuum tubes
Aperture area
Usable water
Electric auxiliary
heating
GV150REMB GV200REMB GV300REMB GV100RNF GV150RNF GV200RNF GV300RNF
φ 58mm x 1800mm, all-glass vacuum tube collector
Horizontal 35o
12 16 22
1.51m22.02m22.80m23.83m21.51m22.02m22.80m23.83m2
300L 150L 200L 300L100L100L 150L 200L
1500W/220V; 1650W/230V
Note: The deviation of the aperture area is 3%≤；
The permitted error limit of other parameters is ± 10%.
Installation instructions
Selection of installation location 1. The water heater shall be installed within the
lightening protected area of a building in locations
prone to lightening strikes.
2. The orientation of the water heater to be installed:
10o south by east and 15o south by west in the
Northern Hemisphere;
10o north by west and 15o north by east in the
Southern Hemisphere.
3. There must be no shielding object in front of the
installation location of the water heater. If an object
exists, the space between the heater and the
objective shall be more than L,
(wherein: H- height of the shielding objective;
α- local latitude)
3
