Seite 1/4
www.hager.com
Safety instructions
Electrical equipment must only be installed and assembled by a qualiîšżed
electrician in accordance with the relevant installation standards, regulations,
directives and safety and accident prevention directives of the country.
Failure to comply with these installation instructions may result in damage to
the device, îšżre or other hazards.
Function
Multiple frames for 2gang to 5gang combinations of ush-mounted devices.
The frames are suitable for vertical as well as for horizontal installation.
Correct use
- For ush-mounted installation with standard connectable wall boxes.
- Only suitable for use in indoor areas with no drip and no spray water.
Technical data
For horizontal installation:
Dimensions (Width x Height)
- 2gang: 170.2 x 86 mm
- 3gang: 256.3 x 86 mm
- 4gang: 342.3 x 86 mm
- 5gang: 428.3 x 86 mm
For vertical installation:
Dimensions (Width x Height)
- 2gang: 86 x 170.2 mm
- 3gang: 86 x 256.3 mm
- 4gang: 86 x 342.3 mm
- 5gang: 86 x 428.3 mm
Multi-gang frames
2gang / 3gang / 4gang / 5gang
Hager Dream
Installation manual
2
Information for electricians
Installation and electrical connection
Preparing the devices for installation
îš„Remove cover at every single device to be combined (see installation manual of the
respective device).
Connecting the devices for multiple combinations
(for example with "3gang frame (horizontal)")
For îšżtting of the devices the multi-gang frame has two diagonally arranged snap mecha-
nisms (1). On the outside corners of the supporting plate the devices have corresponding
îšżxing holes for snapping onto multi-gang frame.
1
Fixing holes
Snap
mechanisms
Click
Click
Click
Click
Click
Click
îš„Depending on the application position the multi-gang frame horizontally or vertically.
Example here: horizontal (1).
îš„Snap the devices one after the other in the desired order on the multi-gang frame (1).
3
Installing the device combination into the wall box
(for example with “3gang frame (horizontal)”)
DANGER!
Touching live parts can result in an electric shock.
An electric shock can lead to death.
Disconnect the connecting cables before working on the device and
cover all live parts in the area!
ç
îš„Wire each device of the combination according to its wiring diagram (see installation
manual of the respective device).
2
Multigang frame
îš„After wiring, îšżx the device combination with the screws into the wall boxes ( ).2
