Let’s get

started.

GL-AX1800 / Flint

AX Wireless Router1800

Set Up Router

Visit http://192.168.8.1 in your browser to set

up your router; start by choosing your preferred

language.

Power On

When powered up, your router will broadcast

both 2.4G and 5G Wi-Fi signal with the SSID:

GL-AX1800-xxx GL-AX1800-xxx-5G and .

Default password is goodlife

Search the SSID and connect to it

Connect to the Wi-Fi called , GL-AX1800-xxx

and then input the default Wi-Fi password

goodlife, which is also printed on the bottom

of the router.

Connect via Wi-Fi Connect via LAN

Plug the cable connecting

to your computer into LAN port

Plug in power cable

SETTING UP

SUPPORT

Technical Supports

For more detailed and updated instructions, please visit our website docs.gl-inet.com

For further questions, you can get help from the following ways:

- Email to support@gl-inet.com

- Message us on our Facebook: facebook.com/gl.inet.wiﬁ/

- Post questions in our forum: forum.gl-inet.com

- Ask professionals in other forums e.g. OpenWrt, LEDE or other professional websites

Repair / Reset

If you cannot access the web-based setup page or cannot connect to the router,

you can press the button:Reset

Press and hold for , and then release to repair your network.3 seconds

Press and hold for , and then release to reset the router to 10 seconds

factory settings. All user data will be cleared. https://docs.gl-inet.com/en/3/

USB3.0 port

LAN port

WAN port

Reset button

Sync button

LED light

WARRANTY

We provide for routers and for accessories. Extra warranty may apply one year limited warranty 3-month limited warranty

according to the local law in which the product purchase took place.

Highly recommend using the included power adapter.12V/1.5A

Any damage to the router caused by not following the instructions will render this warranty null and void.

Any damage to the router caused by modifying the PCBA, components or case will render this warranty null and void.

Issues caused by the use of third-party firmware may not get official support from us.

Any damage to the router caused by inappropriate use, e.g. inappropriate voltage input, high temperature, dropping in the water or

on the ground will render this warranty null and void.

Pictures on the instructions are only for reference. We reserve the right to change or modify these materials without further notice.

ver. 20210824

GL Technologies (Hong Kong) Limited

Unit 203, 2/F, Building 19W, 19 Science Park West Avenue,

Hong Kong Science Park, Pak Shek Kok, N.T., Hong Kong

Hong Kong Ofﬁce

Shenzhen Guanglianzhitong Tech Co., Ltd.

Room 305 - 306, Skyworth Digital Building, Shiyan Street,

Baoan District, Shenzhen, China, 518000 ( +86-0755-86606126 )

Shenzhen Ofﬁce

Hereby, GL TECHNOLOGIES (HONG KONG) LIMITED declares that the radio equipment type [AX1800 Wireless Router, GL-AX1800] is in compliance with the essential

requirements and other relevant provisions of Directive 2014/53/EU.The full text of the EU declaration of conformity is available at the following internet address:

https://www.gl-inet.com/products/certificate

Caution:

This product uses WiFi 2.4GHz Operating Frequency is 2400~2483.5MHz/20dBm; 5GHz Operating Frequency is 5150~5250MHz/23dBm.

Restriction Statement:

The 5150~5250MHz band is allocated for indoor use only.

Restriction in BE, BG, CH, CZ, DK, DE, EE, IE, EL, ES, FR, HR, IT, CY, LV, LT, LU, HU, MT, NL, AT,PL, PT, RO, SI, SK, FI, SE, UK(NI).

The Product comply with Directive 2011/65/EU and its amendment directive 2015/863/EU (RoHS2.0)

1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired operation.

2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

3. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help important announcement.

FCC ID: 2AFIW-AX1800

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum

distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
