Owner’s Manual
Stationary Diesel Generators
Residential and Commercial
15–50 kW, 12–40 kVA
Protector™ Series
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(888-436-3722)
Para español , visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter : http://www.generac.com/service-support/product-support-lookup
Para portugues, visite: http://www.generac.com/service-support/product-support-lookup
Найти языке версию на русском : http://www.generac.com/service-support/product-support-lookup
SAVE THIS MANUAL FOR FUTURE REFERENCE
®
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
ii Owner’s Manual for Stationary Diesel Generators
Use this page to record important information about the generator.
For quick and easy reference, copy the information
printed on the Unit Identification Label into the table pro-
vided below. The Unit Identification Label is located on
the left engine mount on 15/20 kW (2.5L) models, on the
left side of the radiator shroud on 30 kW (2.2L) models,
and on the left side of the engine support rail on 48/50
kW (3.3L) models. The label provides the following infor-
mation:
Model Number
Serial Number
Rated KW or kVA
Voltage Rating
Maximum Current
Rating (AMPS)
Always provide the complete model number and serial
number when contacting an Independent Authorized Ser-
vice Dealer (IASD) about parts and/or service.
Operation and Maintenance: Correct maintenance and
care of the unit ensures a minimum number of problems,
and keeps operating expenses at a minimum. It is the
operator’s responsibility to perform all safety inspections,
to verify all maintenance for safe operation is performed
promptly, and to have the equipment inspected periodi-
cally by an IASD. Normal maintenance, service, and
replacement of parts are the responsibility of the owner/
operator and are not considered defects in materials or
workmanship within the terms of the warranty. Individual
operating habits and usage may contribute to the need
for additional maintenance or service.
Contact an IASD for assistance when the generator
requires servicing or repairs. IASDs are factory-trained
and are capable of handling all service needs.
SAMPLE LABEL
006366
(000394)
WARNING
Breathing diesel engine exhaust exposes you
to chemicals known to the State of California
to cause cancer and birth defects or other
reproductive harm.
• Always start and operate the engine in a
well-ventilated area.
• If in an enclosed area, vent the exhaust to
the outside.
• Do not modify or tamper with the exhaust
system.
• Do not idle the engine except as necessary.
For more information go to
www.P65Warnings.ca.gov/diesel.
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.
INDEPENDENT AUTHORIZED
SERVICE DEALER LOCATION
To locate the nearest
INDEPENDENT AUTHORIZED
SERVICE DEALER,
please call this number:
1-800-333-1322
or visit the dealer locator at:
www.generac.com/Service/DealerLocator/
Owner’s Manual for Stationary Generators iii
Section 1: Safety Rules & General
Information
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
Safety Rules .........................................................1
How to Obtain Service .................................................1
General Hazards ..................................................2
Exhaust Hazards ..................................................2
Electrical Hazards ................................................3
Fire Hazards .........................................................3
Explosion Hazards ...............................................3
Section 2: Specifications
Emission Information ..........................................5
Emissions Data Plate ..................................................5
Specifications ......................................................6
Engine .........................................................................6
Engine Oil Recommendations ............................7
Coolant Water Treatment ....................................7
Fuel Requirements ..............................................7
Fuel Maintenance ........................................................7
Corrosion Protection ...........................................7
Battery Requirements .........................................8
Battery Charger ...........................................................8
Battery Disposal ..................................................8
Accessories ..........................................................8
Section 3: Activation and Startup
Introduction ........................................................11
Orientation ..........................................................11
Removing Side Access Panels .........................11
Priming Fuel System .........................................11
Installing Battery (2.5L Models) ........................12
Opening Viewing Window .................................13
Starting and Running Engine ...........................13
Testing Auxiliary Shutdown Switch
Operation ............................................................13
Activate Unit .......................................................14
Operational Checks ...........................................15
Self Test ....................................................................15
Checking Manual Transfer Switch Operation ............15
Electrical Checks .......................................................15
Testing Generator Under Load ..................................16
Checking Automatic Operation ..................................16
Final Instructions .............................................. 17
Shutting Generator Down While Under
Load or During a Utility Outage ....................... 17
Section 4: Operation
Control Panel ..................................................... 19
AUTO/MANUAL/OFF ......................................... 20
Menu Navigation ................................................ 20
Alarm/Warning Conditions ............................... 22
Changing Time and Date .................................. 22
Programmable Timers ...................................... 22
Dealer Programmable ...............................................22
User Programmable ..................................................22
USB Port for Firmware Updates ....................... 22
Battery Charger ................................................. 23
Transfer Switch Automatic Operation ............. 23
Automatic Sequence of Operation ............................23
Transfer Switch Manual Operation .................. 24
Transfer to Generator Power .....................................24
Transfer Back to Utility Power ...................................24
Section 5: Maintenance
Component Locations ...................................... 25
Access Panels ................................................... 27
Removal .................................................................... 27
Installation .................................................................27
Service Maintenance Intervals ......................... 27
Remove From Service ....................................... 28
30 Hour Break-In ................................................ 29
Daily Maintenance (If Running
Continuously) .................................................... 29
Schedule A Maintenance .................................. 29
Preliminary Instructions .............................................29
Checking Fuel Level and Fill .....................................29
Draining Fuel Filter and Inspect Fuel Lines/Hoses ....30
Inspecting Coolant Level and Hoses .........................30
Checking Radiator for Clogging ................................30
Checking Lubricating Oil Level ..................................31
Checking Battery Condition/Fluid Level ....................31
Battery Replacement .................................................32
Inspecting and Adjusting V-Belt ................................ 33
Adjusting V-Belt Tension ...........................................33
Replacing Air Filter Element—2.5L Engine ..... 34
Replacing Air Filter Element—2.2L Engine ..... 34
Table of Contents
