Seite 1/40
Owner’s Manual
3 Phase 60 Hz Air-Cooled Generators
20 kW
SAVE THIS MANUAL FOR FUTURE REFERENCE
®
Para español, visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter : http://www.generac.com/service-support/product-support-lookup
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(888-436-3722)
(000209a)
WARNING
This product is not intended to be used in
a critical life support application. Failure to
adhere to this warning could result in
death or serious injury.
ii Owner’s Manual for 60 Hz Air-Cooled Generators
Use this page to record important information about your generator set.
Record the information found on your unit data label on this
page. See General Information for the location of the unit
data label. The unit has a label plate affixed to the inside
partition, to the left of the control panel console as shown in
Figure 2-1. See Operation for directions on how to open the
top lid and remove the front panel.
When contacting an Independent Authorized Service Dealer
(IASD) about parts and service, always supply the complete
model and serial numbers of the unit.
Operation and Maintenance: Proper maintenance and care
of the generator ensures a minimum number of problems
and keeps operating expenses at a minimum. It is the
operator’s responsibility to perform all safety checks, to
make sure that all maintenance for safe operation is
performed promptly, and to have the equipment checked
periodically by an IASD. Normal maintenance, service, and
replacement of parts are the responsibility of the owner/
operator and are not considered defects in materials or
workmanship within the terms of the warranty. Individual
operating habits and usage may contribute to the need for
additional maintenance or service.
When the generator requires servicing or repairs, Generac
recommends contacting an Independent Authorized Service
Dealer for assistance. Authorized service technicians are
factory–trained and are capable of handling all service
needs.To locate the nearest Independent Authorized Service
Dealer, please visit the dealer locator at:
www.generac.com/Service/DealerLocator/
Model:
Serial:
Prod Date Week:
Volts:
LPV Amps:
NG Amps:
Hz:
Phase:
Controller P/N:
(000005)
WARNING
California Proposition 65. This product contains or
emits chemicals known to the state of California to
cause cancer, birth defects, and other reproductive
harm.
(000004)
WARNING
California Proposition 65. Engine exhaust and some
of its constituents are known to the state of California
to cause cancer, birth defects, and other reproductive
harm.
Owner’s Manual for 60 Hz Air-Cooled Generators iii
Section 1: Safety Rules & General
Information
Introduction ..........................................................1
Read This Manual Thoroughly ....................................1
How to Obtain Service .................................................1
Safety Rules .........................................................2
General Hazards ..................................................2
Exhaust Hazards .........................................................3
Electrical Hazards .......................................................3
Fire Hazards ................................................................4
Explosion Hazards ......................................................4
Section 2: General Information
The Generator ......................................................5
Specifications ......................................................6
Generator ....................................................................6
Engine .........................................................................6
Protection Systems .............................................7
Emission Information ..........................................7
Fuel Requirements ..............................................7
Battery Requirements .........................................7
Battery Charger ....................................................7
Engine Oil Requirements ....................................7
Activating the Generator .....................................7
Replacement Parts ..............................................8
Accessories ..........................................................8
Section 3: Operation
Site Prep Verification ...........................................9
Generator Enclosure ...........................................9
Opening the Lid ...........................................................9
Removing the Front Access Panel ..............................9
Intake Side Panel Removal .........................................9
Main Line Circuit Breaker (Generator Disconnect) ......9
LED Indicator Lights ..................................................10
Control Panel Interface .....................................11
Using the AUTO/OFF/MANUAL Interface ........11
Interface Menu Displays ....................................11
The LCD Panel ..........................................................11
Menu System Navigation ..........................................12
Setting the Exercise Timer ............................... 14
Battery Charger ................................................. 14
Manual Transfer Operation ............................... 15
Transfer to Generator Power Source ........................15
Transfer to Utility Power Source ................................16
Automatic Transfer Operation ......................... 16
Automatic Sequence of Operation .................. 16
Utility Failure ..............................................................16
Cranking ....................................................................16
Cold Smart Start ........................................................17
Load Transfer ............................................................17
Shutting Generator Down While Under Load
Or During An Extended Outage ....................... 17
To turn the generator OFF ........................................ 17
To turn the generator back ON ..................................17
Section 4: Maintenance
Maintenance ....................................................... 19
Preparing for Maintenance ............................... 19
To turn the generator OFF: ....................................... 19
To turn the generator back ON: .................................19
Performing Scheduled Maintenance ............... 19
Service Schedule ............................................... 20
Maintenance Log .......................................................20
Checking Engine Oil Level ............................... 21
Engine Oil Requirements .......................................... 21
Changing the Oil and Oil Filter ......................... 22
Servicing the Air Cleaner .................................. 22
Spark Plugs ........................................................ 22
Valve Clearance Adjustment ............................ 23
Check Valve Clearance .............................................23
Adjust Valve Clearance .............................................23
Battery Maintenance ......................................... 24
Cleaning the Sediment Trap ............................. 25
Perform Leak Test ............................................. 25
Attention After Submersion ............................. 26
Corrosion Protection ........................................ 26
Table of Contents
