Installation Guidelines
For
Manual Transfer Switches 6335 / 6382
This manual should remain with the unit.
This manual must be used in conjunction with
the appropriate owners manual.
*NOT INTENDED FOR USE IN CRITICAL LIFE SUPPORT
APPLICATIONS.
*ONLY QUALIFIED ELECTRICIANS OR CONTRACTORS
SHOULD ATTEMPT INSTALLATION!
ii Transfer Switch Installation Guidelines
Forward
INTRODUCTION: Thank you for purchasing a Generac Transfer Switch to safely connect a portable generator to the load center
in your home or business (single phase only) for standby power applications. Product features include:
Generator and Utility Mains mechanically interlocked preventing utility or generator power back feed.
Full branch circuit protection with Siemens circuit breakers.
12 gauge High Corrosion-resistant aluminum cabinet.
Ample ground and neutral termination positions for all branch circuits.
Extra spaces for branch circuit breakers.
Subfeed lugs provided to feed additional downstream panels or to expand beyond 16 circuits.
Accepts a Switched Neutral Kit (Model 6297). See Note on Neutral Bonded Generators found on page 5.
Description
This unit is a combination indoor/outdoor transfer switch and distribution panel. It can be used as service entrance equipment for 200 Amp services. In
addition to being a transfer switch, this unit provides additional circuits for outdoor applications such as air conditioner compressors, sewage lift pumps,
boat docks, outbuildings, garages, pump houses, barns and the like. These 200 amp series models will accommodate 12 single pole circuits.
This transfer switch is made up of five basic elements:
1. 200 amp rated Utility Main Breaker
2. Generator Main Breaker
3. A 30 or 50 amp 125/250 volt inlet pre-wired to the generator breaker
4. A mechanical safety interlock that prevents both Mains from being “ON” at the same time
5. A set of sub-feed lugs to handle cable up to 4/0 AWG to feed the house Main panel.
READ THIS MANUAL THOROUGHLY. This manual has been prepared to familiarize personnel involved with the
installation of transfer switches with the manufacturer’s installation requirements. Information and instructions con-
tained herein are not intended to replace or supersede, local, state, or national safety, electrical, and building codes
pertaining to such installations. Applicable laws, codes, and standards must always take precedence over the recom-
mendations contained herein. Always check with the local Authority Having Jurisdiction (AHJ) for the codes or stan-
dards that apply.
Only authorized dealers or qualified, competent installation contractors or electricians thoroughly familiar with applica-
ble codes, standards, and regulations should install this standby electric power system. The installation must be in strict
compliance with all codes, standards, and regulations.
It is not intended that this manual be a transfer switch. used by any unqualified person for the purpose of installing
Installation, inspection, and testing of the system must be attempted only by competent, qualified electricians or instal-
lation contractors who are familiar with the equipment and with all installation codes and requirements.
It would be impossible to provide details for every installation configuration. For this reason, much of the information in
this manual is general in nature. Illustrations of typical installations are not intended to serve as specific installation
plans, but may be used in the planning and design process when considering the selection and purchase of a genera-
tor set for standby power applications. Always have the unit specific drawings and manuals on hand before beginning
any installation.
If a portable generator is used to power electrical load circuits normally powered by a utility
power source, it is required by code to install a transfer switch. The transfer switch must
effectively isolate the electrical system from the utility distribution system when the generator
is operating. Failure to isolate an electrical system by such means may result in damage to the
generator and may also result in injury or even death to utility power workers due to backfeed
of electrical energy.
After the transfer switch has been installed, do nothing that might render the installation in non-
compliance with such codes, standards, and regulations. Every effort was made to ensure that
the information in this manual was both accurate and complete at the time it was released.
However, the manufacturer reserves the right to change, alter, or otherwise improve this product
at any time without notice.
*
Transfer Switch Installation Guidelines iii
Section 1 Safety
1.1 Introduction .......................................................................................................................... 1
1.2 Safety Rules .......................................................................................................................... 1
1.3 General Hazards ................................................................................................................... 1
1.4 Electrical Hazards ......................................................................................... ........ 2...............
1.5 Fire Hazards .......................................................................................................................... 2
1.6 Explosion Hazards ............................................................................................................... 2
1.7 Standards Index ................................................................................................................... 2
Section 2 Installation
2.1 Required Tools ..................................................................................................................... 3
2.2 Compatible Circuit Breakers Types .................................................................................... 3
2.3 Specications .......................................................................................................................4
2.4 Transfer Switch Installation ................................................................................................4
Section 3 Operation
3.1 Transferring from Utility Power to Generator Power ........................................................7
3.2 Transferring from Generator Power to Utility Power ........................................................ 7
WARNING!
California Proposition 65
Engine exhaust and some of its constituents are known to the state of California to cause cancer,
birth defects, and other reproductive harm.
WARNING!
California Proposition 65
This product contains or emits chemicals known to the state of California to cause cancer,
birth defects, and other reproductive harm.
Table of Contents
Forward ....................................................................................................................ii
