Seite 1/8
03908 04/19
Important: Retain these instructions for future use.
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call your gas supplier.
Do not store or use gasoline or other flammable vapour
and liquids in the vicinity of this or any other appliance.
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the instructions thoroughly before installing or
servicing this equipment.
FOR OUTDOOR USE ONLY
PROPANE GAS
Model No. PH7056 / PH7057
The ideal solution for extending the outdoor
entertaining season
Direct ignition
Maximum output 40MJ/h
Adjustable heat output
Includes wheels
Operates for approximately 9 hours on a properly
filled 9Kg propane cylinder
Includes a safety ‘tip-over’ switch that halts supply of
gas to the unit should it be accidentally knocked over
Flame safeguard system for enhanced safety
Complete with hose and regulator
For outdoor use only
Gas certified to Australian standards
STELLAR BLACK
DELUXE PATIO HEATER
2
Installation, Operation and Maintenance Instructions
INSTALLATION 3. Proper clearance from combustible materials must be
maintained at all times. The minimum clearances are
as follows:
Minimum Clearance from Combustibles:
Side Rear 500 mm 500 mm
Ceiling 500 mm
Combustible materials are considered to be wood,
compressed paper, plant fibres, plastic, plexiglas or other
materials capable of being ignited and burned.
Such materials shall be considered combustible even
though flame proofed, fire-retardant treated or plastered.
Additional clearance may be required for glass, painted
surfaces and other materials which may be damaged by
radiant or convection heat.
4. Heaters must be placed on a level and adequate
footing and be readily accessible.
5. The gas manifold supply pressure must be regulated at
2.75 kPa utilising an AGA approved regulator (supplied
with heater).
6. The appliance must be inspected before each use, and
at least annually by a qualified service person.
a. The appliance area must be kept clear and free of
combustible materials, gasoline and other flammable
vapours and liquids.
b. Gas orifices and burner must be kept clear of dirt
and cobwebs. Flow of combustion and ventilation air
through the perforated portions of the heater must not
be obstructed. Cleaning with a soft brush before use
and at least every six months is recommended.
c. All gas connections should be checked for
leaks utilising a soap solution. Never use a flame for
this purpose.
d. The flame pattern should be visually checked
whenever heater is operated. If flames extend beyond
surface of the guard the appliance should be turned
off and should not be operated again until the unit is
serviced and or repaired.
e. Any cleaning agent used on the heater should be of a
non-combustible and non-corrosive nature.
f. The stainless steel emitter normally does not require
cleaning and should be painted. NEVER
Important Safety Rules
This appliance must only be used in a well ventilated
area.
1. This appliance shall not be installed or used
indoors, in buildings, garages or any other
enclosed area.
2. place articles on or against this DO NOT
appliance.
3. use or store flammable materials near DO NOT
this appliance.
4. Children and adults should be alerted to the
hazards of high surface temperatures, burns and
clothing ignition.
5. Children should be carefully supervised when
they are in the area of the appliance.
6. hang anything including clothes or other NEVER
flammable items on the appliance.
7. operate this appliance unless it is fully DO NOT
assembled with burner guard in place.
8. DO NOT SPRAY AEROSOLS IN THE VICINITY
OF THIS APPLIANCE WHILE IT IS IN
OPERATION.
9. Installation and repair should be done by a
qualified service person. The appliance must be
inspected before use and at least annually by
a qualified service person. It is imperative that
control compartment, burners and circulating air
passages of the heater be kept clean.
Prior to assembling your appliance, the following must
be reviewed. Compliance with the following should result
in satisfactory heater operation. This instruction manual
should be retained for future reference. The installation
must conform with local codes or authority having
jurisdiction.
1. The patio heater is intended for heating residential
and non-residential outdoor spaces. The installation
must conform with local codes and with the Australian
Standard AS/NZS 5601.
2. Adequate clearance around air openings into the
combustion chamber, clearances from combustible
materials, provisions for accessibility and for
combustion and ventilating air supply must be
maintained at all times when the appliance is
operating.
3
7. The hose must be protected from contact with hot or
sharp surfaces both during use and while in storage.
The hose assembly should be visually inspected prior
to each use of the heater. If excessive abrasion or
wear is evident, or the hose is cut, it must be replaced
prior to operating the heater. The replacement hose
assembly may be obtained from the manufacturer.
8. use any pressure regulator or hose assembly DO NOT
other than those supplied with the appliance.
Replacement pressure regulator and hose assembly
must be those specified. Replacement parts maybe
obtained from the manufacturer or your local sales
representative.
9. Installation and use of this heater must conform with
local codes and AS/NZS 5601.
10. This heater is designed to operate with a standard 9Kg
propane cylinder with Approved Cylinder Connection.
11. The valve outlet must be maintained in good condition.
When the cylinder is not in use, be sure to cover it
with a dust cap. A leak test should be performed with
soapy water whenever connecting a new cylinder.
NEVER use a match to test for leaks.
12. The propane cylinder must be turned off whenever the
heater is not in use. When the heater is to be stored
indoors, the propane cylinder and the heater must be
disconnected and the cylinder stored in accordance
with the Standard for Storage and Handling of
Liquefied Gases.
13. The patio heater has been designed with several safety
features which include a tip over switch.
NOTE: The plastic container in the base must be filled with
sand before use.
Any modification to the heater not described in the
installation instructions may compromise the safety of this
appliance. Special concern is as follows:
(1) shorten post length;DO NOT
(1) bypass thermocouple safety;DO NOT
(2) operate heater without the reflector;DO NOT
Clothing or other flammable materials should not be hung
from the heater, or placed on or near the heater. The area
above the burner may be extremely hot. Direct contact with
these metal surfaces should be avoided in order to prevent
burns or clothing ignition.
IMPORTANT
Storage of an appliance indoors with the cylinder
attached is only permitted if the size of the cylinder
complies with AS/NZS 1596; otherwise cylinders must
be stored outdoors in a well ventilated area.
Screw the coupling nut of regulator into the cylinder valve
outlet.
POL CYLINDER CONNECTION DEVICE
Type of Gas Propane
Consumption 40 MJ/h
Operating Pressure 2.75 kPa
Injector Size 1.9 mm
PH7056 Colour Black
PH7057 Colour Graphite
Heater specifications can be found on the data label.
