IMPORTANT
Read these instructions for use carefully.
Familiarise yourself with the appliance
before connecting it to its gas container.
Keep these instructions for future
reference.
ONLY USE IN WELL-VENTILATED AREAS.
CARBON MONOXIDE HAZARD - USING THIS
APPLIANCE IN AN ENCLOSED SPACE MAY CAUSE
DEATH. DO NOT USE IN CARAVANS, TENTS,
MARINE CRAFT, CARS, MOBILE HOMES OR
SIMILAR LOCATIONS.
• Do not modify this appliance.
• Check that seals between the appliance and
the gas container are in place and in good
condition before connecting the gas container.
• Do not use the appliance if it has damaged or
worn seals.
• Do not use this appliance if it is leaking,
damaged or does not operate properly.
• This appliance must only be serviced by an
authorized person.
• The openings at the base of the burner
provide air for combustion, they should never
 beobstructed.Iftheamebecomes
 signicantlyorangechecktheseopenings
for a blockage.
• If the appliance cannot be adjusted to
perform correctly it should not be used until
serviced or repaired.
• Tocheckthatthegascontainerislled,when
shaken a sloshing sound will be heard.
CAUTION: Accessible parts may be very hot.
Keep young children away.
USE OUTDOORS ONLY.
PROPANE/UNIVERSAL LPG PRODUCT
This appliance shall only be used with a propane
gascylindercertiedtoAS2469orUniversal
L.P.G.
IT MAY BE HAZARDOUS TO ATTEMPT TO
FIT OTHER TYPES OF GAS CONTAINERS.
Gas cylinders should be stored outdoors in a
well ventilated area out of reach of children. Any
indoorstorageshallcomplywithAS/NZS1596.
Only use the hose assembly as supplied with
this appliance for connection to the cylinder -
DO NOT USE ADAPTORS.
Maximum hose length is 100cm.
After use, turn the gas cylinder valve off, wait
fortheametogoout,andthenturnthe
appliance control valve(s) off.
Avoidtwistingorkinkingtheexiblehose.
If there is a leak on your appliance (smell
of gas) immediately attempt to turn off the
cylinder valve. Remove the appliance to a
well-ventilated location away from any ignition
source. Check for leaks using soapy water. Do
nottrytodetectleaksusingaame.
4403-06/16
Important: Retain these instructions for future use.
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber, Hamilton, N.Z. www.gasmate.co.nz
Classic Two Burner Stove
Model No. CS1095
Product Features:
• Fine burner adjustment controls
• Durablepowdercoatednish
• Removable cooking trivet for
easy cleaning
• Units folds to a compact size
with handle
• Windshields on three sides
• Completewithhosetosuit3/8”
BSP-LH cylinders
• For outdoor use only
• GascertiedtoAustralianand
New Zealand Standards
GENERAL INFORMATION SAFE APPLIANCE LOCATIONS
This appliance shall only be used in an above
ground open-air situation with natural ventilation,
without stagnant areas, where gas leakage and
products of combustion are rapidly dispersed by
wind and natural convection.
Any enclosure in which the appliance is used
shall comply with the following:
An enclosure with walls on all sides, but at least
one permanent opening at ground level and no
overhead cover (see Example 1).
Within a partial enclosure that includes an
overhead cover and no more than two walls
(seeExample2&3).
Within a partial enclosure that includes an
overhead cover and more than two walls, the
following will apply:
atleast25%ofthetotalwallareaiscompletely
open,andatleast30%oftheremainingwallarea
isopenandunrestricted(seeExample4&5).
In the case of balconies, at least 20% of the
total wall area shall be and remain open and
unrestricted.
DIAGRAMMATIC REPRESENTATIONS OF OUTDOOR AREAS
Thefollowingguresarediagrammaticrepresentationsofoutdoorareas.Rectangularareashavebeen
usedinthesegures–thesameprinciplesapplytoanyothershapedarea.
INSTRUCTIONS
Read these instructions for use carefully.
Familiarise yourself with the appliance
before connecting it to its gas container.
Keep these instructions for future reference.
1. Remove appliance from carton and remove
any transit protection material.
2. Open the lid to the vertical position, fold out
the windshield and engage the clips with the
slots in the side of the body.
3. Lift the front edge of the wire trivet to remove
the hose from its storage position and replace
 thetrivet.Checkthe“O”ringsforany
damage before connecting hose. Connect the
hose to the appliance by pushing the hose
fitting into the inlet connector, then tightening
the knurled nut until hand tight and firm.
4. Check that the control valves for the burners
are turned OFF (clockwise for off).
5. Connect the hose to the cylinder and use a
spanner to tighten firmly.
6. Ensure the plastic feet are in position to
maintain clearance between the appliance and
the support surface and for good airflow and
correct operation.
This appliance should only be operated on a
hard, flat, level surface.
a. The appliance area must be kept clear and
free of combustible materials, gasoline and
other flammable vapours and liquids.
b. Gas orifices and burner must be kept
clear of dirt and cobwebs. Flow of
combustion and ventilation air through the
perforated portions of the appliance must
not be obstructed.
c. Any cleaning agent used on the appliance
should be of a non-combustible and
non-corrosive nature.
7. Proper clearance from combustible materials
must be maintained at all times. The minimum
clearances are as follows:
Minimum Clearance from Combustibles:
Rear Side Top600mm 600mm 600mm
Combustible materials are considered to be
wood, compressed paper, plant fibres, plastic,
plexiglas or other materials capable of being
ignited and burned.
Such materials shall be considered combustible
even though flame proofed, fire-retardant
treated or plastered. Additional clearance may
be required for glass, painted surfaces and other
materials which may be damaged by radiant or
convection heat.
LIGHTING & BURNER ADJUSTMENT
1. Open the cylinder control valve about one full
turn ensuring that all the control knobs on
the stove are turned OFF at this point.
DO NOT ATTEMPT TO LIGHT THE STOVE!
2. Useasolutionofsoapywater(dishwashing
liquid and water is fine). Brush it on or use a
spray bottle. Ensure the connections have a
good coating.
3. Iftheconnectionisleaking,bubbleswillstart
to grow in the soapy solution. If this happens
shut off the gas supply at the cylinder.
4. Tightentheconnectionsusingaspannerthen
 repeatsteps1-2.Theconnectionisgastight
when no bubbles grow around the gas
connection.
5. Each burner can be operated independently
by turning the control valve on (rotating the
knob anti-clockwise about one turn) and
applying a lighted match to the burner. The
flame can be regulated by opening or closing
the valve.
6. Iftheburnerfailstoigniteafterseveral
attempts, turn the control knob to OFF and
wait a few minutes before attempting
re-ignition.
7. Turn the control knob anti-clockwise to
increase the flame, or clock-wise to decrease
the flame.
8. IMPORTANT:Whenturningthestoveoffat
completion of use, the gas supply should be
first turned off at the cylinder, and all gas in
the hose burnt away before closing the valves
on the stove. Leaving the gas in the hose can
cause jet (nipple) blockage.
Note: If re-ignition if necessary while the
stove is still hot, you must wait for a
minimum of 5 minutes before commencing to
re-ignite (this allows accumulated gas fumes
to clear).
SPARE PARTS
10001 Knob
01007-05001 Spindlewith“O”rings
05001 “O”ringonSpindle
01098 Hoseassembly
05009 “O”ringonhose(cylinderend)
05012 “O”ringonhose(stoveend)
01089 10,000BTUburnerassembly
l20 Injector0.20mm
REGULAR MAINTENANCE
Clean the body of your appliance using a cotton
cloth soaked in soapy hot water. Never use
abrasive or flammable cleaning products. Use a
soft brush to clean the burner.
STORAGE
When the appliance is not used it must be
stored in a suitable area to protect it from any
risk of deterioration. Keep it in a well ventilated
area and out of reach of children.
HANDY HINTS
a. The hose connections, cylinder valve outlet
connection and appliance inlet connection
should be kept clean. If grit or dirt is present
when the connections are made, the rubber
seals at each end of the hose may be
damaged.
b. To clear blocked jets wash in petrol. Do
not use wires or prickers. If washing is
unsuccessful, fit new jet.
WARNING
Be very careful when turning the burner
down.Visuallychecktoensuretheame
does not go out.
c. Check for gas leaks with SOAPY WATER.
DO NOT USE A FLAME.
d. Ensure that the area in which the appliance is
to be used is well ventilated and DO NOT use
as a space heater in tent, caravan, etc.
e. Ensure the appliance is completely
extinguished before disconnecting from the
cylinder.
f. DONOTplacetheappliancecloserthan60cm
from ceiling or flammable material.
g. Avoid moving the appliance during use as this
can cause large flames.
h. Allow the appliance to cool down after use
before touching the burners, trivet,
windshields or folding up for transportation.
GAS CONSUMPTION g/h MJ/h BTU Jet
Burners x 2 390g/h 19.6MJ/h 18,956BTU 0.20mm
GAS CONTROL
