Installation Manual
GPS PLOTTER/SOUNDER GP-1670F
GP-1870F
SAFETY INSTRUCTIONS ................................................................................................ i
1. MOUNTING .............................................................................................................. 1-1
1.1 Mounting of Display Unit ............................................................................................... 1-1
1.2 Replacement Kit (option) .............................................................................................. 1-2
2. INSTALLATION OF TRANSDUCERS ..................................................................... 2-1
2.1 How to Mount a Transducer through the Unit ............................................................... 2-1
2.2 Transom Mount Transducer .......................................................................................... 2-3
2.3 How to Mount a Transducer inside the Hull .................................................................. 2-4
3. WIRING .................................................................................................................... 3-1
3.1 Display Unit ................................................................................................................... 3-1
3.2 Transducer .................................................................................................................... 3-2
3.3 External Equipment ....................................................................................................... 3-2
PACKING LIST ........................................................................................................... A-1
OUTLINE DRAWINGS ................................................................................................ D-1
INTERCONNECTION DIAGRAMS ............................................................................. S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
www.furuno.com
i
SAFETY INSTRUCTIONS
The user and installer must read the appropriate safety instructions before attempting to install or
operate the equipment.
WARNING
WARNING
Do not open the equipment.
The equipment uses high voltage that
can cause electrical shock. Refer any
repair work to a qualified technician.
If water leaks into the equipment or
something is dropped into the equip-
ment, immediately turn off the power
at the switchboard.
Fire or electrical shock can result.
If the equipment is giving off smoke
or fire, immediately turn off the power
at the switchboard.
Fire or electrical shock can result.
If you feel the equipment is acting
abnormally or giving off strange
noises, immediately turn off the
power at the switchboard and contact
a FURUNO service technician.
Mandatory Action
Prohibitive Action
WARNING
CAUTION
Warning, Caution
The operator must read the safety instructions before attempting to operate the equipment.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.
WARNING
WARNING
Do not disassemble or modify the
equipment.
Fire, electrical shock or serious injury
can result.
Make sure no rain or water splash
leaks into the equipment.
Fire or electrical shock can result if
water leaks into the equipment.
Do not place liquid-filled containers
on or near the equipment.
Fire or electrical shock can result if a
liquid spills into the equipment.
Do not operate the equipment with
wet hands.
Electrical shock can result.
Use the proper fuse.
Use of the wrong fuse can cause fire or
electrical shock.
1-1
1. MOUNTING
1.1 Mounting of Display Unit
Mounting considerations
The display unit can be installed on a tabletop or flush mounted in a console.
Select a suitable mounting location considering the following:
• Keep the display unit out of direct sunlight.
• The temperature and humidity should be moderate and stable.
• Locate the unit away from exhaust pipes and vents.
• The mounting location should be well ventilated.
• Mount the unit where shock and vibration are minimal.
• Keep the unit away electromagnetic field generating equipment such as motor, gen-
erator.
• For maintenance and checking purposes, leave sufficient space at the sides and
rear of the unit and leave slack in cables.
• A magnetic compass will be affected if placed too close to the display unit. Observe
the compass safe distances shown in the Safety Instructions to prevent disturbance
to the magnetic compass:
Mounting procedure
Follow the procedure below to mount the display unit on a tabletop or in a console.
Refer to the outline drawing at the back of this manual.
• Tabletop, mounting
1. Fix the hanger by four tapping screws φ ×4.8 22.
2. Screw knob bolts in display unit, set it to hanger, and tighten knob bolts.
3. Attach hard cover to protect LCD.
• Flush mounting
Follow the procedure below to mount the display unit in a console. Refer to the out-
line drawing at the back of this manual.
1. The thickness of the cutout should be 5 to 20 mm.
2. Prepare a cutout in the mounting location whose dimensions are shown in the
outline drawing at the back of this manual.
3. Screw in four threaded rods into the display unit.
4. Peel the paper from flush mount gasket and set the gasket to the display unit.
5. Set the display unit to the cutout and fasten it with the washers and nuts.
