INTRODUCTION

The Catalyst™ 48 Universal Remote

Control,developed by Universal

Electronics,Inc. for Funai,is the complete

solution for all of your remote control

requirements. It is designed to operate

from four to eight devices with the

emphasis on features and functions of

your dedicated component(s).

The Catalyst 48 requires two (2) fresh

AA alkaline batteries (not included)

and some easy programming to control

your devices. For best results, please

read and perform all instructions listed

here. Also, keep these instructions for

future reference.

FEATURES AND FUNCTIONS

Use the Key Charts to learn how the

Catalyst 48 functions.

Key Charts

The LED (red light)

blinks to show that

the remote control is

working and is

sending signals.

Use SETUP for all

programming

sequences.

Press PWR once to

turn on or off the

selected home enter-

tainment component.

Press AUX,CBL VCR, ,

TV,SAT,CD,AMP, or

TNR once to select a

home entertainment

component to control.

Use the keypad (0 ~ 9)

to directly select

channels (for example,

09 or 31).

Press MUTE once to

turn sound off

or on.

Press ENTER once after

entering channel

numbers on some TV

models.

Use VOL + (or VOL-)

to raise (or lower) the

sound volume.

Use (or CH + CH -) to

select the next higher

(or lower) channel.

Press LAST once to

recall the last channel

and to page back one

screen in the

main menu.

Press SLEEP to activate

your TV’s sleep timer.

Or if none is available,

press SLEEP to activate

the Catalyst 48’s sleep

timer for automatic

shut-off of your TV.

Each key press (up to

four) add 15 minutes

to the sleep timer.

Press INPUT once to

switch the input of the

chosen component.

Use GUIDE to display

the program guide.

Use EXIT to exit out of

the selected compo-

nent’s menu or guide.

Use the cursor keys to

move the cursor in

the program guide and

menu screens.

Use SELECT to choose

options from your

selected component’s

menu or guide.

Use INFO to display

current channel and

program information.

Press MENU to access

the menu of your

chosen component.

Use the transport

keys to control

your VCR, or CD or

DVD player.

Use these keys for

specific features on

your dedicated

components.

INSTALLING BATTERIES

1. On the back of the Catalyst 48,push

the tab and lift off the battery cover.

2. Obtain two (2) fully-charged AA

alkaline batteries. Match the + and –

marks on the batteries to the + and

– marks in the battery case,then

insert the new batteries.

3. Press the battery cover back into

place. The tab should click when the

cover is locked.

4. Test the unit by pressing PWR and

any mode key (e.g., AUX,CBL VCR, ,

etc.).If the batteries are inserted cor-

rectly,the LED will blink once.

NOTE:When batteries need replacement,

the Catalyst 48 will blink twice with every

key press.Simply replace them and the

remote control will be restored to its full

functionality, including favorite settings.

PROGRAMMING

COMPONENT CONTROL

The Catalyst 48 can control up to eight

different components. Perform the fol-

lowing instructions for each component

you want controlled:

NOTE: For TV/VCR Combo control,see the

next section.

1. Turn on a component (e.g.,VCR)

and,if applicable, insert media,

(e.g.,cassette or disc).

NOTE: Please read steps 2-4 completely

before proceeding.We recommend

highlighting or writing down the codes

and device you wish to program before

moving onto step 2.

2. On the Catalyst 48,press a component

key once (i.e., AUX VCR,CBL, ,TV,SAT,

CD,AMP,or TNR). Press and hold

SETUP until the LED blinks twice,

then release SETUP.

3. Use the Manufacturer’s Codes (on the

back side) to locate the the type of

component and brand name and

then enter the first four-digit code

for your component. If performed

correctly,the LED will blink twice.

NOTE: If the LED did not blink twice,then

repeat steps 2 through 3 and try entering

the same code again.

4. Aim the Catalyst 48 at the component

and press PWR once.It should turn

off. If it does not respond, repeat steps

2-3, trying each code for your brand

until you find one that works. If it still

does not work,try searching for the

code (see Searching For Your Code).

NOTE: If the device does not have a PWR

key, press PLAY.

5. Repeat steps 1 through 4 for each

component you want the Catalyst 48

to control.

PROGRAMMING

TV/VCR COMBO CONTROL

Perform the following instructions to

control a TV/VCR Combo:

1. Turn on the TV/VCR Combo and

insert a video cassette.

NOTE: Please read steps 2-4 completely

before proceeding.We recommend

highlighting or writing down the code

for the brand you wish to program

before moving onto step 2.

2. On the Catalyst 48,press VCR. Press

and hold SETUP until the LED blinks

twice,then release SETUP.

3. Use the Setup Codes For TV/VCR

Combos (on the back side) to locate

the brand name and then enter the

first four-digit code for your compo-

nent.If performed correctly, the LED

will blink twice.

NOTE: If the LED did not blink twice,then

repeat steps 2 through 3 and try entering

the same code again.

4. Aim the Catalyst 48 at the component

and press PWR once.It should turn

off. If it does not respond, repeat steps

2-3, trying each code for your brand

until you find one that works. If it still

does not work,try searching for the

code (see Searching For Your Code).

NOTE: If the device does not have a PWR

key, press PLAY.

5. If you’ve located a setup code that

works,but it has a separate TV code,

you’ll also need to program it into the

Catalyst 48 to access volume control

as follows:

a. Press TV once.The LED will

blink twice.

b. Enter the TV code for your

TV/VCR Combo. If correct, the

LED will blink twice.

If there is no separate TV code listed,

you will need to perform the follow-

ing steps to access volume control:

a. Press and hold SETUP until the

LED blinks twice,then release

SETUP.

b. Enter 9 - 9 - 3 . The LED will

blink twice.

c. Press VCR once. The LED will

blink twice.

SEARCHING FOR YOUR CODE

If your device does not respond to the

Catalyst 48 after trying all codes listed

for your brand,or if your brand is not

listed at all, try searching for your code.

For example,to search for a code for

your TV:

1. On the Catalyst 48, press TV once.

2. Press and hold SETUP until the LED

blinks twice,then release SETUP.

3. Enter 9 1- 9 - . The LED will

blink twice.

4. Aim the remote control at the the

TV and slowly alternate between

pressing PWR and TV. Stop when the

TV turns off.

NOTE: In the search mode,the

Catalyst 48 will send IR codes from its

library to the selected device,starting

with the most popular code first.

5. Press SETUP once to lock in the code.

6. To search for the codes of your other

components,repeat steps 1 through

5,but substitute the appropriate key

(i.e., AUX, , , , ,CBL VCR SAT CD AMP,or

TNR) for the (Auxiliary, VCR,Cable,

Satellite,CD, Amplifier,or Tuner)

component you are searching for.

CHECKING THE CODES

If you have set up the Catalyst 48 using

the Searching For Your Code procedure,

you may need to find out which four-

digit code is operating your equipment:

For example,to find out which code is

operating your TV:

1. On the Catalyst 48, press TV once.

2. Press and hold SETUP until the LED

blinks twice,then release SETUP.

3. Enter 9 0- 9 - . The LED will

blink twice.

4. To view the code for the first digit,

press 1 once. Wait 3 seconds, count

the LED blinks (e.g.,3 blinks = 3)

and write down the number.

NOTE: If a code digit is “0”, the LED

will not blink.

5. Repeat step 4 three more times for

remaining digits. Use 2for the sec-

ond digit,3for the third digit,and 4

for the fourth digit.

6. To check for the codes of your other

components, repeat steps 1 through

5,but substitute the appropriate key

(i.e., AUX, , ,CBL VCR SAT,CD,AMP,or

TNR) component you are checking.

As before, write down each four-

digit code.

RE-ASSIGNING DEVICE KEYS

The Catalyst 48 can be set up to control a

second TV or VCR, or any combination of

eight home entertainment components.

For example,to have the Catalyst 48 con-

trol a TV, a Cable Converter, and two

VCRs, you will need to re-assign the

unused AUX key to operate the second

VCR as follows:

1. On the Catalyst 48,press and hold

SETUP until the LED blinks twice,

then release SETUP.

2. Enter 9 2- 9 - . The LED will

blink twice.

3. Press VCR AUX once, then press once.

4. The AUX key is now ready to be pro-

grammed for your second VCR. See

Programming Component Control.

To re-assign other device keys,repeat

steps 1 through 4 by substituting the key

sequence from the below chart for the

most popular components:

To Re-Assign Key

Sequence Perform

TV as 2nd VCR key: SETUP - 9 9 -

- - - 2 VCR TV

TV as 2nd CBL key: SETUP - 9 9 -

- - - 2 CBL TV

TV as 2nd AUX key: SETUP - 9 9 -

- - - 2 AUX TV

TV as 2nd TNR key: SETUP - 9 9 -

- - - 2 TNR TV

TV as 2nd AMP key: SETUP - 9 9 -

- - - 2 AMP TV

TV as 2nd CD key: SETUP - 9 9 -

- - - 2 CD TV

TV as 2nd SAT key: SETUP - 9 9 -

- - 2 SAT - TV

TV back to TV 9 :SETUP - - 9

- - - 2 TV TV

VCR as 2nd TV key: SETUP - 9 9 -

- - - 2 TV VCR

VCR as 2nd CBL key: SETUP - 9 9 -

- - - 2 CBL VCR

VCR as 2nd AUX key: SETUP - 9 - 9

- - - 2 AUX VCR

VCR as 2nd TNR key: SETUP - 9 9 -

- - - 2 TNR VCR

VCR as 2nd AMP key: SETUP - 9 9 -

- - - 2 AMP VCR

VCR as 2nd CD key: SETUP - 9 9 -

- - - 2 CD VCR

VCR as 2nd SAT key: SETUP - 9 9 -

- - 2 SAT - VCR

VCR back to VCR SETUP : - 9 - 9

- - - 2 VCR VCR

AUX as 2nd TV key: SETUP - 9 9 -

- - - 2 TV AUX

AUX as 2nd VCR key: SETUP - 9 9 -

- - - 2 VCR AUX

AUX as 2nd CBL key: SETUP - 9 9 -

- - - 2 CBL AUX

AUX as 2nd TNR key: SETUP - 9 9 -

- - - 2 TNR AUX

AUX as 2nd AMP key: SETUP - 9 9 -

- - - 2 AMP AUX

AUX as 2nd CD key: SETUP - 9 9 -

- - - 2 CD AUX

AUX as 2nd SAT key: SETUP - 9 9 -

- - 2 SAT - AUX

AUX back to AUX 9 :SETUP - - 9

- - - 2 AUX AUX

When a re-assignment is done,the LED

will blink twice to confirm your choice.

At that time, you will need to program the

Catalyst 48 to control the new component

(see Programming Component Control).

CHANGING VOLUME LOCK

The Catalyst 48 is set to control volume

of a component through your TV while

in the TV,VCR, Cable, or Satellite mode.

However,in an Audio mode (i.e., TNR,

AMP,or CD), you have separate control of

your audio component’s volume.

If your TV is not remote controllable,or

if you want volume to be controlled by a

different component,you can change the

Volume Lock setting to control a volume

through a non-associated mode (e.g.,

through the cable in the TV mode).

To change Volume Lock to the

another mode:

1. On the Catalyst 48, press and hold

SETUP until the LED blinks twice,

then release SETUP.

2. Enter 9 3- 9 - and then press any

mode key once (except TV). The LED

will blink twice.

3. Now,whenever you press VOL +,

VOL –,or MUTE, volume will be con-

trolled by your mode choice.

To change Volume Lock back to the

TV mode:

1. On the Catalyst 48, press and hold

SETUP until the LED blinks twice,

then release SETUP.

2. Enter 9 3- 9 - and then press TV.

The LED will blink twice.

3. Now, whenever you press VOL +,

VOL –,or MUTE on the Catalyst 48,

volume will be controlled by your TV.

TROUBLESHOOTING

PROBLEM: LED does not blink when

you press a key.

SOLUTION: Replace the batteries with

two (2) new AA alkaline

batteries.

PROBLEM: LED blinks when you

press a key, but home

entertainment component

does not respond.

SOLUTION: Make sure the Catalyst 48

is aimed at your home

entertainment component

and is not farther than

15 feet away.

PROBLEM: Catalyst 48 does not con-

trol home entertainment

components or commands

are not working properly.

SOLUTION: Try all listed codes for the

component brands being

set up. Make sure they

can be operated with an

infrared remote control.

PROBLEM: TV/VCR combo does not

respond properly.

SOLUTION: Use the VCR codes for

your brand. Some combo

units may require both a

TV code and a VCR code

for full operation.

PROBLEM: No volume on a 2nd TV.

SOLUTION: Follow instructions in

Changing Volume Lock.

PROBLEM: CH+ ,CH

, and LAST do

not work for your RCA TV.

SOLUTION: Due to RCA design (1983-

1987),only the original

remote control will oper-

ate these functions.

PROBLEM: Changing channels does

not work properly.

SOLUTION: If original remote control

required pressing ENTER

to change channels, press

ENTER on the Catalyst 48

after entering the

channel number.

PROBLEM: Tried “Search Method”

and still could not find a

working code.

SOLUTION: Try the “Search Method”

again after clearing out

the device key as follows:

Press and hold SETUP

until the red light blinks

twice,then release.Next

enter 9 9 2- - .Then press

and release the device key

to be cleared twice.

Continued on back...

CATALYST ™48

UNIVERSAL REMOTE CONTROL

USER GUIDE

TROUBLESHOOTING (CONT’D)

PROBLEM: Remote control does not

turn on Sony or Sharp

TV/VCR Combo.

SOLUTION: For power on,these prod-

ucts require programming

TV codes. For Sony, use

TV code 0000 and VCR

code 0032. For Sharp, use

TV code 0093 and VCR

code 0048.

MANUFACTURER’S CODES

Setup Codes for Audio Amplifiers:

GE 0078

Harman/Kardon 0892

JVC 0331

Marantz 0892

Optimus 0395

Philips 0892

Polk Audio 0892

Realistic 0395

Sony 0689

Soundesign 0078

Victor 0331

Wards 0078

Yamaha 0354

Setup Codes for Audio Receivers

or Tuners :

ADC 0531

Aiwa 0121, 1405,1089

Capetronic 0531

Carver 1089, 1189

Denon 1160,1104

Harman/Kardon 0110

JBL 0110

JVC 0074

Kenwood 1027,0186, 1313,1569, 1570

MCS 0039

Magnavox 1089,0531, 1189

Marantz 1189,1089, 0039

Onkyo 0135

Optimus 1023,0186, 0531,0670

Panasonic 0039, 1518

Philips 1089, 1189,1269

Pioneer 0150,0531, 0630,1023

Proscan 1254

Quasar 0039

RCA 1254,0531, 1023

Sansui 1089

Sharp 0186

Sony 1158,1058, 1258

Soundesign 0670

Sunfire 1313

Technics 0039,1308, 1518,1309

Thorens 1189

Victor 0074

Yamaha 0176,0186, 1176

Setup Codes for Cable Coverters:

ABC 0003,0017

Americast 0899

Bell South 0899

General Instrument

0276,0476, 0810

GoldStar 0144

Hamlin 0009, 0273

Jerrold 0003,0276, 0476,0810

Memorex 0000

Motorola 1106

Pace 0237

Panasonic 0107, 0000

Paragon 0000

Philips 0305, 0317

Pioneer 0144,0533, 0877

Pulsar 0000

Quasar 0000

Regal 0273,0279

Runco 0000

Samsung 0144

Scientific Atlanta 0017, 0477,0877

Starcom 0003

Toshiba 0000

Zenith 0000, 0525,0899

Setup Codes for CD Players:

Aiwa 0157

Burmester 0420

Cal.Audio Labs 0029

Carver 0157, 0179

DKK 0000

Denon 0003, 0873

Emerson 0305

Fisher 0179

Garrard 0420

Genexxa 0032,0305

Harman/Kardon 0157,0173

Hitachi 0032

JVC 0072

Kenwood 0028,0190, 0826,0037, 0626,0681

Krell 0157

LXI 0305

Linn 0157

MCS 0029

MTC 0420

Magnavox 0157,0305

Marantz 0157,0626, 0029

Mission 0157

NSM 0157

Onkyo 0101, 0868

Optimus 0032,0468, 0420,0179, 0305,1063,

0000,0037, 0145

Panasonic 0029

Parasound 0420

Philips 0157, 0626

Pioneer 0032,0468, 0305,1062, 1063

Polk Audio 0157

Proton 0157

QED 0157

Quasar 0029

RCA 0053,0032, 1062,0468, 0305,0179

Realistic 0179,0420

Rotel 0157, 0420

SAE 0157

Sansui 0157,0305

Sanyo 0179

Scott 0305

Sears 0305

Sharp 0037,0861

Sherwood 1067

Sonic Frontiers 0157

Sony 0000,0490

Soundesign 0145

Tascam 0420

Teac 0420

Technics 0029

Victor 0072

Wards 0053,0157

Yamaha 0036,0888

Setup Codes for DVD Players:

Apex 0672

Denon 0490

Emerson 0675, 0821

Fisher 0670

FUNAI 0675, 1334

GE 0522

Gradiente 0651

Hitachi 0573,0664

Hiteker 0672

JVC 0623,0558

Kenwood 0682,0534

Konka 0719,0711, 0720,0721

Magnavox 0675,0821, 0503,0675

Marantz 0539

Mitsubishi 0521

Onkyo 0503

Optimus 0571

Oritron 0651

Panasonic 0490, 0677,0632

Philips 0539, 0503

Pioneer 0571,0525, 0632

Proscan 0522

RCA 0522,0571

Samsung 0573

Sharp 0630

Sony 0533

Superscan 0821

Sylvania 0675, 0821

Symphonic 0675

Technics 0490

Theta Digital 0571

Toshiba 0503

Yamaha 0490,0545

Zenith 0591, 0503

Setup Codes for DVD Player/

VCR Combos:

Sylvania 0593

Symphonic 0675

Setup Codes for Home Automation:

GE 0240

One For All 0167

Radio Shack 0240

Security System 0167

Universal X10 0167

X10 0167

Setup Codes for Satellite Receivers:

AlphaStar 0772

Chaparral 0216

Echostar 0775, 1005

Expressvu 0775

GE 0566

General Instrument

0869

HTS 0775

Hitachi 0819

Hughes Net.Sys. 0749,1142, 1749

JVC 0775

Magnavox 0722,0724

Memorex 0724

Mitsubishi 0749

Next Level 0869

Panasonic 0247, 0701

Philips 1076, 1142,0722,0724, 0749

Proscan 0392

RCA 0566,0392, 0143,0855

Radio Shack 0869

Samsung 1109

Sony 0639

Star Choice 0869

Toshiba 0749,0790

Uniden 0724, 0722

Zenith 0856

Setup Codes for TVs:

AOC 0019, 0030

Admiral 0093, 0463

Aiko 0092

Aiwa 0701

Akai 0030

Alaron 0179

America Action 0180

Anam 0180

Audiovox 0092, 0180,0451, 0623

Baysonic 0180

Belcor 0019

Bell & Howell 0016,0154

Bradford 0180

Brockwood 0019

Broksonic 0236, 0463

CXC 0180

Candle 0030, 0056

Carnivale 0030

Carver 0054

Celebrity 0000

Cineral 0451,0092

Citizen 0056, 0030,0060,0092

Concerto 0056

Contec 0180

Craig 0180

Crosley 0054

Crown 0180

Curtis Mathes 0060,0030,0016, 0047,0051, 0054,

0056,0093, 0145,0154, 0166,0451,

1147,1347

Daewoo 0092, 0623,0019, 0624,0451

Daytron 0019

Denon 0145

Dumont 0017, 0019

Durabrand 0171

Electroband 0000

Emerson 0171, 0236,0180, 0178,0179, 0463,

0624,0623, 0019,0154

Envision 0030

Fisher 0154

Fujitsu 0179,0683

FUNAI 0171, 1271,0180, 0179

Futuretech 0180

GE 0047,1347, 0051,0178, 0451,1147,

0093

Gibralter 0017,0019, 0030

GoldStar 0178,0019, 0030,0056

Gradiente 0056,0053

Grunpy 0179, 0180

Hallmark 0178

Harley Davidson 0179

Harman/Kardon 0054

Harvard 0180

Hitachi 0145,0056, 0016

Infinity 0054

Inteq 0017

JBL 0054

JCB 0000

JVC 0053

KEC 0180

KTV 0180, 0030

Kenwood 0030,0019

Konka 0707,0632, 0628,0638, 0703

LG 0056

LXI 0154,0047, 0054,0156, 0178

Logik 0016

Luxman 0056

MGA 0150,0019, 0030,0178

MTC 0060, 0030,0019, 0056

Magnavox 0054,0030, 0179,1254

Majestic 0016

Marantz 0054,0030

Matsushita 0250

Megatron 0145, 0178

Memorex 0179, 0463,0178, 0016,0056, 0150,

0154,0250

Midland 0017, 0047, 0051

Mitsubishi 0150,0178, 0019,0093

Motorola 0093

Multitech 0180

NAD 0156, 0166,0178

NEC 0030, 0019,0056

NTC 0092

Nikko 0178,0030,0092

Onwa 0180

Optimus 0250,0166, 0154

Optonica 0093

Orion 0463, 0179,0236

Panasonic 0051, 0250

Penney 0047,1347, 0060,0030, 0178,0051,

0019,0056, 0156

Philco 0145, 0019,0030, 0054,0463

Philips 0054

Pilot 0019,0030

Pioneer 0166,0679

Portland 0019,0092

Princeton 0717

Prism 0051

Proscan 0047

Proton 0178

Pulsar 0017, 0019

Quasar 0051,0250

RCA 0047,1347, 1147,0679, 1247,0019,

0051,0090, 0093,1047, 1447

RadioShack 0180,0030, 0178,0154, 0019,0047,

0056

Realistic 0180,0154, 0030,0178, 0019,0056

Runco 0017, 0030

SSS 0019, 0180

Sampo 0030

Samsung 0060,0019, 0178,0030, 0056

Sansei 0451

Sansui 0463

Sanyo 0154

Scimitsu 0019

Scotch 0178

Scott 0236, 0019,0178, 0179,0180

Sears 0171,0154, 0056,0156, 0047,0054,

0178,0179

Semivox 0180

Semp 0156

Sharp 0093,0688

Shogun 0019

Signature 0016

Sony 0000

Soundesign 0178,0179, 0180

Squareview 0171

Starlite 0180

Supreme 0000

Sylvania 0171, 0054,0030

Symphonic 0171,0180

TMK 0056, 0178

TNCi 0017

Tandy 0093

Technics 0051,0250

Technol Ace 0179

Techwood 0051, 0056

Teknika 0016,0054,0179, 0180,0019, 0092,

0056,0060, 0150

Telefunken 0056

Toshiba 0156,0060, 0154,1256

Vector Research 0030

Victor 0053

Vidikron 0054

Vidtech 0019, 0178

Wards 0054,0178, 0016,0019, 0030,0056,

0179

White Westinghouse

0624,0623, 0463

Yamaha 0019,0030

Zenith 0017, 0624,0016, 0092,0463

Setup Codes for TV/DVD Player

Combos:

Sylvania 0171, 0675

Setup Codes for TV/VCR Combos:

American High 0035 (for TV use 0051)

Brocksonic 0002, 0294,

Colt 0072

Curtis Mathis 0035 (for TV use 0051)

Daewoo 0278

Emerson 0002, 0294,0479

FUNAI 0000

GE 0035 (for TV use 0051),

0060 (for TV use 0047),

0048 (for TV use 0093),0240

Hitachi 0035 (for TV use 0051),0000

HQ 0000

Lloyd’s 0000

MGA 0240

Magnasonic 0593

Magnavox 0593,0081 (for TV use 0054),

0035 (for TV use 0051),0000

Magnin 0240

Memorex 0037,0162 (for TV use 0250)

Mitsubishi 0048 (for TV use 0093)

Optimus 0593

Orion 0002, 0294,0479

Panasonic 0035 (for TV use 0051),

0162 (for TV use 0250)

Penney 0035 (for TV use 0051),0240,

0162 (for TV use 0250)

Quasar 0035 (for TV use 0051),

0162 (for TV use 0250)

RCA 0060 (for TV use 0047),

0035 (for TV use 0051),

0048 (for TV use 0093)

Sansui 0000, 0479

Sanyo 0240

Sears 0000,0037

Sharp 0048 (for TV use 0093)

Sony 0032 (for TV use 0000)

Symphonic 0593,0000

Zenith 0000

Setup Codes for TV/VCR/DVD Player

Combos:

Emerson 0821, 1334

FUNAI 1334

Magnavox 0821

Superscan 0821

Sylvania 0821, 1334

Setup Codes for VCRs:

Admiral 0048, 0209

Adventura 0000

Aiko 0278

Aiwa 0000, 0037

America Action 0278

American High 0035

Asha 0240

Audiovox 0037

Beaumark 0240

Bell & Howell 0104

Broksonic 0121, 0184,0002,0209, 0479

CCE 0072,0278

Calix 0037

Canon 0035

Carver 0081

Cineral 0278

Citizen 0278, 0037

Colt 0072

Craig 0037, 0072,0047,0240

Curtis Mathes 0035,0060,0162

Cybernex 0240

Daewoo 0278, 0045

Denon 0042

Dynatech 0000

Electrohome 0037

Electrophonic 0037

Emerex 0032

Emerson 1593, 0184,0002, 0209,0278, 0121,

0479,0000, 0037,0043

Fisher 0047, 0104

Fuji 0033, 0035

FUNAI 1593, 0000

GE 0035,0060, 0048,0240

Garrard 0000

Go Video 0432

GoldStar 0037,0038

Gradiente 0000

HI-Q 0047

Harley Davidson 0000

Harman/Kardon 0038,0081

Harwood 0072

Hitachi 0042,0000

Hughes Net.Sys. 0042

JVC 0067

KEC 0037, 0278

KLH 0072

Kenwood 0067,0038

Kodak 0035, 0037

LXI 0037

Lloyd’s 0000

Logik 0072

MEI 0035

MGA 0043,0240

MGN Technology 0240

MTC 0000, 0240

Magnasonic 0593,0278

Magnavox 0593,0035, 0081,0563, 0000,0039,

0149

Magnin 0240

Marantz 0081,0035

Marta 0037

Matsushita 0035,0162

Memorex 0104,0047,0479, 0000,0037, 0048,

0035,0240, 1037,0039, 0162,0209,

1162,1262

Minolta 0042

Mitsubishi 0043,0048, 0067

Motorola 0035,0048

Multitech 0000,0072

NEC 0038, 0067,0104

Nikko 0037

Noblex 0240

Olympus 0035

Optimus 0593,0162, 1062,1162, 0048,1262,

0037,1048, 0104,0432

Orion 0479, 0002,0184, 0209

Panasonic 0035, 0162,1162, 1262,1362,0616,

1062

Penney 0035,0240, 0037,0042, 0038

Pentax 0042

Philco 0035, 0209,0479

Philips 0081, 0035,0618,1081, 1181

Pilot 0037

Pioneer 0067

Polk Audio 0081

Profitronic 0240

Proscan 0060

Protec 0072

Pulsar 0039

Quasar 0035,0162, 1162

RCA 0060,0149, 0042,0035, 0048,0240

RadioShack 0000, 1037

Radix 0037

Randex 0037

Realistic 0000,0104, 0047,0048, 0037,0035

ReplayTV 0614, 0616

Runco 0039

STS 0042

Samsung 0045,0240

Sanky 0039, 0048

Sansui 0479,0000, 0067,0209

Sanyo 0047, 0104,0240

Scott 0184, 0121,0043, 0045

Sears 0037,0042, 0000,0035, 0047,0104

Semp 0045

Sharp 0048

Shintom 0072

Shogun 0240

Singer 0072

Sony 0033,0032, 0000,0035, 0636,1032

Sylvania 0593, 1593,0035, 0081,0000, 0043

Symphonic 1593,0593, 0000

TMK 0240

Teac 0000

Technics 0035,0162

Teknika 0000,0035, 0037

Thomas 0000

Tivo 0618,0636

Toshiba 0045, 0043

Totevision 0037,0240

Unitech 0240

Vector 0045

Vector Research 0038

Video Concepts 0045

Videosonic 0240

Wards 0035,0060, 0000,0047, 0240,0042,

0048,0072, 0081,0149

White Westinghouse

0072,0278, 0209

XR-1000 0072, 0000,0035

Yamaha 0038

Zenith 0039, 0000,0033, 0209,0479

Setup Codes for Video Accessories:

Panasonic 1120

Pioneer 1010

Sensory Science 1126

Sharp 1010

Sylvania 1563

ADDITIONAL INFORMATION

The Catalyst 48 does not have any user-serviceable

parts.Opening the case, except for the battery cover,

may cause permanent damage to your Catalyst 48.

publication may be reproduced,transmitted,tran-

scribed, stored in any retrieval system,or translated

to any language, in any form or by any means,elec-

tronic,mechanical, magnetic, optical, manual, or

otherwise, without the prior written permission of

Universal Electronics,Inc.

M4800A 09/04

Produktspezifikationen

Marke:	Funai
Kategorie:	Fernbedienungen
Modell:	Catalyst 48

Brauchst du Hilfe?

Wenn Sie Hilfe mit Funai Catalyst 48 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Fernbedienungen Funai

Funai Catalyst 48 Bedienungsanleitung

16 Oktober 2024

Bedienungsanleitung Fernbedienungen

Neueste Bedienungsanleitung für -Kategorien-

Ruwido Easytip 2 Bedienungsanleitung

15 Oktober 2024

Technics RAK-SSA163XH Bedienungsanleitung

14 Oktober 2024

Technics SA-GX350 Bedienungsanleitung

13 Oktober 2024

Meliconi Personal 1 Bedienungsanleitung

12 Oktober 2024

One For All URC 3550 Super Easy Bedienungsanleitung

11 Oktober 2024

Philips SRP2008B Bedienungsanleitung

9 Oktober 2024

Logitech Harmony 350 Bedienungsanleitung

9 Oktober 2024

T'nB RCOLORSI Bedienungsanleitung

8 Oktober 2024

Marantz RC5200 Bedienungsanleitung

13 Juli 2024

Marantz RC3200 Bedienungsanleitung

11 Juli 2024
