Seite 1/17

R32

REFRIGERANT

This Air Conditioner contains and

operates with ref rigerant R32.

THIS PRODUCT MUST ON BE INSTALLED OR SERVICEDLY

BY QUALIFIED PERSONNEL.

Refer to Commonwealth, State, Territory and local legislation,

regulations, codes, installation & operation manuals, before

the installation, maintenance or service of this product.

Before using this product, read these instructions

thoroughly. Also, keep this manual for future

reference, together with the installation manuals for

the indoor and outdoor units.

PART No. 9378532113

MODEL:

□ AGTG09KVCA

□ AGTG12KVCA

□ AGTG14KVCA

* Please check the model name.

(Refer to the rating label.)

OPERATION MANUAL

AIR CONDITIONER

Floor type

En-1

1. SAFETY PRECAUTIONS

To prevent personal injury or property damage, read this section

carefully before you use this product, and be sure to comply

with the following safety precautions.

Incorrect operation due to failure to follow the instructions may

cause harm or damage, the seriousness of which is classied

as follows:

WARNING

This mark warns of death or serious injury.

CAUTION

This mark warns of injury or damage to property.

This mark denotes an action that is PROHIBITED.

This mark denotes an action that is COMPULSORY.

Explanation of symbols displayed on the indoor unit or outdoor unit.

WARNING

This symbol shows that this product uses a low

burning velocity material. If the refrigerant is leaked

and exposed to an external ignition source, there is a

risk of re.

CAUTION

This symbol shows that the operation manual should

be read carefully.

CAUTION

This symbol shows that a service personnel should

be handling this equipment with reference to the

installation manual.

CAUTION

This symbol shows that information is available such

as the operation manual or installation manual.

WARNING

• When installing this product to an unventilated area,

pay attention to prevent re and explosion caused

by the stagnated gas in case of refrigerant leakage.

(For products which contain more than 1.842 kg

refrigerant.)

• This product contains no user-serviceable parts.

Always consult authorized service personnel for

repairing, installation, and relocation of this product.

Improper installation or handling will cause leakage,

electric shock, or re.

• In the event of a malfunction such as burning smell,

immediately stop operation of the air conditioner, and

disconnect all the power supply by turning o󰀨 the

electrical breaker or disconnecting the power plug.

Then consult authorized service personnel.

• Take care not to damage the power supply cable.

If it is damaged, it should be replaced only by

authorized service personnel in order to avoid a

hazard.

• If a refrigerant leakage is suspected, all naked

ames shall be removed or extinguished, and consult

authorized service personnel.

• In the event of a thunder storm or any prior sign

of a lightning strike, turn o󰀨 the air conditioner via

the remote controller, and refrain from touching the

product or the power source to prevent any electrical

hazards.

• This product shall be stored in a room without

continuously operating ignition sources (for example:

open ames, an operating gas appliance or an

operating electric heater).

• This product shall be stored in a well-ventilated area.

• Be aware that refrigerants may not contain an odour.

• This product shall be stored so as to prevent

mechanical damage from occurring.

• Disposing of the product shall be done properly, in

compliance with national or regional regulations.

• During transportation or relocation of the indoor unit,

pipes shall be covered with the wall hook bracket for

protection.

Do not move this product by holding the indoor unit pipes.

(The stress applied to the pipe joints may cause the

ammable gas to leak during operation).

• This product is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of this product by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with this

product.

• Dispose of the packing materials safely. Tear and

dispose of the plastic packing bags so that children

cannot play with them. There is danger of su󰀨ocation

if children play with the original plastic bags.

Contents

1. SAFETY PRECAUTIONS 1 ..........................................

2. PREPARATION ......................................................... 2

3. NAME OF PARTS 3 .....................................................

3.1. Indoor unit 3 ........................................................

3.2. Remote controller 3 .............................................

3.3. Battery loading 5 .................................................

4. BASIC OPERATIONS 5 ...............................................

5. AIRFLOW SETTINGS 5 ...............................................

5.1. Fan speed setting 5 .............................................

5.2. Airow direction setting .................................... 6

6. TIMER OPERATIONS 6 ...............................................

6.1. Weekly timer 7 .....................................................

6.2. On timer or O󰀨 timer ......................................... 7

6.3. Program timer 7 ...................................................

6.4. Sleep timer 7 ......................................................

7. ENERGY SAVING OPERATION 8 ...............................

7.1. Economy operation 8 ..........................................

7.2. Fan control for energy saving 8 ...........................

8. OTHER OPERATIONS 8 .............................................

8.1. Powerful operation 8 ...........................................

8.2. Outdoor Unit Low Noise operation 8 ...................

8.3. 10 °C Heat operation 8 ........................................

9. SETTINGS ON INSTALLATION 9 ................................

9.1. Remote controller custom code setting 9 ............

10. CLEANING AND CARE 9 .............................................

11. GENERAL INFORMATION ..................................... 11

12. OPTIONAL PARTS ................................................. 11

12.1. Wired remote controller 11 ..................................

13. TROUBLESHOOTING ............................................ 11

[Original Instructions]

En-2

WARNING

• Do not install the unit in area lled with mineral oil

such as a factory or area containing a large amount of

splashed oil or steam such as a kitchen.

• Do not start or stop the operation of this product by

inserting or pulling out the power plug, or by turning

on or o󰀨 the circuit breaker.

• Do not use ammable gases near this product.

• Do not expose yourself directly to the cooling airow

for many hours.

• Do not insert your ngers or any other objects into

outlet port or inlet port.

• Do not operate with wet hands.

• Do not use means to accelerate the defrosting

process or to clean this product, other than those

instructed in this manual.

• Do not pierce or burn.

• Do not splash water over the product, to avoid safety

hazards.

CAUTION

• Provide occasional ventilation during use.

• Always operate this product with air lters installed.

• Ensure that any electronic equipment is at least 1 m

(40 in) away from this product.

• After a long period of use, ensure to get the mounting

of the indoor unit checked to prevent this product from

falling down.

• The airow direction and the room temperature should

be carefully considered when you use this product in a

room with infants, children, elderly or sick persons.

• Keep the surroundings of the outdoor unit clean and

tidy, and do not place items around it. Any objects

blocking or entering from the outlet ports may cause

product malfunction.

• Do not direct the airow at replaces or heating apparatus.

• Do not block or cover the intake grille and the outlet port.

• Do not apply any heavy pressure to radiator ns.

• Do not climb on or sit, place objects on, or hang

objects from this product.

• Do not place any other electrical products or

household belongings under this product. Dripping

condensation from this product might get them wet,

and may cause damage or malfunction of your

property.

• Do not use this product for preservation of food, plants,

animals, precision equipment, art work, or other objects.

This may cause quality deterioration of those items.

• Do not expose animals or plants to the direct airow.

• Do not drink the drainage from the air conditioner.

• Do not pull the power supply cable.

• Do not touch the aluminum ns of heat exchanger

built-in this product to avoid personal injury when you

maintain the unit.

• Do not stand on unstable steps when operating or

cleaning this product. It may overturn and can cause

injury.

• Do not use ammable substances (such as pesticides

and hair sprays). Doing so may cause an electric

shock, re or wrong detection by the refrigerant

sensor.

• This product is equipped with a refrigerant leakage

sensor. Do not install the product at a location lled

with smoke, gases or chemicals.

CAUTION

• Do not turn o󰀨 the breaker unless the product is under

repair, inspection, or cleaning. Otherwise, the sensor

is unable to detect refrigerant leak.

This product contains uorinated greenhouse gases.

2. PREPARATION

WARNING

• Take care to prevent infants and young children from

accidentally swallowing the batteries.

CAUTION

• If leaking battery uid comes in contact with your skin,

eyes, or mouth, immediately rinse with plenty of clean

water, and consult your physician.

• Exhausted batteries must be removed immediately,

and be disposed according to the local laws and

regulations of your region.

• If the remote controller is to be stored unused for a long

period, the batteries should be removed.

• Batteries are to be inserted with the corrected polarity.

• Be aware of the risk of terminals of the battery-operated

appliance or battery being short-circuited by metal

objects.

• Do not attempt to recharge dry batteries.

• Do not use dry batteries that has been recharged.

• The supply terminals must not be short-circuited.

• Do not expose the remote controller or battery to

excessive temperatures.

Indoor unit accessories

Please check that the following accessories are included.

Remote controller Remote controller

holder

Tapping screws

Batteries Air cleaning lters

Remote controller holder installation

321

Insert

Screws Slide up

Produktspezifikationen

Marke:	Fujitsu
Kategorie:	Klimaanlage
Modell:	SET-AGTG09KVCA

Brauchst du Hilfe?

Wenn Sie Hilfe mit Fujitsu SET-AGTG09KVCA benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Klimaanlage Fujitsu

Fujitsu AOYG07KGCA Bedienungsanleitung

9 Oktober 2024

Fujitsu AOHG45LBTB Bedienungsanleitung

9 Oktober 2024

Fujitsu Lifestyle ASTG30KMTC Bedienungsanleitung

9 Oktober 2024

Fujitsu ASYG18LFCA Bedienungsanleitung

8 Oktober 2024

Fujitsu Airstage AUXK054GLEH Bedienungsanleitung

7 Oktober 2024

Fujitsu ASYG14LECA Bedienungsanleitung

4 Oktober 2024

Fujitsu Airstage AUXA30GALH Bedienungsanleitung

3 Oktober 2024

Fujitsu Airstage AGHE007GCEH Bedienungsanleitung

2 Oktober 2024

Fujitsu Airstage AJY045LELAH Bedienungsanleitung

29 September 2024

Fujitsu ASTG22KMTC Bedienungsanleitung

26 September 2024

Bedienungsanleitung Klimaanlage

Neueste Bedienungsanleitung für -Kategorien-

MundoClima MUCSR-H3 Bedienungsanleitung

16 Oktober 2024

Duux DXMA10 North Bedienungsanleitung

16 Oktober 2024

Duux DXAC04 Bedienungsanleitung

16 Oktober 2024

LG HS-H076QPA0 Bedienungsanleitung

16 Oktober 2024

Klarstein Vita Pure 2G Bedienungsanleitung

16 Oktober 2024

Einhell BMK 2400E Bedienungsanleitung

15 Oktober 2024

Qlima P 126 Bedienungsanleitung

15 Oktober 2024

Amana PTC093K35AXXX Bedienungsanleitung

15 Oktober 2024

Amana AMAP121AB-2 Bedienungsanleitung

15 Oktober 2024

Amana PTC173J35AXXX Bedienungsanleitung

15 Oktober 2024
