Seite 1/17

R32

REFRIGERANT

This Air Conditioner contains and

operates with ref rigerant R32.

THIS PRODUCT MUST ON BE INSTALLED OR SERVICEDLY

BY QUALIFIED PERSONNEL.

Refer to Commonwealth, State, Territory and local legislation,

regulations, codes, installation & operation manuals, before

the installation, maintenance or service of this product.

AIR CONDITIONER

MODEL:

Wall Mounted Type

OPERATING MANUAL

Before using this product, read these instructions

thoroughly. Also, keep this manual for future

reference, together with the installation manuals for

the indoor and outdoor units.

PART No. 9387602043

* Please write down the model name.

(Refer to the rating label.)

En-1

1. SAFETY PRECAUTIONS

To prevent personal injury or property damage, read this section

carefully before you use this product, and be sure to comply

with the following safety precautions.

Incorrect operation due to failure to follow the instructions may

cause harm or damage, the seriousness of which is classied

as follows:

WARNING

This mark warns of death or serious injury.

CAUTION

This mark warns of injury or damage to property.

This mark denotes an action that is PROHIBITED.

This mark denotes an action that is COMPULSORY.

Explanation of symbols displayed on the indoor unit or outdoor unit.

WARNING

This symbol shows that this product uses a

ammable refrigerant. If the refrigerant is leaked and

exposed to an external ignition source, there is a risk

of re.

CAUTION

This symbol shows that the operating manual should

be read carefully.

CAUTION

This symbol shows that a service personnel should

be handling this equipment with reference to the

installation manual.

CAUTION

This symbol shows that information is available such

as the operating manual or installation manual.

WARNING

• This product contains no user-serviceable parts.

Always consult authorized service personnel for

repairing, installation, and relocation of this product.

Improper installation or handling will cause leakage,

electric shock, or re.

• In the event of a malfunction such as burning smell,

immediately stop operation of the air conditioner, and

disconnect all the power supply by turning off the

electrical breaker or disconnecting the power plug.

Then consult authorized service personnel.

• Take care not to damage the power supply cable.

If it is damaged, it should be replaced only by

authorized service personnel in order to avoid a

hazard.

• In the event of refrigerant leakage, be sure to keep

away from re or any ammables, and consult

authorized service personnel.

• In the event of a thunder storm or any prior sign

of a lightning strike, turn off the air conditioner via

the remote controller, and refrain from touching the

product or the power source to prevent any electrical

hazards.

• This product shall be stored in a room without

continuously operating ignition sources (for example:

open ames, an operating gas appliance or an

operating electric heater).

• This product shall be stored in a well-ventilated area.

• Be aware that refrigerants may not contain an odour.

• This product shall be stored so as to prevent

mechanical damage from occurring.

• Disposing of the product shall be done properly, in

compliance with national or regional regulations.

• During transportation or relocation of the indoor unit,

pipes shall be covered with the wall hook bracket for

protection.

Do not move this product by holding the indoor unit pipes.

(The stress applied to the pipe joints may cause the

ammable gas to leak during operation).

• This product is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of this product by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with this

product.

• Dispose of the packing materials safely. Tear and

dispose of the plastic packing bags so that children

cannot play with them. There is danger of suffocation

if children play with the original plastic bags.

• Do not install the unit in area lled with mineral oil

such as a factory or area containing a large amount of

splashed oil or steam such as a kitchen.

Contents

1. SAFETY PRECAUTIONS 1 ..........................................

2. PREPARATION ......................................................... 2

3. NAME OF PARTS 3 .....................................................

3.1. Indoor unit 3 ........................................................

3.2. Remote controller 3 .............................................

4. BASIC OPERATIONS 5 ...............................................

5. AIRFLOW SETTINGS 5 ...............................................

5.1. Fan speed setting 5 .............................................

5.2. Airow direction setting .................................... 5

6. TIMER OPERATIONS 5 ...............................................

6.1. Weekly timer 6 .....................................................

6.2. On timer or Off timer 6 .........................................

6.3. Program timer 6 ...................................................

6.4. Sleep timer 6 ......................................................

7. ENERGY SAVING OPERATIONS 7 ............................

7.1. Economy operation 7 ..........................................

7.2. Human sensor for energy saving 7 .....................

7.3. Fan control for energy saving 7 ...........................

7.4. Demand Response 7 ...........................................

8. OTHER OPERATIONS 8 .............................................

8.1. Powerful operation 8 ...........................................

8.2. Outdoor Unit Low Noise operation 8 ...................

8.3. 10 °C Heat operation 8 ........................................

9. SETTINGS ON INSTALLATION 8 ................................

9.1. Remote controller custom code setting 8 ............

10. CLEANING AND CARE 9 .............................................

11. GENERAL INFORMATION ..................................... 10

12. OPTIONAL PARTS ................................................. 11

12.1. Wired remote controller 11 ..................................

12.2. Wireless LAN control 11 ......................................

13. TROUBLESHOOTING ............................................ 13

En-2

WARNING

• Do not start or stop the operation of this product by

inserting or pulling out the power plug, or by turning

on or off the circuit breaker.

• Do not use ammable gases near this product.

• Do not expose yourself directly to the cooling airow

for many hours.

• Do not insert your ngers or any other objects into

outlet port or inlet port.

• Do not operate with wet hands.

• Do not use means to accelerate the defrosting

process or to clean this product, other than those

recommended by the manufacturer.

• Do not pierce or burn.

CAUTION

• Provide occasional ventilation during use.

• Always operate this product with air lters installed.

• Ensure that any electronic equipment is at least 1 m

(40 in) away from this product.

• Disconnect all the power supply when not using this

product for extended periods.

• After a long period of use, ensure to get the mounting

of the indoor unit checked to prevent this product from

falling down.

• The airow direction and the room temperature should

be carefully considered when you use this product in a

room with infants, children, elderly or sick persons.

• Keep the surroundings of the outdoor unit clean and

tidy, and do not place items around it. Any objects

blocking or entering from the outlet ports may cause

product malfunction.

• Do not direct the airow at replaces or heating apparatus.

• Do not block or cover the intake grille and the outlet port.

• Do not apply any heavy pressure to radiator ns.

• Do not climb on, place objects on, or hang objects

from this product.

• Do not place any other electrical products or

household belongings under this product. Dripping

condensation from this product might get them wet,

and may cause damage or malfunction of your

property.

• Do not expose this product directly to water.

• Do not use this product for preservation of food, plants,

animals, precision equipment, art work, or other objects.

This may cause quality deterioration of those items.

• Do not expose animals or plants to the direct airow.

• Do not drink the drainage from the air conditioner.

• Do not pull the power supply cable.

• Do not touch the aluminum ns of heat exchanger

built-in this product to avoid personal injury when you

maintain the unit.

• Do not stand on unstable steps when operating or

cleaning this product. It may overturn and can cause

injury.

This product contains uorinated greenhouse gases.

CAUTION

• If leaking battery uid comes in contact with your skin,

eyes, or mouth, immediately rinse with plenty of clean

water, and consult your physician.

• Exhausted batteries must be removed immediately,

and be disposed according to the local laws and

regulations of your region.

• Do not attempt to recharge dry batteries.

• Do not use dry batteries that has been recharged.

Indoor unit accessories

Please check that the following accessories are included.

Remote controller Remote controller

holder

Tapping screws

Batteries Filter holdersAir cleaning lters

Remote controller holder installation

321

Battery loading and remote controller preparation

(R03/LR03/AAA x 2)

1~3. Put batteries as shown in the gure above.

4. Press to start clock setting.

5. Press

( )

to set day of the week (Monday to

Sunday).

* By pressing , the time indicator can be changed

from a 24-hour to a 12-hour clock.

6. Press to continue.

7. Press

( )

to set the clock.

Press the buttons to change the clock by a minute.

Press down the buttons to change the clock by 10 minutes.

8. Press to complete the setting.

Be close to the indoor unit. If you press the button from a

distance, settings may not be properly sent.

NOTES:

• Use specied type of batteries only.

• Do not mix different types or new and used batteries together.

• Batteries can be used about 1 year in ordinary use.

• If the remote control range noticeably shortens, replace the

batteries, and press as shown in page 4.

InsertScrews Slide up

2. PREPARATION

WARNING

• Take care to prevent infants and young children from

accidentally swallowing the batteries.

Produktspezifikationen

Marke:	Fujitsu
Kategorie:	Klimaanlage
Modell:	ASTG22KMTC

Brauchst du Hilfe?

Wenn Sie Hilfe mit Fujitsu ASTG22KMTC benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Klimaanlage Fujitsu

Fujitsu AOYG07KGCA Bedienungsanleitung

9 Oktober 2024

Fujitsu AOHG45LBTB Bedienungsanleitung

9 Oktober 2024

Fujitsu Lifestyle ASTG30KMTC Bedienungsanleitung

9 Oktober 2024

Fujitsu ASYG18LFCA Bedienungsanleitung

8 Oktober 2024

Fujitsu Airstage AUXK054GLEH Bedienungsanleitung

7 Oktober 2024

Fujitsu ASYG14LECA Bedienungsanleitung

4 Oktober 2024

Fujitsu Airstage AUXA30GALH Bedienungsanleitung

3 Oktober 2024

Fujitsu Airstage AGHE007GCEH Bedienungsanleitung

2 Oktober 2024

Fujitsu Airstage AJY045LELAH Bedienungsanleitung

29 September 2024

Fujitsu ASTG22KMTC Bedienungsanleitung

26 September 2024

Bedienungsanleitung Klimaanlage

Neueste Bedienungsanleitung für -Kategorien-

MundoClima MUCSR-H3 Bedienungsanleitung

16 Oktober 2024

Duux DXMA10 North Bedienungsanleitung

16 Oktober 2024

Duux DXAC04 Bedienungsanleitung

16 Oktober 2024

LG HS-H076QPA0 Bedienungsanleitung

16 Oktober 2024

Klarstein Vita Pure 2G Bedienungsanleitung

16 Oktober 2024

Einhell BMK 2400E Bedienungsanleitung

15 Oktober 2024

Qlima P 126 Bedienungsanleitung

15 Oktober 2024

Amana PTC093K35AXXX Bedienungsanleitung

15 Oktober 2024

Amana AMAP121AB-2 Bedienungsanleitung

15 Oktober 2024

Amana PTC173J35AXXX Bedienungsanleitung

15 Oktober 2024
