Seite 1/36

DETAILED RIGID

FLAPS INSTALLED STRONG DURABLE EPO

STABLE

SMOOTH FLYING PERFORMANCE

FMSMODEL.COM

Manuel d’utilisation

Instruction Manual

Bedienungsanleitung

操作手册

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.

Failure to operate the product correctly can result in damage to the product,personal property and cause serious injury.

This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and failure to do so

could result in injury or damage to the product or other property. This product is not intended for use by children without direct

adult supervision.

This manual contains instructions for safety operation and maintenance. It is essential to read and follow all the instructions and

warnings in the manual prior to assembly, setup or use, in order to operate and avoid damage or serious injury.

WARNING

As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and others or

result in damage to the product or the property of others. This model is controlled by a radio signal subject to interference from

many sources outside your control. This interference can cause momentary loss of control so it is advisable to always keep a

safe distance in all directions around your model, as this margin will help avoid collisions or injury.

Age Recommendation: Not for children under 14 years. This is not a toy.

·Never operate your model with low transmitter batteries.

·Always operate your model in an open area away from cars, traffic or people.

·Avoid operating your model in the street where injury or damage can occur.

·Never operate the model in populated areas for any reason.

·Carefully follow the directions and warnings for this and any optional support equipment you use (chargers,rechargeable

battery packs, etc.)

·Keep all chemicals, small parts and anything electrical out of the reach of children.

·Moisture causes damage to electronics. Avoid water exposure to all equipment not specifically designed and protected for this

purpose.

·Never lick or any place of any your model in your mouth as it could cause serious injury or even death.

Lithium Polymer (Li-Po) Battery Warning

CAUTION: Always follow the manufacturer’s instructions for safe use and disposal of batteries. Fire, property

damage, or serious injury can result from the mishandling of Li-Po batteries.

By handling, charging or using a Li-Po Battery you assume all risks associated with lithium batteries.

If at any time the batteries begin to swell or balloon, discontinue use immediately!

Always store the batteries at room temperature in a dry area to extend the life of the battery. Always transport

or temporarily store the battery in a temperature range of 40-120F. Do not store the battery or model in a car or in direct sunlight.

If stored in a hot car, the battery can be damaged or even catch fire.

Never use a Ni-Mh Charger to charge Li-Po Batteries. Failure to charge the battery with a Li-Po compatible charger

may cause fire resulting in personal injury and property damage.

Never discharge Li-Po Cells below 3V.

Never leave charging batteries unattended.

Never charge damaged batteries.

Charging the Flight Battery Warning

Use a battery charger that is designed to safely charge the Li-Po Battery. Read the charger instructions care

fully before use. When charging the battery, make certain the battery is on a heat resistant surface. It is also highly

recommended to place the Li-Po Battery inside a fire resistant charging bag readily available at hobby shops or

online.

p w

Before assembly, please inspect the contents of the kit. The

photo below details the contents of the kit with labels. If any

parts are missing or defective, please identify the name or

part number (refer to the spare parts list near the end of the

manual) then contact your local shop or email us: support

Kit contents

A: Fuselage

B: Canopy hatch

C: Main wing set

D: Vertical stabilizer

E: zHori ontal abili st zer

F: Spar set

Introduction

Kit contents

Model assembly

Battery installation

Receiver diagram

Get your model ready to fly

Clevis installation

Control horn and servo arm settings

Center of gravity(CG)

Before flying the model

Flying course

Troubleshooting

Spare parts list content

Table of contents

·····························································

·····

·························································3

·······················································4

············································· ········ 5

·········································

··

········ 6

··································

·····

············································

··

·········· 8

·························· 8

··············································· 8

··············································9

···························································9

······················································10

············································10

Introduction

Thank you for purchasing the FMS 3000mm FOX. Featuring an

impressive wingspan of 3000mm, the FOX is one of the largest

wingspan production foam aircraft in the world. Utilizing FMS’

decades long experience in designing and producing model

aircraft, the FOX has an ultra-efficient airfoil along with a 70A

ESC power system- providing more than ample power for

high-powered aerobatic maneuvers.

Constructed with FMS’ new snap-together design, the FOX can

be easily transported and assembled at the field with no tools

required.

Powering the Fox is a Predator 4258, 460KV motor linked to a

70A ESC and a 15*7.5 foldable propeller; when paired with a

6S battery- this power system gives the 3000mm FOX

near-unlimited vertical performance- a rare sight for glider

aircraft. Meanwhile, the surfaces are controlled by 23g

high-torque servos, ensuring precise action and power for

extreme maneuvers.

Positive and negative loops, stall turns, point rolls and inverted

flight are just some of the aerobatics that the 3000mm Fox

could perform, the rest is up to the pilot!

Wingspan: 3000mm(118.11in)

Overall Length: 1873mm(73.73in)

Flying Weight: ~4700g

Motor Size: 4258-KV460

Wing Load: 64.5g/dm²(0.14oz/in²)

Wing Area: 74.4dm²(1153.2sq.in)

ESC: 70A

Servo: 23g Servo x 6

Recommended Battery: 22.2V 5000mAh 35C

Specifications

@fmsmodel.com.

Features:

1.Large Wingspan

2.Powerful 4258 Motor, Predator 70A ESC

3.High torque 23G metal servos

4.Snap-together construction (glue-less and no screws

necessary)

5.Fast assembly time(10-15 minutes)

6.A 10 second quick-release wing, easily portable airframe

7.6S 5000mAh battery allows for around 30 minute flight time

8.Functional Flaps

9.Foldable propeller
