i3000s/i2000 Flex
AC Current Probe
Instructions
Introduction
The i3000s 24 Flex, i3000s 36 Flex, and i2000 Flex AC Current Probes
(the Probe) are used with oscilloscopes, digital multimeters, recorders
or data loggers. The i3000s probes can be used to measure AC current
up to 3000 A. The i2000 can be used to measure AC current up to
2000 A. The flexible measuring head allows current measurements on
conductors that are hard to reach or inaccessible using typical clamp-
on current probes.
The Probes provide a low-voltage (3 V ac for i3000s models, and 2 V ac
for i2000) output that is proportional to the current being measured.
The Probes provide full-scale direct readings for 30 A, 300 A, and
3000 A when using the i3000s models, and 20 A, 200 A, and 2000 A
when using the i2000.
Safety Information
A Warning identifies hazardous conditions and procedures that are
dangerous to the user. A Caution identifies conditions and procedures
that can cause damage to the Product or the equipment under test.
XW Warning
To prevent possible electrical shock, fire, or personal injury:
Read all safety information before you use the Product.
Carefully read all instructions.
Do not alter the Product and use only as specified, or the
protection supplied by the Product can be compromised.
Do not use the Product if it operates incorrectly.
Do not use the Product if it is altered or damaged.
PN 2560447 (English)
March 2006 Rev. 3, 02/22
©2021-2022 Fluke Corporation. All rights reserved. Specifications are
subject to change without notice. All Product names are trademarks of their
respective companies.
2
Have an approved technician repair the Product.
If the Probes are used in a manner not specified in these
operating instructions, protection provided by the Probes
may be impaired.
Use the Probes only if qualified.
Use caution during installation and use of the Probe; high
voltages and currents may be present in circuit under test.
Protect the probe against water and humidity.
Wear protective clothing and gloves as required.
Do not install this product on live conductors. Always de-
energize the circuit under test before installing the flexible
measuring head.
Always inspect the electronics unit, connecting cable, and
flexible measuring head for damage before using the
Probe.
Do not use the Probe if damaged.
Always connect Probe to display device before installing
the flexible measuring head.
Never change batteries while measurement head is
installed on conductor.
Use only the provided original or specified accessories.
Comply with local and national safety codes. Use personal
protective equipment (approved rubber gloves, face
protection, and flame-resistant clothes) to prevent shock
and arc blast injury where hazardous live conductors are
exposed.
CAT III equipment is designed to protect against the
transients in the equipment in fixed equipment
installations, such as distribution panels, feeders and short
branch circuits, and the lighting systems in large buildings.
3
Symbols
The table below lists the symbols that can be used on the Product or in
this document.
Specifications
Electrical Characteristics
Symbol Description
~
This product complies with the WEEE Directive marking
requirements. The affixed label indicates that you must
not discard this electrical/electronic product in
domestic household waste. Do not dispose of this
product as unsorted municipal waste.
WWARNING. RISK OF DANGER.
XWARNING. HAZARDOUS VOLTAGE. Risk of electric
shock.
»Consult user documentation.
O
Measurement Category III is applicable to test and
measuring circuits connected to the distribution part of
the building’s low-voltage MAINS installation.
TDouble Insulated.
-
Do not apply around or remove from uninsulated
hazardous live conductors without taking additional
protective measures.
PConforms to European Union directives.
Measuring ranges
i3000s (24 and 36 Flex) 30 A/300 A/3000 A ac, switch selectable
i2000 Flex 20 A/200 A/2000 A ac, switch selectable
Output sensitivity (AC
coupled) 100 mV/10 mV/1 mV per A
Accuracy (at 25 ºC) ±1 % of range (45 Hz to 65 Hz)
Frequency range
i3000s (24 and 36 Flex) 10 Hz to 50 kHz (-3 dB typical)
i2000 Flex 10 Hz to 20 kHz (-1 dB typical)
Phase error (45 Hz to 65 Hz), ±10° (at 20 kHz)
Linearity ±0.2 % of reading from 10 % to 100 % of
range
Position sensitivity
From 1 % up to 3 % of range with cable,
depending on distance from the center
(see figure below). Measurements closer
than 25 mm from the coupling are
typically greater than 3 % of range.
