Seite 1/29
TABLE OF CONTENTS
Weights and Capacities ............................................... 2
Rough-In Drawings ...................................................... 2
Fast Start Brewing ....................................................... 5
Brew Recipes ............................................................... 6
Settings ........................................................................ 7
Inputs 8...........................................................................
Service ......................................................................... 8
Error Codes .................................................................. 9
Hot Water Portions ..................................................... 10
Calibration .................................................................. 11
How to calibrate the flow rate ..................................... 11
Outputs ....................................................................... 12
Counters ..................................................................... 13
Brewer Setup .............................................................. 14
Installation Guide........................................................ 15
Operator Training ....................................................... 16
Parts diagrams ........................................................... 18
Wiring Diagrams ......................................................... 25
User’s Guide and Operator Instructions
CBS-2251, CBS 2253 Next Generation Brewing System- -2252 & CBS
FETCO Next Generation-NG® Commercial Beverage Equipment
- 5 - 52 CBS 22 1 CBS 22
(Dispensers not included Plastic brew baskets are standard, ) ( brewers avalible with optional stainless steel brew baskets )
CONTACT INFORMATION
FETCO® FOOD EQUIPMENT TECHNOLOGIES COMPANY
600 ROSE ROAD
LAKE ZURICH • IL • 60047 0429 • USA-
Product made in USA
INTERNET: www.fetco.com
PATENTS:https://www.fetco.com/pl,pages,patents,74.html
©2020 2023- FOOD EQUIPMENT TECHNOLOGIES COMPANY
PHONE: (800) 338- 2699 (US & CANADA)
- (847) 719 3000 (All Countries and International)
- FAX:(847) 719 3001
EMAIL:sales@fetco.com
orders@fetco.com (to order parts and equipment)
techsupport@fetco.com (all service queries)
P 3 195 February 202
COFFEE BREWER CBS-2250NG Series
fetco.com
Go to fetco.com for the latest versions of all information Page 2 P J 3195 anuary 202
Weights and Capacities
Model Height Depth Width
Water tank
capacity
Empty
Weight
Shipping
Weight
Shipping
Dimensions
CBS-2251
1½ gal
36 7/8 in
940 mm
12 3/4 in
320 mm
22 1/2 in
570 mm
6.5 gallon
24.4 L
53 lbs
24 kg
107 lbs
48.3kg
63 lbs
28.6 kg
38” x 18” x 24”
96.5 x 45.7 x 61 cm
CBS-2252
1½ gal
36 7/8 in
940 mm
21 7/8 in
550 mm
11.1 gallon
42.1 L
77 lbs
35.0 kg
97 lbs
44 kg
38” x 24” x 27”
96.5 x 61 x 68.6 cm
CBS-2 253
2 gal
39 in
99.1 mm
21 7/8 in
550 mm
11.1 gallon
42.1 L
82 lbs
37.2 kg
97 lbs
44 kg
40” x 24” x 27”
102 x 61 x 68.6 cm
CBS-2 -2 251 & CBS 252
Calibrated for
1½ gallons/ 6 liters
CBS-2 253
Calibrated for
2 gallons/ 8 liters
Filter Paper all models
15” X 5 ½ ”– standard
Or use FETCO # F001
Brewers ship with plastic brew baskets.
See page 25 for optional brew baskets
Rough In Drawings-
- 1 - - - - - CBS 225 Front CBS 2252 Front CBS 2251, CBS 2252, CBS 2153 Side CBS 2252 Front Back (ALL)
Specifications and Requirements
FETCO CBS-2250 Brewers have unique construction only available for these models.
Water Requirements:
Coffee Filter Size:
CBS-2250 20- - 75 psig, (138 517kPa) 1½ gpm/(5.7 lpm)
15” X 5 ½ ” standard FETCO # F001–
Optimal water hardness between 125 13 grain)-250 -TDS (6
Important! Please use a water filter for all beverage equipment
Temperature, as set by factory:
200°F (93°C) inside water tank (at sea level)
Water inlet fitting: . 3/8 inch male flare. Electrical: See electrical configuration chart Pg 3
Brew Volume: Full Batch - - - CBS 2250: 1 ½ gallon/ 6 liters CBS5. 2252 2: 2 gallons 7.5 liters
Brew Capacity
(approximate)
CBS- - 2251 7 10 brews per hour
CBS- -2252 7 22 brews per hour
Output is controlled by heater power and water temperature
Total Brew Cycle: Factory setting: minutes consisting of 4 min brew time and 6 . 2.0 . min drip delay
Individual menu brew- process parameters are user controllable for:
Basic user controls for brew volume, brew time, units of measure, recipe name
Advanced user controls for pulse count, prewet percent and prewet delay, drip delay, programmable energy saving
See pages 4-5 for how to adjust controls for temperature, brew volume, units and all other settings -
Go to fetco.com for the latest versions of all information Page 3 P J 3195 anuary 202
Electrical and Output Specifications Single 1½ Gallon 6 Liter Coffee Brewers -for CBS 2251Next Generation -
CBS- -2251 Domestic USA and Canada models Single Voltage. - With cUL/UL & NSF 4 Certification
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
SKU Number
Phase
Voltage
Heater
Configuration
Wires KW
Maximum Amp
Draw
Brew- Volume
Per Hour
E2251US 1B230 PA110- -
1
200 240-
2 X 3.0 kW
2+G
4.6 6.1-
22.4 25.8-
15.3 gal/58 liters
E2251US 1B230 MA110- -
1
200 240-
2 X 3.0 kW
2+G
4.6 6.1-
22.4 25.8-
15.3 gal/58 liters
CBS- -2251 Domestic and International models Single Voltage. With cUL/UL & NSF-4 Certification
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
E2251IN- - 1B140 PA110
1
200 240-
1 X 4.0 kW
2+G
4.1
14.2 17.1-
9.3 gal/35 liters
E2251IN- - 1B150 PA110
1
200 240-
1 X 5.0 kW
2+G
5.1
17.7 21.3-
12.7 gal/48 liters
E2251IN PA110 - -1B230
1
200 240-
2 X 3.0 kW
2+G
6.1
21.3 25.5-
15.3 gal/58 liters
CBS- ) -2251 NOM (Mexico In Spanish Single Voltage. With cUL/UL & NSF-4 Certification
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
E2251NM 1B230 PA110- -
1
200
2 X 3.0 kW
2+G
4.2
21.2
14.5 gal/54 liters
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS- 1 225 Export CE CE listed models Listed w - ith NSF 4 Certification. Internal EMI Filter Not cUL or UL
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
E2251CE 2B230- - PA110
2
2 X 2.3 kW
230/400
2L,N,PE
4.9
11.8
14.0 gal/53 liters
E2251CE 1B230 PA110- -
2
2 X 3.0 kW
230/400
2L,N,PE
5.6
12.4
15.3 gal/58 liters
Electrical and Output Specifications 6 Liter Coffee Brewers -for CBS 225 Dual2Next Generation -1½ Gallon
CBS- 2 S - . - 225 Domestic USA and Canada Field electable Voltage With cUL/UL & NSF 4 Certification
Electrical and Output Specifications
All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required.
SKU Number Phase
Voltage
Heater
Configuration
Wires KW
Maximum Amp
Draw
Brew- Volume
Per Hour
E2252US UB230 MA110- -
Field
Selectable 1 or 3 phase
Sold as 3 phase
1 - - - 200 240 2 X 3.0 kW 2+G 4.6 6.1 22.4 25.8 15.3 gal/58 liters
3
200 240-
3 X 3.0 kW
3+G
6.9 9.1-
19.5 22.5-
22.5 gal/85 liters
E2252US UB230 PA110- -
Field
Selectable 1 or 3 phase
Sold as 3 phase
1
200 240-
2 X 3.0 kW
2+G
4.6 6.1-
22.4 25.8-
15.3 gal/58 liters
3
200 240-
3 X 3.0 kW
3+G
6.9 9.1-
19.5 22.5-
22.5 gal/85 liters
E2252US UB250 PA110- -
Field Selectable 1 or 3 phase
Sold as 3 phase
1
200 240-
2 X 5.0 kW
2+G
7.6 10.1-
36.9 42.5-
25.3 gal/97 liters
3 - - - 200 240 3 X 5.0 kW 3+G 11.4 15.1 32.0 36.9 38.3 gal/145 liters
CBS- -2252 Domestic and International models Single Voltage. With cUL/UL & NSF- 4 Certification
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required.
E2252IN- - 1B230 PA110
1
200 240-
2 X 3.0 kW
2+G
4.6 6.1-
22.4 25.8-
15.3 gal/58 liters
E2252IN- - 1B250 PA110
1
200 240-
2 X 5.0 kW
2+G
7.6 10.1-
36.9 42.5-
25.3 gal/97 liters
E2252IN- - 3 3B340 PA110
220/380 or
240/415
3 X 4.0 kW 4+G 12.2 15.7 17.1 - 29.5 gal/112 liters
E2252IN- - 3 3B330 PA110
220/380 or
240/415
3 X 3.0 kW 4+G 9.1 11.8 12.9 - 22.5 gal/85 liters
E2252IN- - 3 3B350 PA110
220/380 or
240/415
3 X 5.0 kW 4+G 15.1 19.5 21.4 - 38.3 gal/145 liters
CBS- - .2252 NOM (Mexico In Spanish) Field Selectable Voltage With cUL/UL & NSF- 4 Certification
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
E2252 UB250 PA110NM- -
Field Selectable 1 or 3 phase
Sold as 3 phase
1
200 240-
2 X 5.0 kW
2+G
7.6 10.1-
36.9 42.5-
25.3 gal/97 liters
3 - - - 200 240 3 X 5.0 kW 3+G 11.4 15.1 32.0 36.9 38.3 gal/145 liters
E2252NM 1B250 PA110- -
1
200 240-
2 X 5.0 kW
2+G
7.6 10.1-
36.9 42.5-
25.3 gal/97 liters
NM in SKU suffix (above) denotes equipment with NOM certification, Spanish labeling for Mexico and Spanish language user guide
CBS- 2 225 Export CE CE listed models Listed w - ith NSF 4 Certification. Internal EMI Filter Not cUL or UL
Electrical and Output Specifications All brewers use terminal block electrical connection for 50Hz or 60Hz Professional installation is required
E2252CE 3B350 PM110- -
3
230/400
3 X 5.0 kW
3L,N,PE
14.1
20.4
38.3 gal/145 liters
E2252CE 3B350 PA110- -
3
230/400
3 X 5.0 kW
3L,N,PE
14.1
20.4
38.3 gal/145 liters
E2252CE 3B330 PA110- -
3
230/400
3 X 3.0 kW
3L,N,PE
8.6
12.4
22.5 gal/85 liters
