K10C...KIT
ANTIFREEZE HEATING CABLE KIT
WITH CONSTANT ANTIFREEZE POWER
■
Kit consisting of a heating cable
complete with a contact thermostat
and power cable with Schuko plug
■
Constant power delivered ~10 W/m
■
Avoid possible damage caused by
low temperatures on pipes, valves,
taps, water meters, water troughs,
vessels and small tanks
CODE Cable
length
Minimum
installation room
temperature
Maximum
room temperature
powered
Maximum
room temperature
not powered
K10C3KIT 3 m -5 °C 65 °C 65 °C
K10C6KIT 6 m -5 °C 65 °C 65 °C
K10C9KIT 9 m -5 °C 65 °C 65 °C
K10C14KIT 14 m -5 °C 65 °C 65 °C
HOMOLOGATION AND STANDARDS
■
Compliant with Directive 2014/35/EU;
■
Complying with Standard EN60335-1;
OPERATION
■
The cable is ready for use;
■
The cable is actuated when the contact
temperature drops below +5°C and automatically
goes off when the temperature exceeds +15°C;
■IT
consists of a resistance wound in a spiral
on two conductors and in contact with these at
junction points at constant intervals (the energy
to heat the resistance is drawn at the splicing
points).
K10C...KIT - HEATING CABLE WITH CONSTANT ANTIFREEZE POWER ANTIFREEZE KIT
GENERAL FEATURES
Cable composition Thermoplastic material with a mechanical protection and
earth braiding and an external protective sheath
Cable diameter 9 mm
Cable length K10C3KIT 3 m
K10C6KIT 6 m
K10C9KIT 9 m
K10C14KIT 14 m
Maximum room temperature powered 65 ° C
Minimum installation room temperature -5 °C
Thermostat temperature scale ON +5°C / OFF +15°C
Minimum storage room temperature -20 ÷ -25°C
Protection rating IPX7
Power supply 230V-50Hz
Constant power delivered ~10W/m
ELECTRICAL FEATURES
INSTALLATION
■
The cable is ready for use: it has a Schuko plug
to connect directly to the mains and a thermostat
(+5°C to +15°C);
■
Thanks to the electric socket and the thermostat,
installation is simple, safe and fast;
■
Secure the pipe with the relevant fixing tape: code
K50 for steel pipes or code K50AL for plastic pipes;
■
The cable must be as long as the piping;
■
In the case of large pipes, the spiral cable may
need to be wound so as to ensure adequate heat,
taking care not to overlap it at any point;
■
It is advisable to apply an insulating coating over
the heating cable for a correct installation. INSULATION THICKNESS
Pipe size 11/2 3/4 1 1/4 1 1/2
Nominal width
mm 15 20 25 32 40
Insulation thickness
mm 20 20 20 30 40
K10C...KIT - HEATING CABLE WITH CONSTANT ANTIFREEZE POWER ANTIFREEZE KIT
ACCESSORIES
K50
FIBERGLASS FIXING TAPE FOR METAL PIPES
■
It does not shrink and preserves its qualities over time;
■
Suitable for temperatures between -30 and + 150°C;
■
Roll length 55 m, width 19 mm.
K50AL
FIXING TAPE FOR PLASTIC PIPES
■
It reflects the heat as it is coated with an aluminium film;
■
Suitable for temperatures between -20 and + 130°C;
■
Roll length 50 m, width 50 mm.
KFAN
LABELS FOR THE PRESENCE OF A HEATING CABLE
■
Indicate the presence of the heating cable under the insulating coating;
■
To be applied on the coating at intervals of about 5 m; yellow.
