CARATTERISTICHE TECNICHE SECONDO EN 60730-1:
TECHNICAL FEATURES ACCORDING TO EN 60730-1:
-
-
-Microinterruttore in commutazione a scatto rapido
con contatti in AgCdO.
-SPDT microswitch, with silver contacts
-
-apre 1-2
-Rising temperature:
Opens1-2
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-Grado d’inquinamento 2
-Pollution degree 2
-Tensione impulsiva nominale 2.5kV
Portata contatti 15(6)A 250V~ 50Hz -Nominal impulse voltage 2.5kV
Contact rating 15(6)A 250V~ 50Hz -Dispositivo di comando previsto per essere fornito esclusivamente
ai costruttori dell'apparecchiatura
-Control device to be supplied to the product manufacturers only
-Categoria di resistenza al calore e al fuoco, categoria D
-Grado di protezione IP00
-Heatproof and fireproof category, D category
-Protection degree IP00 All’aumento della temperatura:
-Mezzo di connessione (conduttori esterni), terminali FASTON
6.3mm
-Wire connection (external wires), FASTON 6.3mm
-Conduttori speciali connessi ai terminali per conduttori interni:
conduttori idoneii alle temperature resistenti al calore CARATTERISTICHE TECNICHE SECONDO EN 60947-5-1:
-Special wires (joint to screw terminals for internal wires): wires TECHNICAL FEATURES ACCORDING TO EN 60947-5-1:
suitable to the temperature, heatproof wires
-Temperatura massima dei morsetti per conduttori interni 160°C
-Maximum temperature of the terminals for internal wires 160°C
Limiti di temperatura della testa -35T85°C
Maximum head temperature -35T85°C
Classe d’isolamento I
Insulation class I
Microdisconnessione tipo 2B
Micro/disconnection type 2B
PTI dei materiali usati per l’isolamento PTI 175V
Material PTI used for insulation PTI 175V
Metodo di montaggio, da incorporare
Mounting way, to be included
Temperatura di trasporto e immagazzinaggio -35T120°C
Storage and transport temperature -35T120°C
Periodo di sollecitazione elettrica delle parti isolanti, periodo lungo
Period of electrical stress of the insulating parts, long period
CARATTERISTICHE COSTRUTTIVE
GENERAL FEATURES
-Termostato di blocco per montaggio a retroquadro a sicurezza positiva, per caldaie
ed impianti di riscldamento, da collegare in serie ad un termostato di regolazione;
- Shoutdown thermostats rear panel mounting with positive safety limit, suitable for
boilers and heating installations, to be connected to a control thermostat;
- Se l’impianto raggiunge la temperatura limite, il termostato interrompe il circuito e
pre riattivarlo necessario intervenire sul riarmo manuale (dopo che la temperatura si
è abbassata di ~25°C);
- When the set temperature limit is reached, the thermostat will shutdown the eletrical
circuit, to restart it is necessary to operate the manual reset button (after a temperture
drop of 25°C);
-In caso di guasto o rottura dell’elemento sensibile, il termostato interrompe il circuito
e non è più possibile riattivare l’impianto (è necessario sostituire il termostato);
- In the case of failure or breakage of the sensing element, the thermostat will
shutdown the eletrical circuit and the insatllation cannot be restarted (thermostat
replacement is necessary);
- Funzionamento a dilatazione di liquido;
- Liquid expamsion sensing element;
-Elemento sensibile con membrane in acciaio inossidabile;
-Stainless steel membrane sensor.
-Bulbo e capillare in rame.
-Copper bulbe and capillary tube.
-Montaggio del corpo termostato a retroquadro
-Rear panel mounting;
-Basetta, coperchio e manopola in meteriale termoplastico antiurto e autoestinguente
V0 1.6mm
-Base, cover and knob made of shock-proof self-extinguishing thermoplastic V0.
LIMITATORE TERMICO TIPO C09A3M
VIA DELL’OSIO, 6 20090 CALEPPIO DI SETTALA MI
Tel. 02956821 fax 0295307006
E-mail: info@fantinicosmi.it http://www.fantinicosmi.it
Supporto tecnico: supportotecnico@fantinicosmi.it
5679436
TEMPERATURE LIMITER TYPE C09A3M
TIPO
TYPE
C09A3M 100 +0 -6 120 1
Intervento di blocco
Shutdown temperature
°C
Tolleranza d’intervento
Lockout tolerance
K
Temp.Max Bulbo
Max bulb temp.
°C
Tensione nominale d’isolamento
Nominal insulation tension
Corrente nominale di impiego Ie:
Continuous duty normal current:
Carico resistivo
Carico induttivo
Inductive load
Corrente continua
Direct current
220V- 250V~ 380V~
Corrente nominale di impiego Ie:
Operating nominal current Ie:
Ui 380~
Ith 15A
Resistive load
AC-12 - 15A 10A
AC-15 - 2,5A 1,5A
DC-13 0,2A - -
QUOTE D'INGOMBRO/DIMENSION
Lunghezza capillare
Capillary lenght
m
