Seite 1/1
TERMOSTATI A IMMERSIONE PER MONTAGGIO DIRETTO SERIE C03A3-C03B3
DIMENSIONS
VIA DELL’OSIO, 6 20090 CALEPPIO DI SETTALA MI
Tel. 02956821 fax 0295307006
E-mail: info@fantinicosmi.it http://www.fantinicosmi.it
Supporto tecnico: supportotecnico@fantinicosmi.it
8
37
Gc 1/2
85
110
15 10
40
8 70
21
5679440C
STEM THERMOSTATS TYPE C03A3-C03B3
QUOTE D'INGOMBRO
TIPO
TYPE
C03A3
C03B3
10÷90 ±3 6±1 150
40÷120 ±3 6±1 150
Scala
Range
°C
Precisione di taratura
Calibation accuracy
°C
Differenziale
Differential
K
Temp.Max Bulbo
Max bulb temp.
°C
-
CARATTERISTICHE TECNICHE SECONDO EN/UL/CSA 60730-1, -
EN/UL/CSA 60730-2-9: -
TECHNICAL FEATURES ACCORDING TO -
- -
-
-
-
-
-
-
-Microinterruttore in commutazione a scatto rapido -
-con contatti in AgCdO, dorati. -apre 1-2 chiude 1-4
-SPDT microswitch, with gold plated silver contacts -Rising temperature:
-
- Opens1-2, closes 1-4
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Tensione impulsiva nominale 2.5kV
Nominal impulse voltage 2.5kV
Azione tipo 1
EN/UL/CSA 60730-1,
Type 1 action
EN/UL/CSA 60730-2-9:
Portata contatti 15(6)A 250V~ 50Hz Dispositivo di comando previsto per essere fornito esclusivamente
ai costruttori dell'apparecchiatura
Contact rating 15(6)A 250V~ 50Hz Control device to be supplied to the product manufacturers only
15A carico resistivo, 6A FLA/36LRA 240Vac 50/60Hz Categoria di resistenza al calore e al fuoco, categoria D
15A resistive load, 6A FLA/36LRA 240Vac 50/60Hz Heatproof and fireproof category, D category
All’aumento della temperatura:
Grado di protezione IP40
Protection degree IP40
Mezzo di connessione (conduttori esterni), morsetti a vite
Wire connection (external wires), screw terminals
Conduttori speciali connessi ai terminali per conduttori interni:
conduttori idoneii alle temperature resistenti al calore
Special wires (joint to screw terminals for internal wires): wires
suitable to the temperature, heatproof wires CARATTERISTICHE TECNICHE SECONDO EN 60947-5-1:
Temperatura massima dei morsetti per conduttori interni 130°C TECHNICAL FEATURES ACCORDING TO EN 60947-5-1:
Maximum temperature of the terminals for internal wires 130°C
Limiti di temperatura della testa T85°C
Maximum head temperature T85°C
Classe d’isolamento I
Insulation class I
Microdisconnessione tipo 1B
Micro/disconnection type 1B
PTI dei materiali usati per l’isolamento PTI 175V
Material PTI used for insulation PTI 175V
Metodo di montaggio, da incorporare
Mounting way, to be included (incorporated control)
Temperatura di trasporto e immagazzinaggio -35T120°C
Storage and transport temperature -35T120°C
Periodo di sollecitazione elettrica delle parti isolanti, periodo lungo
Period of electrical stress of the insulating parts, long period
Grado d’inquinamento 2
Pollution degree 2
Tensione nominale d’isolamento
Nominal insulation tension
Corrente nominale di impiego Ie:
Continuous duty normal current:
Carico resistivo
Carico induttivo
Inductive load
Corrente continua
Direct current
220V- 250V~ 380V~
Corrente nominale di impiego Ie:
Operating nominal current Ie:
Ui 380~
Ith 15A
Resistive load
AC-12 - 15A 10A
AC-15 - 2,5A 1,5A
DC-13 0,2A - -
0497
