Seite 1/12
English 2
Svenska 4
Norsk 6
Suomi 8
Deutsch 10
Ver. 20130426
UniversalhÄllare Universalholder Yleispidike Universalhalterung· · ·
Universal Phone Holder
Art.no.
38-4250
38-4251
2
English
1
2
3
9
5
7
8
10
6
4
Universal Phone Holder
Art. no 38-4250, 38-4251
Please read the entire instruction manual before using the product and save it for
future reference. We reserve the right for any errors in text or images and any
necessary changes made to technical data. If you have any questions regarding
technical problems please contact Customer Services.
Exibel Universal Phone Holder
Extra-wide holder, adjustable approx. 40–110 mm. Swivel mount, perfect for using
a “smartphone” as a sat nav. Equipped with a ïŹ‚exible arm and a suction cup for
attaching to a windscreen. Compatible with most phones, MP3 players and sat navs.
Contents
‱ Flexible arm with suction cup
‱ Universal holder for mobile phones, sat navs, etc.
‱ Instruction manual
Description
1. Side clamps
2. Foldable feet
3. Clamp release button
4. Attachment for arm
5. Swivel attachment
6. Flexible arm
7. Locking lever
8. Cup release button
9. Pull tab
10. Suction cup
3
English
Assembly
1. Line the lug on the cradle’s arm attachment (4) up with the slot in the arm’s swivel
attachment (5) and push the two pieces together.
2. Clean the surface of the glass where the suction cup (10) is to be mounted and
remove the plastic ïŹlm from the base of the suction cup.
3. Lift the locking lever (7) and press the suction cup against the clean glass surface.
Press down the locking lever completely until the suction cup is attached to
the glass surface.
4. Bend the ïŹ‚exible arm to the desired position. Adjust the holder’s horizontal angle
by twisting the holder.
5. Push the clamp release button (3) to open the side clamps.
6. Place the mobile phone (max. width 110 mm) in the middle of the holder and
carefully close the side clamps until the mobile phone is securely fastened.
The feet can be opened out to support the bottom of the phone if desired.
7. To remove the phone: Hold the phone with one hand whilst pushing the clamp
release button (3).
8. Remove the arm from the surface of the glass by pushing in the cup release
button (8) and then pulling the tab (9) up until the suction cup comes free.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure how to proceed, contact your local authority.
Specifications
Length of arm 16 cm (38-4250)
27 cm (38-4251)
Max phone width 110 mm
Operating temp. -20–70 ÂșC
