Seite 1/19
info@evoheat.com.au
1300 859 933
www.evoheat.com.au
Evo270-1 Manual
Page 1
Contents
1. Introduction ............................................................................................................................................... 2
2. Dimensions ............................................................................................................................................... 2
3. Quick Start Guide ..................................................................................................................................... 3
4. Safety Instructions .................................................................................................................................... 4
5. Installation ................................................................................................................................................ 5
5.1 System Installation .............................................................................................................................. 5
5.2 Handing & Transportation ................................................................................................................... 5
5.3 Location of Installation 6........................................................................................................................
5.3.1 Indoor Installation ......................................................................................................................... 6
5.4 Airflow Clearances .............................................................................................................................. 6
5.5 Cable Connection................................................................................................................................ 6
5.6 Filling the Tank .................................................................................................................................... 6
5.7 Initial Start- Up ..................................................................................................................................... 6
6. Operation .................................................................................................................................................. 7
6.1 The Controller ..................................................................................................................................... 7
6.2 Operating Functions ............................................................................................................................ 8
6.2.1 Startup & Shutdown ...................................................................................................................... 8
6.2.2 Switching Modes 8..........................................................................................................................
6.2.3 Locking the Controller ................................................................................................................... 8
6.2.4 Setting & Checking the Target Temperature ................................................................................. 9
6.2.5 Hydroboost Setting ....................................................................................................................... 9
6.2.6 Force Defrost ................................................................................................................................ 9
6.2.7 Sanitech System ......................................................................................................................... 10
6.2.8 System Date & Time ................................................................................................................... 10
6.2.9 Setting & Cancelling Timers ........................................................................................................ 11
6.2.10 Vacation Mode .......................................................................................................................... 12
6.2.11 Fan/Ventilation Function ........................................................................................................... 12
7. Troubleshooting ...................................................................................................................................... 13
8. Appendix ................................................................................................................................................ 14
8.1 Wiring Diagram ................................................................................................................................. 14
8.2 Use of the P&T Valve ........................................................................................................................ 15
8.3 Using the Overheating Protector ....................................................................................................... 15
8.4 Draining the Water Tank ................................................................................................................... 15
9. Maintenance ........................................................................................................................................... 16
10. Warranty ............................................................................................................................................... 17
info@evoheat.com.au
1300 859 933
www.evoheat.com.au
Evo270-1 Manual
Page 2
1. Introduction
This manual contains information relating to the installation, troubleshooting, operation, and maintenance of this
EvoHeat unit. Instructions in this manual must always be followed. Failure to comply with these recommendations will
invalidate the warranty. Should you have any questions or require technical support, call the EvoHeat office on 1300
859 933 to speak to our team.
TECHNICAL DATA Evo2701
The EVO 270 1 is the next evolution in water heating- with
advanced energy efficiency technologies and built in-
smart features to ensure you’re provided with clean, safe,
and economical hot water all year round.
Conforms to AS 3498-2009 Australia and New Zealand
Measurement conditions: Instant heating: Ambient air temperature
20°C/15°C, water inlet 15°C, water outlet 55°C, highest setting
temperature: 75°C
Working Temp Range
1. Ambient temperature is 5°C ~ 43°C (Heat Pump)-
2. The max temperature of water tank is 70
Operating parameters: The range of the operating water pressures:
0.15~0.7MPa
Storage Capacity L 270
Max Temperature Setting ˚C 60
Power Input kW 0.94
Heating Output kW 3.6
C.O.P at 20˚C Air 4.27
Noise Rating dB(A) 48
Running Current A 3.9
Power Supply 220 240V/1/50Hz-
Water Inlet/Outlet Size mm 20 (3/4”)
Auxiliary Heating kW 1.5
Operating Temperature Range ˚C -5 to 43
Hot Water Recovery L/hr 89
With Hydro Boost L/hr 119
Net Weight kg 130
2. Dimensions
Evo270-1
A
B
C
D
E
DIAMETER
1992
1443
593
1211
1111
640
Φ64 0
