EVE AUDIO PRODUCT MANUAL
SC2070
DEC 2022
SC2070
2
SAFETY INSTRUCTIONS
To avoid the risk of electrical shock, do not attempt to open the unit.
There are no user-serviceable parts inside. Do not attempt to service the
equipment yourself. In case of problems, please contact your local dealer
or distributor.
This unit should be connected to a grounded power outlet. If you use
extension cords and power distributors they should be grounded as well.
Verify that the specied operating voltage on the rear side matches the
local mains voltage. If these values do not match you will have to adjust
the loudspeaker setting appropriately and change the fuse type.
Use only the fuse types specied on the rear side of the unit. Never bypass
the fuse.
Make sure that no liquids wet the inside of the cabinet. Never spray, pour
or spill liquids directly onto the unit.
Do not use a wet cloth nor ammable or acid chemicals for cleaning.
Do not touch the diaphragms of the loudspeaker and do not obstruct the
bass reex ports.
Make sure there is enough air ow behind the loudspeaker to maintain the
electronic components cool.
Do not expose this product to extreme temperatures.
The diaphragms build up a magnetic eld around the loudspeaker.
High sound pressure levels can damage your hearing permanently! Avoid
standing close to loudspeakers producing high sound pressure levels.
!
!
!
!
!
EVE Audio product manual
3
TABLE OF CONTENTS
1. INTRODUCTION ............................................................................4
2. QUICK START 5 .................................................................................
2.1. First Steps 5 .............................................................................................................................
2.2. Speaker Connection 5 .........................................................................................................
2.3. Powering On 5 .......................................................................................................................
3. OPERATION ...................................................................................6
3.1. First Steps 6 .............................................................................................................................
3.2. Operating Modes 7 ..............................................................................................................
3.3. Powering on/o: Standby Mode 7 .................................................................................
3.4. Volume Mode 7 .....................................................................................................................
3.5. Settings Menu 9 ....................................................................................................................
3.6. Filters .....................................................................................................................................9
3.7. Low Filter 9 ..............................................................................................................................
3.8. High Filter.......................................................................................................................... 10
3.9. Mid Filter 10 ...........................................................................................................................
3.10. Desk Filter 11 .........................................................................................................................
3.11. LED Mode 11 ..........................................................................................................................
3.12. Saving Your Settings ..................................................................................................... 12
3.13. Power Switch 12 ...................................................................................................................
3.14. DIP Switches 13 .....................................................................................................................
3.15. Mains Voltage Selector ................................................................................................. 13
3.16. Power Connector (IEC) 13 .................................................................................................
4. POSITIONING ..............................................................................14
4.1. Speaker Positioning + Rubber Feet 14 .........................................................................
4.2. Height and Distance 15 .....................................................................................................
4.3. Stereo Setup..................................................................................................................... 15
4.4. Stereo Setup + Subwoofer (2.1) 16 ................................................................................
4.5. Multichannel Setup (5.1) 17 .............................................................................................
4.6. Mixer/Workplace Reections 18 .....................................................................................
4.7. Room Acoustics 19 ..............................................................................................................
5. TECHNICAL SPECIFICATIONS 20 .....................................................
6. DECLARATION OF CONFORMITY 21 ...............................................
7. WARRANTY ..................................................................................22
