Seite 1/2
MCC-1D gerilim koruma rölesi 168V sabit düþük gerilim sýnýrý olan çekmede gecikmeli düþük gerilim
koruma rölesidir. Tek fazlý klima sistemlerinde, elektronik kumanda ve kontrol sistemlerinde ve motor gibi
ekipmanlarýn korunmasýnda kullanýlýr.
Kullaným ve Çalýþma Prensibi:
Cihaz, üzerinde yer alan zaman ayar düðmesiyle 5-15 dk. arasýnda istenilen süreye ayarlanýr.
"On" : Besleme "Out" : Normal ýþýklarýdýr.
1- Röle ilk çalýþmaya baþladýðýnda "ON" ýþýðý yanýktýr. Gerilim normal seviyede ise zaman sayýmý baþlar
ve ayarlanan süre sonunda çýkýþ rölesi kontaðýný çeker ve "OUT" ýþýðý yanar.
2-Þayet besleme (ölçme) gerilimi168 V'un altýna düþerse röle gecikmesiz kontaðýný býrakýr ve "OUT" ýþýðý
söner.
TEK FAZLI DÜÞÜK GERÝLÝM KORUMA RÖLESÝ
MCC-1D
Ýþletme Gerilimi (Un)
Ýþletme Frekansý (f)
Ýþletme Aralýðý ( U)∆
Besleme Giriþi Güç Tüketimi
Hataya Geçme Gerilimi
Gecikme Zamaný ( t)∆
Çýkýþ Kontaðý ( )
Ortam Sýcaklýðý
Baðlantý Þekli
Boyutlar
Koruma Sýnýfý
Aðýrlýk
Baðlantý Þemasý
: 220/230 V AC
: 50/60 Hz.
: 160-260V AC
: < 8 VA
: 168 V AC
: 5-15 dk. ± %10 (Ayarlanabilir)
1-5 dk. ±%10 (Opsiyonel)
: 1 NO, 10A/2500VA, Cos =1ϕ
: -5°C; +50°C
: Klemensli, klemens rayýna montaj, panoya vida ile
montaj adaptör parçasý ile mümkündür. (Þekil 1)
: Tip PK 22
: IP 20
:0.1 Kg
MCC-3D gerilim koruma rölesi 168V sabit düþük gerilim sýnýrý olan çekmede gecikmeli düþük gerilim
koruma rölesidir. Üç fazlý klima sistemlerinde, elektronik kumanda ve kontrol sistemlerinde ve motor gibi
ekipmanlarýn korunmasýnda kullanýlýr.
Kullaným ve Çalýþma Prensibi:
Cihaz, üzerinde yer alan zaman ayar düðmesiyle 5-15 dk. arasýnda istenilen süreye ayarlanýr.
"On" : Besleme "Out" : Normal ýþýklarýdýr.
1- Röle ilk çalýþmaya baþladýðýnda "ON" ýþýðý yanýktýr. Gerilimler normal seviyede ise zaman sayýmý baþlar
ve ayarlanan süre sonunda çýkýþ rölesi kontaðýný çeker ve "OUT" ýþýðý yanar.
2-Þayet fazlardan herhangi biri 168 V'un altýna düþerse röle gecikmesiz kontaðýný býrakýr ve "OUT" ýþýðý
söner.
ÜÇ FAZLI DÜÞÜK GERÝLÝM KORUMA RÖLESÝ
MCC-3D
Ýþletme Gerilimi (Un)
Ýþletme Frekansý (f)
Ýþletme Aralýðý ( U)∆
Besleme Giriþi Güç Tüketimi
Hataya Geçme Gerilimi
Gecikme Zamaný ( t)∆
Çýkýþ Kontaðý ( )
Ortam Sýcaklýðý
Baðlantý Þekli
Boyutlar
Koruma Sýnýfý
Aðýrlýk
A2904/Rev.7
Baðlantý Þemasý
: 220/230 V AC 3 faz 4 telli yýldýz baðlantý
: 50/60 Hz.
: 160-260V AC
: < 8 VA
: 168 V AC
: 5-15 dk. ± %10 (Ayarlanabilir)
1-5 dk. ±%10 (Opsiyonel)
: 1 NO, 10A/2500VA, Cos =1ϕ
: -5°C; +50°C
: Klemensli, klemens rayýna montaj, panoya vida ile
montaj adaptör parçasý ile mümkündür. (Þekil 1)
: Tip PK 22
: IP 20
:0.1 Kg
BoyutlarBoyutlar
TÝP PK 22
Sistem
35mm.
23mm.
12mm.
19mm.
45
58
48
32
90
17
62
(Þekil 1) (Þekil 2)
L
N
N
2
On
Out
13
57
9
11
15
t (m.)
L
MCC-1D
1
N
21
TÝP PK 22
45
58
48
32
90
17
62
(Þekil 1) (Þekil 2)
L1
L2
L3
N
Sistem
N
L 21
On
Out
13
57
9
11
15
t (m.)
L2 N L
3
MCC-3D
1
21
35mm.
23mm.
12mm.
19mm.
Teknik Özellikler
Güvenli Kullaným ve Kur Ýçin Uyarýlarulum
Aþaðýdaki talimatlara uyulmamasý halinde yaralanma veya ölümle sonuçlanabilecek durumlar ortaya
çýkabilir.
Cihaz üzerindeki herhangi bir iþlemden önce tüm besleme gerilimlerini kesiniz.
Cihaz þebekeye baðlý iken ön paneli çýkarmayýnýz.
Cihazý solvent veya benzeri maddelerle temizlemeyiniz. Cihazý temizlemek için sadece kuru bez
kullanýnýz.
Cihazý çalýþtýrmadan önce baðlantýlarýnýn doðru olduðunu kontrol ediniz.
Cihazý panoya monte ediniz.
Cihazýnýzdaki herhangi bir sorunda yetkili satýcýnýzla temas kurunuz.
Yukarýdaki önlemlerin uygulanmamasý sonucu doðabilecek istenmeyen durumlardan üretici
firma hiç bir þekilde sorumlu tutulamaz.
Güvenli Kullaným ve Kur Ýçin Uyarýlarulum
Aþaðýdaki talimatlara uyulmamasý halinde yaralanma veya ölümle sonuçlanabilecek durumlar ortaya
çýkabilir.
Cihaz üzerindeki herhangi bir iþlemden önce tüm besleme gerilimlerini kesiniz.
Cihaz þebekeye baðlý iken ön paneli çýkarmayýnýz.
Cihazý solvent veya benzeri maddelerle temizlemeyiniz. Cihazý temizlemek için sadece kuru bez
kullanýnýz.
Cihazý çalýþtýrmadan önce baðlantýlarýnýn doðru olduðunu kontrol ediniz.
Cihazý panoya monte ediniz.
Cihazýnýzdaki herhangi bir sorunda yetkili satýcýnýzla temas kurunuz.
Yukarýdaki önlemlerin uygulanmamasý sonucu doðabilecek istenmeyen durumlardan üretici
firma hiç bir þekilde sorumlu tutulamaz.
Teknik Özellikler
“Bu ürün, 30.05.2008 tarih ve 26891 sayýlý resmi gazetede yayýnlanan EEE Yönetmeliðinin Madde 2 ve
Ek-1A madde 9 kapsamýndadýr.”
www.entes.com.tr www.entes.com.tr
Dudullu OSB; 1. Cadde; No: 23 34776 Ümraniye - ÝSTANBUL / TÜRKÝYE
Tel : Faks : 0 216 313 01 10 0 216 314 16 15
MCC-3D is a delay OFF protection device that has an under voltage limit at 168VAC. It is mainly used for
protection of three-phase systems such as, electronic command and control systems, capacitors of power
compensation switch boards, air condition systems, motors etc.
Utilization and Operation Principles
Delay ON time can be adjusted between 5-15 minutes with the knob on the front panel
"On" is the Power LED; "Out" is normal LED
1- When the device is supplied for the first time , "On" LED is ON and if the monitored voltages are within
the adjusted range, the output relay is switched ON and "Out" LED turns ON at the end of delay time (5-15
minutes).
2-When any of the phases falls below 168VAC, the output relay and "Out" LED turns OFF without delay.
THREE PHASE UNDER VOLTAGE MONITORING DEVICE
MCC-3D
Rated Voltage (Un)
Rated Frequency (f)
Operating Range ( U)∆
Power Consumption
Tripping Voltage
Delay Time ( t)∆
Output Cantact ( )
Ambient Temperature
Installation
Dimensions
Protection class
Weight
Connection Diagram
: 220/230 V AC 3 phase 4 wire star connection
: 50/60 Hz.
: 160-260V AC
: < 8 VA
: 168 V AC
: 5-15 dk. ±10% (Adjustable)
1-5 dk. ±10% (Optional)
: 1 NO, 10A/2500VA, Cos =1ϕ
: -5°C; +50°C
: Screw type terminals, Rail monted (Possibility of screw montage
with plastic adapter, refer to figure 1)
: Type PK 22
: IP 20
: 0.1 Kg
MCC-1D is a delay OFF protection device that has an under voltage limit at 168VAC. It is mainly used
for protection of single-phase systems such as, electronic command and control systems, capacitors of power
compensation switch boards, air condition systems and motors etc.
Utilization and Operation Principles
Delay ON time can be adjusted between 5-15 minutes with the knob on the front panel.
"On" is the Power LED; "Out" is the normal LED.
1- When the device is supplied for the first time , "On" LED is ON and if the monitored voltage is within
the adjusted range, the output relay is switched ON and "Out" LED turns ON at the end of delay time (5-15
minutes).
2-When the phase value falls below 168VAC, the output relay and "Out" LED turns OFF without delay.
SINGLE PHASE UNDER VOLTAGE MONITORING DEVICE
MCC-1D
Rated Voltage (Un)
Rated Frequency (f)
Operating Range ( U)∆
Power Consumption
Tripping Voltage
Delay Time ( t)∆
Output Cantact ( )
Ambient Temperature
Installation
Dimensions
Protection class
Weight
A2904/Rev.7
Connection Diagram
: 220/230 V AC
: 50/60 Hz.
: 160-260V AC
: < 8 VA
: 168 V AC
: 5-15 min. ±10% (Adjustable)
1-5 dk. ±10% (Optional)
: 1 NO, 10A/2500VA, Cos =1ϕ
: -5°C; +50°C
: Screw type terminals, Rail mounted (Surface mount with clips,
refer to figure 1)
: Type PK 22
: IP 20
: 0.1 Kg
Dimensions Dimensions
Technical Features
TYPE PK 22
90
17
62
45
58
48
32
System
(Figure 1) (Figure 2)
L
N
N
2
On
Out
13
57
9
11
15
t (m.)
L
MCC-1D
1
N
21
Clips
35mm.
23mm.
12mm.
19mm.
TYPE PK 22
90
17
62
45
58
48
32
(Figure 1) (Figure 2)
L1
L2
L3
N
System
N
L
1
2
On
Out
13
57
9
11
15
t (m.)
L
2
N L
3
MCC-3D
1
21
35mm.
23mm.
12mm.
19mm.
Technical Features
PRECAUTIONS FOR INSTALLATION AND SAFE USE
Failure to follow those instructions will result in death or serious injury.
Disconnect all power before working on equipment.
When the device is connected to the network, do not remove the front panel.
Do not try to clean the device with solvent or the like. Only clean the device with a dried cloth.
Verify correct terminal connections when wiring.
Electrical equipment should be serviced only by your compedent seller.
Only for rack panel mounting.
No responsibility is assured by the manufacturer or any of its subsidiaries for any
consequences arising out of the use of this material.
PRECAUTIONS FOR INSTALLATION AND SAFE USE
Failure to follow those instructions will result in death or serious injury.
Disconnect all power before working on equipment.
When the device is connected to the network, do not remove the front panel.
Do not try to clean the device with solvent or the like. Only clean the device with a dried cloth.
Verify correct terminal connections when wiring.
Electrical equipment should be serviced only by your compedent seller.
Only for rack panel mounting.
No responsibility is assured by the manufacturer or any of its subsidiaries for any
consequences arising out of the use of this material.
www.entes.com.tr www.entes.com.tr
Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKEY
Tel : Fax : +90 216 313 01 10 +90 216 314 16 15
