A6696 / Rev.2 www.entes.com.tr
MCB-130/131 MULTIFUNCTION DIGITAL TIME RELAY
With 2 CO Contact
Operating Manual
Dudullu OSB; 1. Cadde; No: 23 34776 Umraniye - ISTANBUL / TURKEY
Tel : Fax : +90 216 313 01 10 +90 216 314 16 15
12
1.1 Product Features
MCB-130/131 has the following features:
· 85-315 VAC/DC - MCB-130
10-30 VAC/DC - MCB-131
· 28 dierent functions
· 0.1-9999 seconds/minutes time range
· 2 separate relay outputs (User can assign a function to any relay.)
· Start-Stop dry contact inputs
· Memoriziing remaining time of function in case of a power outage
· Custom design LCD with green backlight
· SET, ESC, UP, DOWN buttons are located on front panel for easy programming
· PK25 DIN Rail mounting
1.2 Hardware Features
To operate functions with external triggering, the device
has the necessary START and STOP dry contacts.
LCD
UP BUTTON
SET BUTTON
ESC BUTTON
DOWN BUTTON
Stop
Start
LN 4 5 6
C NCNO C NCNO
R1 R2
U
Precautions for Installation and Safe Use
If below precautions are not properly observed and carried out, it may result in cases with injury or
death.
· Disconnect power before working on the device.
· When device is connected to the network, do not remove the front panel.
· Do not clean the device with solvent or similar items. Only clean with dry cloth.
· Verify correct terminal connections before energizing the device.
· Install the device on the electrical panel.
· Contact your authorized reseller in case problems occur with your device.
No responsibility is assured by the manufacturer or any of its subsidiaries for any
consequences rising out of not following above precautions.
1. INTRODUCTION
MCB-125/126 is a multifunction digital timer with 1 CO contact. It oers wide time adjustment range
between 0.1-9999 seconds/minutes.
1.1 Application
MCB-125/126 has 21 different functions with wide adjustable time ranges. The main application area
is the industrial and automation control systems.
The device has two dry contacts for START and STOP inputs.
