Seite 1/2
ERT/ERTC-01 mikroiþlemci tabanlý dört fonksiyona sahip programlanabilir zaman
rölesidir.Bu dört fonksiyon Çekme Gecikmeli, Býrakma Gecikmeli, Aþaðý Sayýcý
ve Flaþördür. Çýkýþ rölesi 1 saniye ile 100 saat arasýnda deðiþen süre sonunda
kontrol edilebilir. Programlanan fonksiyon ve süre bilgileri kalýcý hafýzada saklanýr.
Fonksiyonlar ve süre bilgisi ön panelde bulunan tuþlarla kolayca programlanabilir.
ERT/ERTC-01 optik izoleli Start, Stop ve Reset giriþlerine sahiptir.
Fonksiyonlar:
Çekme Gecikmeli : Bu modda cihaza elektrik geldi inde röle çð ýkýþý verilmez.
Ayarlanan süre sonunda baþlatma sinyaliyle birlikte saymaya baþlar ve süre
sonunda röle çeker. (dLYOn)
Býrakma Gecikmeli: Bu modda cihaza elektrik geldikten sonra start iþaretiyle
birlikte röle çekilir ve ayarlanan süre sonunda röle býrakýr.(dLYOFF)
Aþaðý Sayýcý: Start giriþiyle birlikte ayarlanan süreden aþaðý doðru saymaya
baþlar. Sýfýra ulaþtýðýnda röle çeker. (dO Cnt)
Flaþör tOFF: Bu modda ayarlanan tOFF süresi boyunca röle çekili deðildir.
süresi sonunda röle çeker ve süresi boyunca röle çekili kalýr. tOn süresitOn
sonunda tekrar býrakarak tOFF süresi kadar röle býrakýlý kalýr. Bu iþlem sürekli
devam eder. Flaþörün tOFF veya tOn ile baþlamasý veya ile FlaþörStOn StOFF
modunda ayarlanabilmektedir.
Kontrol Giriþleri: Start giriþiyle sayma iþlemi baþlatýlýr. Stop Giriþiyle sayma
durdurulur ve stop tuþu basýlý olduðu süre boyunca sayma iþlemi durur. Reset
tuþu ise Çekme Gecikmeli, Býrakma Gecikmeli, Flaþör modunda süreyi sýfýrlar
ve aþaðý sayma modunda ise ayarlanan ilk deðere döner.
Fonksiyon Seçimi:
Cihazýn programlanmasý için Set tuþuna 3 saniye basýlý tutulup ana menüye girilir.
Displayde dLYOn ve ledlerden ise dLYOn mod ledi yanýp söner. Aþaðý yukarý
tuþlarý ile istenen fonksiyona gelinir. Set tuþuna tekrar basýlýr menude yanýp sönme
durur. Bu iþlem o fonksiyonun seçildiðini gösterir. Tekrar Set tuþuna basýlýr ve
önce ayarlanmýþ süre bilgisi ekranda yanýp söner aþaðý yukarý tuþlarý yardýmýyla
istenen deðere ayarlanýr. Aþaðý ve yukarý tuþlarýna sürekli basýlý tutulursa bir
sonraki digit arttýrýlýr veya azaltýlýr ve bu böylece en soldaki digite kadar ayarlanýr.
Ýstenilen süre ayarlandýktan sonra Set tuþuna tekrar basýlýr. Ekranda yanýp sönme
durur, tekrar Set tuþuna basýlýrsa seçilmiþ olan fonksiyonun ledi tam yanar ve
ayarlama iþlemi tamamlanýr. ( Not :Flaþör modunda süreyi ayarlamak için birkaç
adým daha gereklidir. Önce tOFF süresi, sonra tOn süresi ardýndan baþlatma
modu seçilir.) Start griþiyle cihaz saymaya baþlar.
Cihaz ön paneldeki tuþlar yardýmýyla da kontrol edilebilir. Set ve yukarý tuþuna
ayný anda basýldýðýnda cihaz baþlatýlýr. (Start giriþiyle ayný fonksiyon)
Set ve aþaðý tuþuna basýldýðýnda cihazýn saymasý durdurulur (Stop griþiyle ayný).
Aþaðý ve yukarý tuþuna ayný anda basýldýðýnda ise deðerler resetlenir (Reset
tuþuyla ayný).
Boyutlar (ERTC-01):
*Soðutma için vantilatör vb. gerekmez
ÇOK FONKSiYONLU ZAMAN RÖLESÝ
ERT/ERTC-01
Teknik Bilgiler:
Besleme Gerilimi (Un) : 220 V AC / 120 V AC
Çalýþma Aralýðý (
D
U) : 190 - 260 V AC / 90 - 140 V AC
Çalýþma Frekansý (f) : 50/60 Hz
Güç Tüketimi : < 3 VA
Çýkýþ kontaðý :1 Enversör 8A/2000VA
Hata :±%0.5 veya ±20msec.(hangisi büyükse)
Tekrarlama Hatasý :±%0.1
Reset Süresi :<= 80 msec.
Ortam Sýcaklýðý : -5°C; +50°C
Gösterge : Kýrmýzý LED gösterge
Boyutlar : PK-20 (ERTC-01) , PR-18 (ERT-01)
Cihaz Koruma Sýnýfý : Çift izolasyonlu ( )
Koruma Derecesi : IP 40 (Ön Panel)
: IP 20 (Terminal kapaðý)
Kutu Malzemesi : Yanmaz , (Yellow Sertifika no:187982)
Kablo Kesiti (Klemens için) : 2.5 mm2
Aðýrlýk : 0.25 kg
Montaj : Ray Montaj (ERTC-01) , Sýnýf III (ERT-01)
Koli Boyutu : 22 x 18 x 18.5 cm (ERTC-01)
: 37 x 21.5 x 17 cm (ERT-01)
Koli Aðýrlýðý : 4 Kg(ERTC-01) , 4.5Kg (ERT-01)
Kolideki Cihaz Sayýsý : 16
Menü butonlarý
Tip PK 20
53 mm
90 mm
45 mm
62 mm
58 mm
32 mm
48 mm
35 mm
Boyutlar (ERT-01):
TÝP PR 18 (72*72)
82.6mm
73.3mm
Duvar
82.6mm
65.5mm
50mm
72mm
66mm
Start
Reset
Stop
Un
C
NC
NO
Yardýmcý
Besleme
Çekme
Gecikmeli
Býrakma
Gecikmeli
Aþaðý
Sayýcý
Flaþör-
StOn Modu
Flaþör-
StOFF Modu
Start Çekme
Gecikme
Zamaný
Býrakma
Gecikme
Zamaný
StartAþaðý
Sayýcý
Zamaný
Start
Start
tOn
Zamaný
tOn
Zamaný
tOn
Zamaný
Start
tOFF
Zamaný
tOFF
Zamaný tOFF
Zamaný
Röle
Çýkýþý Röle
Çýkýþý
Röle
Çýkýþý
Röle
Çýkýþý
Röle
Çýkýþý
3 sn SET
tOFF
süre ayarý
tOn
süre ayarý
StOF veya StOn
ayarý
SET
SET
SET
SET
Start
Start
Baðlantý Þemasý
(ERTC-01):
Programlama Diyagramý:
Baðlantý Þemasý (ERT-01):
Un
1 2 3 4 5 6 7 8 9
NC
NO
C
Start
Stop
Reset
73.3mm
66mm
72mm
66mm
YUKARIAÞAÐI SET
Çekme Gecikmeli Býrakma Gecikmeli Aþaðý Sayýcý Flaþör
Fonksiyon Ledleri
Güvenli Kullaným ve Kur Ýçin Uyarýlarulum
Aþaðýdaki talimatlara uyulmamasý halinde yaralanma veya ölümle sonuçlanabilecek
durumlar ortaya çýkabilir.
Cihaz üzerindeki herhangi bir iþlemden önce tüm besleme gerilimlerini kesiniz.
Cihaz þebekeye baðlý iken ön paneli çýkarmayýnýz.
Cihazý solvent veya benzeri maddelerle temizlemeyiniz. Cihazý temizlemek için
sadece kuru bez kullanýnýz.
Cihazý çalýþtýrmadan önce baðlantýlarýnýn doðru olduðunu kontrol ediniz.
Cihazý panoya monte ediniz.
Cihazýnýzdaki herhangi bir sorunda yetkili satýcýnýzla temas kurunuz.
A2874/Rev.3
Yukarýdaki önlemlerin uygulanmamasý sonucu doðabilecek istenmeyen
durumlardan üretici firma hiç bir þekilde sorumlu tutulamaz.
Bu ürün, 30.05.2008 tarih ve 26891 sayýlý resmi gazetede yayýnlanan
EEE Yönetmeliðinin Madde 2 ve Ek-1A madde 9 kapsamýndadýr.
ERT/ERTC-01 is a microcontroller controlled programmable time relay device with a
wide range of time scale designed to operate in one of 4 different functions that are
On delay Off delay Down timer Flasher, , , modes. Output relay is controlled by set
value that can be set between 1.0 sec 100 hours. Programmed function and set
values are recorded at non-volatile memory. Functions and set values can be
programmed easily by buttons on the front panel. ERT/ERTC-01 has optically isolated
Start, Stop and Reset inputs.
Functions:
On Delay: In the On Delay mode, after the device is energized, the timer starts to
count up and when it reaches the adjusted time , the relay is energized. (dLYOn)
Off Delay: In the Off Delay mode, after the device is energized and with start input ,
the relay is energized and becomes de-energized at the end of the time adjusted by
the user. (dLYOFF)
Down Timer: In the Down Timer mode, after the device is energized, the down counter
starts to count down from the time adjusted by the user and when it reaches zero, the
relay is energized. (dO Cnt)
Flasher: In the Flasher mode, after the device is energized, when time ends thetOFF
relay is energized and becomes de-energized at the end of the delay The tOn (FLSHEr).
starting mode of the flasher mode can be choosen with or . In the StOFFStOFF StOn
mode flasher starts with tOFF and energized after the tOFF value, then continiues to
tOn mode. In the StOn mode flasher starts with tOn and deenergized after the tOn
value, then continues to tOFF mode. The Flasher function is continuously repetitive.
Inputs: Start input is used to begin counting, Stop input is used to end counting and
Reset input is used to clear counter in dlYOn,dlyOFF and FLSHEr. In dO Cnt mode
reset, sets the dO Cnt value. One of this three inputs activated by connecting them
to GND.
Function Select:
The device is programmed by pressing the SET buttun for 3 secs. Then program menu
starts with blinking of dLYOn. With UP and DOWN button desired mode dLYOn,
dLYOFF, dO Cnt or FLSHEr, and the mod led blinks. After pressing the SET button
display stops blinking that this mode is choosen. Pressing once to SET button shows
the old time value of this mode with blinking and this could be adjusted with UP and
DOWN button. Pressing to UP or DOWN button continious, increases or decreases
the left digit. For all the other functions, the left digit is changed the same way. After
adjusting the time value, pressing the SET button stops the display blinking, but led
button still blinks (Note that this setting operations need a few steps more for FLSHEr
mode). After pressing the SET button last time mod led stops blinking, desired mod
and value are set and writed to non-volatile memory.
Device can be started to counting with start input. With stop input device stops
counting until stop input is deactivated. Reset input resets the time values. Device
can be started with pressing set and up button at same time (same function with
start input). Pressing set and down button at the same time stops counting.( same
function with stop input). Pressing DOWN and UP button at the same time resets
counting (same function with RESET input).
Technical Data
Operating Voltage(Un) : 230 V AC / 120 V AC
Operating Range (
D
U) : 190 - 260 V AC / 90 - 140 V AC
Operating Frequency (f) : 50/60 Hz
Power Consumption : < 3 VA
Output Contact :1 Change-Over 8A/2000VA
Error :±%0.5 or ±20msec.(Which is higher)
Repetition Error :±%0.1
Reset Time :<= 80 msec.
Ambient Temprature : -5°C; +50°C
Display : Red LED display
Dimension : PK-20 (ERTC-01) , PR-18 (ERT-01)
Equipment Protection : Double Insulation ( )
Degree of Protection : IP 40 (Front Panel)
: IP 20 (Terminal Covers)
Box Material : Nonflammable, (Yellow Certificate no:187982)
Wire Cros section (for terminal)s : 2.5 mm
2
Weight : 0.25 kg
Installation : Rail Mounting (ERTC-01) , Class ýýý (ERT-01)
Package Diemensons : 22 x 18 x 18.5 cm (ERTC-01)
: 37 x 21.5 x 17 cm (ERT-01)
Package Weight : 4 Kg (ERTC-01) , 4.5 Kg (ERT-01)
Pcs Per Package : 16
MULTIFUNCTION ELECTRONIC TIME RELAY
ERT/ERTC-01
*No need of a vantillator in the installation area
Dimensions (ERTC-01):
Dimensions (ERT- 01):
Programming Diagram
On Delay
Off Delay
Down
Counter
Flasher-
StOn Mode
Flasher-
StOFF Mode
On Delay
Time
Off Delay
Time
Down
Counter
Time
Start
Start
tOn
Time
tOn
Time
tOn
Time
tOFF
Time
tOFF
Time tOFF
Time
Relay
Output
Relay
Output
Relay
Output
Relay
Output
Relay
Output
Start
Start
Start
Menu buttons
UpDown SET
Connection Diagram (ERT-01):
Un
1 2 3 4 5 6 7 8 9
NC
NO
C
Start
Stop
Reset
Type PK 20
53 mm
90 mm
45 mm
62 mm
58 mm
32 mm
48 mm
35 mm
3 s SETec
tOFF
time setting
tOn
time setting
StOF or StOn
setting
SET
SET
SET
SET
Start
Start
Start
Reset
Stop
Un
C
NC
NO
Auxiliary
Supply
TyPe PR 18 (72*72)
82.6mm
73.3mm
66mm
73.3mm
Duvar
82.6mm
65.5mm
50mm
72mm
66mm
Connection Diagram
(ERTC-01):
72mm
66mm
ON Delay OFF Delay Down Counter Flasher
Function Leds
Precautions For Installation and Safe Use
Failure to follow those instructions will result in death or serious injury.
Disconnect all power before working on equipment.
When the device is connected to the network, do not remove the front panel.
Do not try to clean the device with solvent or the like. Only clean the device
with a dried cloth.
Verify correct terminal connections when wiring.
Electrical equipment should be serviced only by your compedent seller.
Only for rack panel mounting.
A2874/Rev.3
No responsibility is assured by the manufacturer or any of its subsidiaries
for any consequences arising out of the use of this material.

Produktspezifikationen

Marke: Entes
Kategorie: niet gecategoriseerd
Modell: ERT-01-72

Brauchst du Hilfe?

Wenn Sie Hilfe mit Entes ERT-01-72 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung niet gecategoriseerd Entes

Entes

Entes ERB-50 Bedienungsanleitung

6 September 2024
Entes

Entes GEM-10SH Bedienungsanleitung

6 September 2024
Entes

Entes RGSR-24S-OG Bedienungsanleitung

6 September 2024
Entes

Entes RGSR-20S-OG Bedienungsanleitung

6 September 2024
Entes

Entes RG3-15CL Bedienungsanleitung

6 September 2024
Entes

Entes MPR-53S-96 Bedienungsanleitung

6 September 2024
Entes

Entes MPR-47S-L Bedienungsanleitung

6 September 2024
Entes

Entes ETMO-02-DR Bedienungsanleitung

6 September 2024
Entes

Entes MPR-45S-L Bedienungsanleitung

6 September 2024
Entes

Entes MPR-53S-OG-DIN Bedienungsanleitung

6 September 2024

Bedienungsanleitung niet gecategoriseerd

Neueste Bedienungsanleitung für -Kategorien-

APC

APC C2C Bedienungsanleitung

18 September 2024
APC

APC AP7868 Bedienungsanleitung

18 September 2024
APC

APC P8VNTG Bedienungsanleitung

18 September 2024
APC

APC P62 Bedienungsanleitung

18 September 2024
APC

APC AP7898 Bedienungsanleitung

18 September 2024
Hama

Hama Magnet 00183283 Bedienungsanleitung

18 September 2024
IFM

IFM TD2211 Bedienungsanleitung

18 September 2024
Coyote

Coyote C1CH36FS Bedienungsanleitung

18 September 2024
IFM

IFM AC001S Bedienungsanleitung

18 September 2024
Dimplex

Dimplex SRX120EM Bedienungsanleitung

18 September 2024
