User Manual
EMM Series
Multimeters
www.entes.com.tr
2
Index
Introduction .......................................................................................................... 3
Safety and warnings ......................................................................................... 3
General Speciîš¿cations ..................................................................................... 3
Mechanical and Environmental Conditions ...................................................... 4
Standards ......................................................................................................... 4
Technical Speciîš¿cations ................................................................................... 4
Connection Diagram ......................................................................................... 6
LED Indicator and GUI design .......................................................................... 9
Key Functions .................................................................................................. 9
Measurement ....................................................................................................... 10
Voltage ............................................................................................................. 10
Current ............................................................................................................. 11
Neutral Current ................................................................................................. 11
Frequency ........................................................................................................ 12
Cos Phi ............................................................................................................. 12
Total Cos Phi .................................................................................................... 12
Total Run Hour ................................................................................................. 13
Run Hour .......................................................................................................... 13
Settings ................................................................................................................ 14
User Settings .................................................................................................... 14
Security Settings .............................................................................................. 14
Password Setting ............................................................................................. 15
Connection Settings ......................................................................................... 15
Connection Type .............................................................................................. 16
Frequency ........................................................................................................ 17
Demand Period (Based on Model) ................................................................... 17
Voltage Transformer Setting ............................................................................. 18
Current Transformer Setting ............................................................................. 19
Communication Settings .................................................................................. 19
Output Settings ................................................................................................. 21
Alarm Settings .................................................................................................. 22
Alarm Messages ............................................................................................... 31
3
Introduction
Safety and Warnings
Caution
Failure to follow the instructions below may result in serious injuries or even death..
• Disconnect all power when installing the device.
• Do not remove the front panel while the device is connected to the mains.
• Do not clean the device with solvent or similar material. Use only a dry cloth.
• Check that the connections are correct before operating the device.
• Contact your authorized dealer if you have any questions about your device.
• The device is for panel mounting only.
• The fuse to be used must be type F and the current limit value must be 1A.
The manufacturer cannot be held responsible for unwanted situations that may emerge due to failure
to follow the measures above.
Security
Read the entire operating manual before using the device.
• Connect a button or a circuit breaker between supply inlets of the product and the mains.
• This button or circuit breaker must be close to the product.
• Place a mark to indicate that this button or circuit breaker will be used to separate the product from
the mains.
Warranty
The warranty period of the device is 2 (two) years. In case of a malfunction, the product should be
repaired by the manufacturing company only. Otherwise, the warranty will be void.
General Speciîš¿cations
• Wide supply range
• Slim design for narrow panels
• 3-Phase Voltage 3-Phase Current measurement
• Alarm options (based on model)
• Run Hour
• 2x Relay Output (based on model)
• Modbus communication (based on model)
• 96 x 96 panel mounting
