Energy Power™ 12 Sub

Owner's Manual

™

Important Safety InStrUCtIonS!

1. READ these instructions.

2. KEEP these instructions.

3. HEED all warnings.

4. FOLLOW all instructions.

5. DO NOT use this apparatus near water.

6. CLEAN ONLY with dry cloth.

7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other appara-

tus (including ampliﬁers) that produce heat.

9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has

two blades with one wider than the other. A grounding type plug has two blades and a third

grounding prong. The wider blade or the third prong are provided for your safety. If the provided

plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11. ONLY USE attachments/accessories speciﬁed by the manufacturer.

12. USE only with a cart, stand, tripod, bracket, or table speciﬁed by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.

14. REFER all servicing to qualiﬁed service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15. DO NOT expose this apparatus to dripping or splashing and ensure that no objects ﬁlled with

liquids, such as vases, are placed on the apparatus.

16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord

plug from the AC receptacle.

17. The mains plug of the power supply cord shall remain readily operable.

The exclamation point, within an equilateral triangle, is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the product.

The lightning ﬂash with arrowhead symbol within an equilateral triangle, is intended

to alert the user to the presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of

electrical shock to persons.

WARNING: To reduce the risk of ﬁre or electrical shock, do not expose this apparatus to rain or

moisture.

WARNING: No naked ﬂame sources – such as candles – should be placed on the product.

Place the equipment near a main power supply outlet and make sure that you can easily access

the power breaker switch.

WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back

panel or included power supply of the product. Operation from other voltages other than those

indicated may cause irreversible damage to the product and void the products warranty. The use

of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages

in which the product was not designed to operate. If the product is equipped with a detachable

power cord, use only the type provided with your product or by your local distributor and/or

retailer. If you are unsure of the correct operational voltage, please contact your local distributor

and/or retailer.

paCkIng LISt

• One 10" Front Firing Subwoofer

• One Power Cord

• One Owner’s Manual

poSItIonIng yoUr poWereD SUBWoofer

Energy powered subwoofers are designed to reproduce the deep bass and deliver

the impact that really makes your movies and music come alive. For optimum

performance, place your subwoofer in a corner of the room on the same wall

as your front channel speakers. Refer to Figure 1 for placement. Please note

that room placement can have a dramatic effect upon the performance of your

powered subwoofer. Corner placement, as suggested above, will increase the

amount of bass output, while placing the subwoofer along the middle of a wall,

or out in the room will decrease the amount of bass output but may result in

tighter sounding bass. Experiment with a number of different placement options

and control settings to ﬁnd the one that best suits your particular room and taste.

When choosing your subwoofer’s location, keep in mind that you will need to con-

nect the subwoofer’s built-in ampliﬁer to an AC power outlet.

ConneCtIng yoUr poWereD SUBWoofer to yoUr eLeCtronICS

Controls and Optional Connections — Powered subwoofers can be hooked

up to the subwoofer output of your electronics via the RCA jack inputs on the

subwoofer’s rear panel. Refer to Figure 2. This is preferred over the conventional

speaker wire connections. For more information on the controls mentioned in this

manual and on bass management, see your dealer or visit energy-speakers.com.

“Line In” — This input is ﬁltered by the built-in Low Pass (LP) crossover and is

designed as a general purpose input for the subwoofer.

Conventional Speaker Wire Connection — Using 16-gauge or larger speaker

wire, connect the RED “positive” (+) terminal of your ampliﬁer’s LEFT channel to

the RED “positive” (+) terminal of your subwoofer’s LEFT channel input (“Speaker

In”). Connect the BLACK “negative” (–) terminal of your ampliﬁer’s LEFT chan-

nel to the BLACK “negative” (–) terminal of your subwoofer’s LEFT channel input

(“Speaker In”). Repeat this procedure for connecting your ampliﬁer’s RIGHT chan-

nel to your subwoofer’s RIGHT channel input. Refer to Figure 2. Take care to make

sure that no bare wires from any of the connections touch any other terminals as

this could cause a short and damage your equipment.

“Low Pass (LP) Crossover” – The crossover allows the user to select the

upper-frequency cutoff of the subwoofer. The frequency is selectable from 50-

150Hz. Frequencies above the set level are ﬁltered out, allowing you to blend the

subwoofer’s output into your main speakers.

“Volume” – This serves as the overall volume control for the subwoofer. It is used

to match the output level of the sub to your main speakers.

“Phase 0/180” – This control is used to acoustically match the subwoofer’s

output to your main speakers. You want to select one of the two positions, either

0 or 180, in which your sub has more output at your listening position.

“Power Off/Auto/On” – “OFF/AUTO/ON” - Selecting “Auto” allows the sub

to turn on the audio ampliﬁcation when it senses an audio input signal. It will

automatically turn off the audio ampliﬁcation after 20 minutes if no signal input

is detected. The sub has an LED on the top of the back panel that indicates the

status of the auto function. The LED will light RED when the ampliﬁer is in the

“Off” position or in the “Auto” position with no audio signal, and GREEN when the

ampliﬁer is receiving a signal in the “Auto” position or when in the “On” position.

Care anD CLeanIng of yoUr poWereD SUBWoofer

The only thing you should ever need to do to your speakers is dust them oc-

casionally. Never apply any abrasive or solvent-based cleaner or any harsh deter-

gent. You can clean the grilles with the brush attachment of a vacuum cleaner.

C a U t I o n

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this

equipment are hazardous to life. No user-serviceable parts inside.

Refer all servicing to qualified service personnel.

proDUCt regIStratIon

•Energywillkeepyouup-to-dateonnewproductsandpromotions.

•Yourpersonalinformationwillneverberesold.

•Thisregistrationinformationisnotusedforwarrantypurposes.

Please retain your receipt for warranty claims.

fCC anD CanaDa emC CompLIanCe InformatIon:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not in-stalled and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Approved under the veriﬁcation provision of FCC Part 15 as a Class B Digital

Device.

Caution: Changes or modiﬁcations not expressly approved by the manufacturer

could void the user’s authority to operate this device.

Caution: To comply with the limits of the Class B digital device, pursuant to Part

15 of the FCC Rules, this device is to comply with Class B limits. All peripherals

must be shielded and grounded. Operation with non-certiﬁed peripherals or

non-shielded cables may result in interference to radio or reception.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du

Canada.

eU CompLIanCe InformatIon:

Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive

2006/95/EC; Conforms to European Union EMC Directive 2004/108/EC.

Weee notICe

Note: This mark applies only to countries within the European Union (EU) and

Norway.

This appliance is labeled in accordance with European Directive

2002/96/EC concerning waste electrical and electronic equipment

(WEEE). This label indicates that this product should not be disposed

of with household waste. It should be deposited at an appropriate

facility to enable recovery and recycling.
