1-way wireless rotary switch for single
mounting 80 x 80 x 25 mm over a  ush box or
mounting into the E-Design55 switching
system. With battery (lifetime 2-8 years).
Smart Home sensor.
The scope of supply comprises a moun ting
base with snapped-on electronics, a frame
R1UE55 and a cover panel with rotary knob.
The rotary switch sends dimming values
(brightness values) to the dimming actuator.
At switching off over the rotary switch, this
value is stored into it. If several rotary switches
are taught in in the same dimming actuator,
and dimming commands are alternatively
sent from different ones, it can be that
brightness jumps appears during the dimming
process.
To teach-in the wireless rotary switch to the
actuators, remove the rotary knob.
2 internal 3 V CR1632 button cells are supplying
the power for several years.
To replace the button cell, just remove the
front panel and the rotary knob.
Only assemble on a  at surface:
Screw on mounting base or stick it on using
the enclosed adhesive foil. Then snap on the
frame, remove the battery insulations, plug on
the rotary knob and snap on the front panel.
We recommend stainless-steel countersunk
screws 2.9x25 mm, DIN 7982 C, for screw
connections. Both with rawl plugs 5x25 mm
and with 55 mm switch boxes. Set of 2 stain-
less-steel countersunk screws 2.9x25 mm
and plugs 5x25 mm are enclosed.
Minimum brightness can be adjusted in 3 steps
with one jumper. You can also select the soft-on
function which switches on the lighting grad-
ually.
Wireless sensor without wire
Wireless rotary switch
FDT55EB-
GB
Temperature at mounting location:
-20°C up to +50°C.
Storage temperature: -25°C up to +70°C.
Relative humidity:
annual average value <75%.
30 055 539 - 1
Press on the middle of the rotary knob to
switch on at the last dimming value or to save
the current dimming value and switch off.
Wireless switching actuators FSR61, FL62
and FSLA can be switched on by pressing or
turning and switched off by pressing.
The following applies to FD62:
Turn to the right (clockwise) to dim up. The
turning speed determines the dim-up speed.
If the dimming actuator was switched off to
the right at the start of dimming, switch-on is
at minimum brightness followed by gradual
dim-up. This is the children‘s room circuit.
If the rotary knob is turned to the right jerkily
– with the actuator previously switched on or off
– dim-up is rapid to full brightness. This corre-
sponds to the double-click function of a normal
direction pushbutton, top
.
Turn to the left (anticlockwise) to dim-down
to the minimum brightness adjusted on the
dimming actuator. The turning speed deter-
mines the dim-down speed.
If the rotary knob is turned to the left jerkily,
dim-down is rapid to the minimum brightness
adjusted on the dimming actuator.
Teach-in:
To teach in the wireless rotary switch in
the actuators, pull off the rotary knob and
the front panel. Press and hold the mini
pushbutton (LRN) which is then accessi-
ble and brie y press the rotary knob
shaft.
Please look on the corresponding actua-
tors manual for the teaching-in position.
Teach-in telegram: 0xE0400D80
If the FDT55EB- is taught-in in FL62, FD62 or
FSLA, con rmation telegrams are auto-
matically switched on and sent. It locks
automatically the teach-in mode.
Enable teach-in mode with FDT55EB-:
Plug in the two jumpers on the 4 pins to
select the minimum brightness and brie y
press the rotary spindle.
Clear rotary switch from actuator:
Plug both jumpers on the 4 pins to select
minimum brightness and brie y press the
rotary spindle three times.
Then replug the two jumpers to the
required positions for minimum bright-
ness and Soft-On.
If the dimming actuator was switched off to
the left at the start of dimming, switch-on is
at minimum brightness followed by gradual
dim-up by turning to the right.
To replace the CR1632 button cells, just
remove the cover panel comprising the
rotary knob.
Set the minimum brightness in 3 steps using
the Min. Level jumper.
The lowest dimming value of 10% is situated in
the as-delivered state (jumper plugged onto
the two centre pins).
To reduce the lowest dimming value to 1%,
plug the jumper onto the two left pins.
To raise the lowest dimming value to 20%,
plug the jumper onto the two right pins.
When the Soft-On jumper is plugged onto the
two pins, is selected and the lighting Soft-On
is switched on gradually.
The crossed-out waste container indicates
that batteries may not be disposed with ot-
her household or commercial waste.
Batteries can be returned free of charge to
the retail outlet after use.
Attention: Danger of explosion if
battery is replaced improperly.
Only replace it by an equivalent
type!
!
Frequency 868.3 MHz
Transmit power max. 10 mW
Hereby, Eltako GmbH declares that the radio
equipment type FDT55EB- is in com pliance
with Directive 2014/53/EU.
The full text of the EU declaration of
conformity is available at the following
internet address: eltako.com
Must be kept for later use!
Eltako GmbH
D-70736 Fellbach
Technical Support English:
+49 711 943 500 25
technical-support@eltako.de
eltako.com
28/2022 Subject to change without notice.
Manuals and documents in further
languages
http://eltako.com/redirect/FDT55EB-
1. App 2. 3.
