Follow Spot 100 LED
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Introduction:
The Follow Spot 100 LED is a 2 channel DMX intelligent LED follow spot. The Follow Spot 100 LED features 8
colors, dimming capabilities, zoom, and focus. The Follow Spot 100 LED can be controlled via DMX control-
ler. The unit can be run as a stand alone unit or in a Master/Slave conîźľguration. This unit has been tested and
there is no assembly required. The unit is ready to be plugged in to a power outlet. To enhance the beams
effects you can use a fog machine.
CAUTION! Please read and understand these instructions before installing or operating this unit.
SPECIFICATIONS:
Model: Follow Spot 100 LED
LED: 70W LED
Weight: 15lbs./ 7kgs.
Size: 580 x 280 x 280mm
Beam Angle: 16 - 22 Degrees
Fuse: 5 Amp
Supply Voltage: 100-240V 60-50Hz
Power Consumption: 100W
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 2 DMX Channels
Warranty: 1 Year
CAUTION! Please read and understand these
instructions before installing or operating this unit.
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: motors, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
Fuse Replacement: Uplug the unit from its
power source. Using a phillips-head screw driver
unscrew and remove the fuse housing. Remove
the bad fuse and replace with a new one.
DMX TRAITS: 2 CHANNELS
CHANNEL 1: COLORS
0 - 31 = OPEN (WHITE)
32 - 63 = RED
33 - 95 = YELLOW
96 - 127 = BLUE
128 - 159 = GREEN
160 - 191 = PURPLE
192 - 223= ORANGE
224 - 255 = PINK
CHANNEL 2: MASTER DIMMER
0 - 255 = 0%-100%
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
OPERATION:
DMX Mode:
Operating through a DMX controller give the user the freedom to create own programs tailored to their s their
own individual needs. This unction also allows you to use your îźľxtures as spot lights. The Follow Spot 100 f
LED has 2 DMX channels. See the front page for the DMX traits.
1. This function will allow you to control each individual xture’s traits with a standard DMX 512 controller.
2. Plug in the îźľxture via the XLR connections to any standard DMX controller.
3. Press the function select button to activate DMX mode. The DMX LED and the DMX Receive LED should
glow when in DMX mode and the unit is receiving a signal.
Master-Slave Conîźľguration:
This function will allow you to link units together to run in a Master-Slave mode. In Master-Slave operation s
one unit will act as the controlling unit and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be programmed to act as the “Master.”
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR microphone cables
to link your units together. Remember that the Male XLR connector is the input and the Female XLR con
nector is the output. The îźľrst unit in the chain (master) will use the female XLR connector only. The last
unit in the chain will use the male XLR connector only.
2. Using the Master unit, choose your desired operating mode and connect the “Slave” unit or units.
1 32
456
Functions:
1. Dimmer Buttons - Used to adjust intensity. - Blackout or open the shutter2. Shutter
3. DMX Address/Status LED’s - Shows the current DMX address, and xture status. LED’s show
the xtures current operating status: DMX LED, DMX Receiving LED, or Manual mode LED.
4. DMX Address Adjustment Buttons - Use these buttons to change the DMX Address.
5. Function Selection Button - Use this button to switch between DMX Mode and Manual Mode.
6. Color Buttons - Choose from 7 different colors plus white.
