Installation
Instructions
KIT CONTENTS
4 Support Pads
4 Mounting Screws
Pedestal Organizer
1
TOOLS YOU WILL NEED
Phillips Head
Screwdriver
17mm Open End Wrench
or Adjustable Wrench
8mm Socket Wrench
INSTALLATION PREPARATION
Remove the packaging.
The pedestal organizer is taped at the top of the
shipping carton. Remove the organizer and set
aside for final installation.
Flatten the product carton to use as a pad
to lay the washer or dryer down on its side.
Continue using the carton to protect the finished
floor
in front of the installation location.
Pedestal
MLP1WW
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT
— Save these instructions
for local inspector’s use.
•IMPORTANT
— Observe all governing
codes and ordinances.
•Note to Consumer – Keep these instructions
with your Owner’s Manual for future reference.
•Completion time – 1 to 2 hours
•Proper installation is the responsibility
of the installer.
•Product failure due to improper installation is not
covered under the Warranty.
CAUTION — Due to the size and weight
of these products, and to reduce the risk of
personal injury or damage to the product, TWO
PEOPLE ARE REQUIRED FOR PROPER INSTALLATION.
•See washer and dryer installation instructions for
additional installation requirements and guidelines.
OR
8mm Socket
Electric Screwdriver
NOTE Use Electric screwdriver matching with 8mm Socket: .
3
Installation Instructions
INSTALL THE PEDESTAL
TO THE WASHER OR DRYER
Place the pedestal against the bottom
of the unit. Check to be sure the drawer front
is at the front of the unit.
Align the holes in the pedestal with the
holes in the bottom of the unit. Use a Phillips
screwdriver to install the 4 screws through the
pedestal and into the unit—do not tighten.
Slide the pedestal toward the unit, until it is
aligned front to back. Use an 8mm socket
wrench to securely tighten the screws.
C
B
A
3
NOTE For easier alignment of screw holes: ,
one packaging side foam should be placed
under the pedestal .
Make sure that the front and back of the
Cabinet and pedestal are aligned, and that
the screw holes are aligned.
packaging side foam
LEVEL THE WASHER OR DRYER
Locate the 4 legs from the parts package
and install.
Stand the washer or dryer upright. Move it
close to its final location.
Make sure that the washer or dryer is level
by placing a spirit level on top. Check side
to side and front to back.
Use an open
ended wrench to
adjust the legs
in and out.
Tighten the lock
nut against the
bottom of
the pedestal.
NOTE:
• To minimize vibration, the locking nuts must
be tight.
• To reduce vibration, ensure that all four rubber
leveling legs are firmly touching the floor. Push
and pull on the back right and then the back
left of your washer or dryer.
D
C
B
A
4
