Control panel Lid handle

Lid

Water tank

Body handles

Water-tray

Steam plate

240

54 0

Time(min.)

buns

steamed buns

fresh

about: 40g/pc

5about: 7 g/pc

Amount (g)

Food Time(min.)

eggs

ribs

fresh

6pcs

300g

Comment

40 35

Amount (g)

Time(min.)

180 mL measuring cup

fresh 150g

rice

Comment

Amount (g)

Comment

highest water level

Steamed

cook/stew

lowest water level

asparagus

baby sweet corn

beans

cauliflower

potatoes

fresh

Amount(g)

Food Time (min.) Comment

680

1030

390

655

1050

PRODUCT SPECIFICATION

TROUBLESHOOTING

SUGGESTED STEAMING TIME TABLE FOR FOODS

IMPORTANT SAFEGUARDS PRODUCT DESCRIPTION

PRODUCT FEATURES

OPERATING INSTRUCTIONS

CLEANING AND MAINTENANCE

USAGE

FOOD STEAMER

MODEL : EFS-F6024D(SS)

Please read this manual careful

before operating your set.

Retain it for future reference.

Record model number and serial

number of the set.

See the label attached on the set

and quote this information to your

dealer when you require service.

Concentractor

Steam

concentractor

Outer body

Steamer tray

handle

This product is designed for household cooking.

It is applied to cook foods with multiple functions.

1. Multiple functions including steaming, boiling, stewing,and braising.

2. Steaming is timed and no need to be looked after.

3. This product is equipped with dry boiled protection.

4. Removable inner pot for easy cleaning.

Please read the manual carefully and operate accord-

ing to the requirement.

Take out the steamer and it accessories from the

package. Remove all packing material before using.

Use food detergent to clean the lid, steam tray, steam

concentractor and the water tank. Clean them with

water and then dry them off with soft cloth.Use wet rag

to clean the inner of the water tank.

The body of the product including the water tank, steam

tray and the outer body should be placed on a stable

platform and should be far away from object incline to

damged by steam. The product should be placed in

location out of reach by children.

Before connecting to the power, please make sure the voltage applied is in accord-

ance with that marked on the product. The power should have reliable grounding. In

case that the power cable is damaged. In order to avoid dangers, return the

appliance to the nearest authorized dealer or after sales service centre for examina-

tion, replace or mechanical adjustment.

Children should not use this product on their own. The product should rest in places

where are not reachable to infants, lest accidents such as electric shocks and burns

occur.

Before connecting to the power, please make sure the water level in the water tank

is not lower than the "lower level” limit. While adding water to the appliance. The

water amount should not exceed the “upper level “limit.

Before use please makes sure all components are correctly assembled. Compo-

nents specially designed for the appliance should be used.

This appliance should not function without water inside. Before connecting to the

power, please make sure the water tank contains enough water as required in the

manual.

During use, if position in touch with you is very hot, heat insulation is necessary or

heat-insulated gloves should be applied for operations. Meanwhile, please avoid

direct touch with steam flow lest burns happen.

When the appliance is heated, to take off the upper component, one should pay

attention not to adhere to the lower component lest accidents like food overturned

occur.

Before cleaning the appliance please makes sure the power plug is disconnected.

Do not immerse the body of the appliance into water or conduct operations possibly

letting water flowing inside the body of this product, lest dangers happen.

The appliance should not be used and should be sent to after sales service centre

for checking and maintenance when :

(1)the base of the is damaged or broken.

(2)the functions with abnormality.

(3)the power cable is damaged or broken.

(4)other abnormality occurs.

This product is only suitable for household use. It is not allowed for commercial or

outdoor use.

Our company should not be responsible for problems that occur due to improper

operations or use ranges which are not in accordance with those stipulated in the

manual.

During the appliance is functioning, do not touch the stainless parts of the container

and the lid to avoid being burnt.

Before the is working, the vents of the lid should not be facing the same direction as

that of the side handles; when in operation, one should try to avoid getting in touch

with hot steam to avoid being burnt

10.

11.

12.

13.

Before connecting to the power, make sure there is water

inside the water tank and water amount inside is

sufficient. If there is not sufficient water inside, make

complement promptly. Set up the time according to differ-

ent suggested cooking times. Before setting up the timer

, the steamer should be connected to the power.After the

power is connected, the LED shows “off ” with a flash of

all LED lights and meanwhile the buzzer produces a

sound then the LED display a flashing“ ---”. The whole

appliance is in a standby state.

The steaming duration indicated in the chart are only for your reference and based on

steaming with ambient water and food placed in the container. The actual duration

may varies subject to the quantity and type of food.

Vegetable:

1. The shortest time is needed for cooking vegetables containing chlorophyll to avoid

color change.

2. To obtain better result , add salt of appropriate amount during steaming process

3. Frozen vegetable can be steamed directly without defrosting.

Calibration for added

water in the water tank

Genra

Top Layer

Bottom Layer

Put the steam concentrator to the center of the outstand-

ing part (as per the right picture).

Attention: The steam concentrator is necessary for

steaming function, while for hot pot or boiling/ stewing is

not necessary.

Fill up water directly into the water tank, and locate the

steam concentractor in the center of the outstanding part

(as per the right picture). The right picture shows the

calibration for added water. When boiling/ stewing mode

is selected, added water should be not lower than the

lower water limit but not over the upper water limit. The

upper level limit allows functioning over 75 minutes.

When timed steaming mode is selected, the necessary

water amount can be decided according to the time

needed for the actual steamed food (the calibration eg.

10 mean that the added water can last about 10 minutes

steaming.

When the steamer is in a standby state, press the “

MENU ” button to select the steaming function, without

further button-pressing movement, the steamer will get

into working state automatically after 5 seconds. The

countdown begins with the cooking process started.

During this process, to press “ + ” or “ - ” to add or reduce

the time ( time adjusted : 1-60 minutes).

KEEP WARM / OFF

During the heating process, press this button to stop

heating or cancel this operation. When in the standby

state, press this button 2 times to enter the keep warm

status, then the LED screen shows the default cooking

time “ 1: 00 ” countdown (this time is not adjustable),

during this process the steamer heating the food with

medium heat.

In order to use the product correctly, please read carefully the manual

before use and keep the manual safely.

Eggs & Meats :

Rice & Grains :

Wheaten food :

Genra

Food

Calibration for added

water in the water tank

Bottom Layer

Top Layer

Calibration for added

water in the water tank

Calibration for added

water in the water tank

Tips:

1. Pouring hot water into the water tank can shorten the steaming time adequately, while please be

reminded the referred times in the recipe is determined on the temperature.

2. Do not place too much food in the container. Adequately space is necessary so that steam can flow to

the top.

3.To obtain better steaming result, sizes of food should be smaller in case of stacking food piece of

different sizes, those of the smallest size should be placed on top.

4.The default time in the steamer is all set up based on of steaming with ambient water and food placed

inside the container.

Free combination of containers

You can choose to have only one layer of container or double layers in the

steamer subject to your needs.

Convenient cooking

When using multiple layers of containers, it is suggested to extend the

cooking time. Massive food schedule shouble be located at the bottom

layer when cooked. Different foods can be placed in differeent layers for

direct cooking, while it will cause different flavors to mix together.

Layer partition able to be disassembled

Usage of the layer partition, smart use of the layer partition can increase the

cooking space to cook massive foods (such as complete chicken or

complete duck). The layer patition can be placed over a container when

more than 2 layers of container are used.

Easy to observe the cooking state

During cooking, the cooking state is visible through the transparent window

in the lid.

After cooking has been done, disconnect the plug move the steamer after it

is completely cooled down. Take off the lid carefully and avoid direct

contact to the spilled steam with the human body. To avoid the food from

being overdone, take it out of the container timely and place it on a plate.

EFS-F6024D(SS)

Model No

220-240 ~50Hz

Rated Voltage

1600W

Rated Power

6.0L

Water Tank

Capacity

Finding

The heater does not work

after timing after dry-burning

protection.

the heating tube has not yet completely

cooled down and the temperature

controller has not yet restored

Add water to the water tank over the lower

level limit and keep the heating tube

cooled down for over 1 minute

The steamer still functions

after the water get dried off

not being clean completely

Dirt is flowing on the water

or the water is smelling

The indicator

light is off.

The indicator

light is on.

the heating tube

component is burnt out

connection of the circuit

panel is disconnected

check to see if the switch, the plug(whether

connected properly), the socket, the fuse

and the power cable are all ok

the power source is not connected

the power circuit is damaged

"C1" or "C2" shows on the

control panel and the

buzzer keeps sounding.

the display circuit panel is damaged

the sensor has a problem of

open circuit or short circuit

sensor failure
