AIR VENTED TUMBLE DRYER
FDR 146 F
INSTRUCTIONS FOR USE
IMPORTANT
PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE.
KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE.
GB
EBD 746 F
INSTALLATION
Position the tumble dryer so that the plug remains accessible after installation. Do not block the vent at
the front or base of the dryer, as this will impair the working of the machine. This appliance must not be
installed behind a lockable door, a sliding door or a door with hinges on the opposite side to that of the
tumble dryer.
TUMBLE DRYER VENTING
Your tumble dryer will release warm, damp air in one of three ways.
1) EXTENDIBLE REAR VENTING - A long flexible vent hose is built into the dryer and can be
extended from the large opening at the rear of the machine
2) FIXED REAR VENTING - Venting is through the large opening at the bottom of the rear panel.
A separate extendible vent hose can be attached if desired.
3) FRONT VENTING - This is a special type of dryer which vents through a grille on the plinth. The
opening on the rear panel is blanked off during manufacturing.
Rear vented dryers can be used without a vent hose but not in a confined space. Rear vented dryers
must have a vent hose if they are installed under a work surface or against a wall. To minimise
condensation it is preferable to vent to outside. This may be through an open door or window. The best
solution is to connect the vent hose to a permanent connection through a wall or a single glazed
window. This is particularly recommended for small, cool rooms. A kit for this purpose is available as
an accessory. Front venting machines must be converted to extendible rear venting before a permanent
connection can be made to the outside.
When using a vent hose, remember the following points:
The vent hose must be at least 10cm (4 in) in diameter.
No more than three right-angled bends should be allowed when positioning the vent hose.
Do not distort or constrict the vent hose as this will reduce the airflow.
The vent hose must not be shared with other appliances, for example, a cooker hood outlet.
FINAL INSTALLATION
Push the filter into its operating position as shown in
the diagram. If you wish to change the side on which
your door opens, see the instructions on the back
page. Remove any dust by wiping the drum and door
with a damp cloth. Any initial smell of burning will
be caused by dust on the heater and will quickly
disappear.
THE CONTROLS
A. Heat push button, press to select appropriate heat setting (some programs have limited choice
of heat setting). High is used for drying cottons and linens; half heat is used for drying
synthetics and delicates; cool does not apply any heat
B. “-” push button, changes program or time selected downwards
C. Display Window, indicates Program number / drying time / delay time
D. “+” push button, changes program or time selected upwards
E. Start push button, starts the drying cycle
F. Activate push button, illuminates the Display Window.
G. Program Chart
H. Anti-crease push button, press to select anti-crease mode. Indicator illuminates when anti-crease
has been selected and flashes when the dryer is in the anti-crease phase of the cycle.
I. Reset push-button, resets the program to the default settings
J. Delay Start display, shows delay time selected
K. Delay Start push button, press to select delay start mode and set delay time
MOISTURE SENSING DRYER – FUNCTIONS
This sensing tumble dryer has a full moisture sensing system so you can choose the level of dryness
required on your clothing/items. Alternatively you can select a timed drying cycle.
P1 – Extra dry: clothes are extra dry and can be put away
P2 – Cupboard dry: clothes are dry enough to be put away
P3 – Mid dry: depending upon fabric, clothes are generally dry enough to be put away
P4 – Extra iron dry: clothes are almost dry but can be easily ironed
P5 – Iron dry: clothes are slightly damp and ready to be ironed
P6 – Damp dry: clothes are damp and ready to be ironed
Programs 1-6 can be operated on the full heat, half heat or cool setting.
P7 – 30 minute fixed time drying program. This program can be operated on the full or half heat setting.
P8 – 30 minute fixed time ‘airing’ program; useful for freshening up clothing. This program operates
without the heater, circulating air through the dryer at the ambient temperature.
