July 11, 2018
earthworksaudio.com
Product Registration
To help you get the most out of your
Earthworks purchase, please take a
moment and register your product with us
online at .earthworksaudio.com/register
Service & Repair
If you have any problems with your
Earthworks products, please contact our
Service & Repairs Department.
Email: returns@earthworksaudio.com
Telephone: (603) 654-2433, ext. 119
MADE IN USA
Printed in USA
User’s Guide
Pin 1
“Shield”
Pin 2
“+”
Pin 3
“ ”-
Description
Earthworks P30/HC is a directional pre-polarized con-
denser High Denition Microphone™ with a rst-order
hypercardioid pickup pattern directly coupled to a dedi-
cated wideband, low output impedance transformerless
preamplier. The P30/HC requires a standard 24-48V
Phantom Power supply. It features a frequency response
from 20Hz to 30kHz, fast impulse response, very low
handling noise, uniform polar pattern, and high SPL
handling capabilities. It provides excellent uncolored
rejection of sounds arriving off-axis. Each microphone
is delivered with its own calibration chart providing the
individually measured frequency response curve. A
mounting clip is included with the microphone. The P30/
HC is protected by US Patent No. 6,091,829.
Applications
Earthworks P30/HC is easy to operate. Connect the
microphone to a microphone preamplier supplying 24-
48V phantom power using a standard XLR microphone
cable. Please allow up to one minute for the microphone
to settle. Plugging in the microphone “hot” (phantom
power already present at the input) will not damage the
microphone, and is actually preferred for faster settling.
It is normal for any phantom powered mic to “pop” when
plugged in or powered up. Make sure to mute the signal
to speakers or headphones when phantom power is rst
applied.
The excellent performance characteristics of the P30/
HC give it a very wide range of application possibilities.
With its 5-inch exible neck and small microphone head,
this high-quality microphone could be placed where
other microphones could not, such as under the strings
of an acoustic bass. The P30/HC is an ideal choice for
recording or live sound applications using percussion,
acoustic or amplied instruments, or choir when using
microphone stands. It is superior for choir because it
doesn’t spotlight; rather, it picks up an entire section
with no hot spots.
This microphone has no removable parts.
Care of Microphone
Earthworks P30/HC microphone is a precision instru-
ment designed and built to provide years of excellent
performance. Following these simple rules will help to
protect your investment in the P30/HC:
Avoid touching the front protective screen.
Never attempt to disassemble the microphone –
it cannot be opened.
Avoid extreme heat and condensing humidity.
Allow the microphone to warm up in the case
when bringing it in from the cold weather.
Rough handling may damage the microphone
even if no visible marks are left.
When not in use keep the P30/HC in its case.
•
•
•
•
•
XLR Output Connector Assignment of P30/HC
Specications
Frequency Response: 20Hz to 30kHz
Polar Pattern: Hypercardioid
Sensitivity: 20mV/Pa (-34dBV/Pa)
Power Requirements: 24-48V Phantom, 10mA
Peak Acoustic Input: 139dB SPL
Output: XLR-3
Output Impedance: 65Ί, balanced between pins 2 & 3
Minimum Load: 600Ί between pins 2 & 3
Noise: 16dB, A equivalent
Dimensions L x D: 250 x 22 mm (10 x .860 in.)
Weight: 225g (.5lb)
Impulse Response of P30/HC (typical)
Polar Response of P30/HC (typical)
Specications are subject to change without notice.
Frequency Response of P30/HC (typical)
