Seite 1/24
OWNER S MANUAL’
CORDLESS 20 VOLT STRING TRIMMER LITHIUM ION BATTERY PACK-
Copyright. All Rights Reserved.
Model LST02010
Your string trimmer has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. Properly cared for, it will give you years of rugged, trouble free performance. -
WARNING: To reduce the risk of injury, the user must read and understand the owner s manual before ’
using this product.
Thank you for your purchase.
DO NOT RETURN THIS PRODUCT TO THE STORE. OPERATING,
ASSEMBLY, PARTS, SERVICE QUESTIONS? GO TO
WWW.AMERICANLAWNMOWER.COM OR CALL 1 5111 -800-313-
BETWEEN 8:00 AM— PM EST FOR ASSISTANCE.5:00
SAVE THIS MANUAL FOR FUTURE REFERENCE
CA Compliant
Charger Included
(Model No.
CHL82000)
3189723
BATTERY MUST BE
CHARGED BEFORE FIRST
USE. TWO TO THREE INITIAL
CHARGING/ DISCHARGING
CYCLES MAY BE REQUIRED
TO ACHIEVE MAXIMUM RUN
TIME/CAPACITY.
GENERAL SAFETY
IMPORTANT SAFETY WARNINGS
TO REDUCE RISK OF INJURY:
Before any use, be sure everyone using this tool reads and
understands all safety instructions and other information contained in
this manual.
CAUTION: Wear appropriate personal hearing protection during use.
Under some conditions and duration of use, noise from this product
may contribute to hearing loss.
Save these instructions and review frequently prior to use and in
instructing others.
WARNING: When using electric gardening appliances, basic safety
precautions should always be followed to reduce risk of fire, electric
shock, and personal injury, including the following:
READ ALL INSTRUCTIONS
KEEP CHILDREN AWAY - All visitors, children and pets should stay
at a safe distance from the work area.
DRESS PROPERLY – t wear loose clothing or jewelry. Wear Don’
protective hair covering to contain long hair. They can be caught in
moving parts. Use of rubber gloves and substantial footwear is
recommended when working outdoors. Always wear long pants
when operating this string trimmer.
USE SAFETY GLASSES –Wear safety glasses with side shields or
goggles that are marked to comply with ANSI Z87.1 standard when
operating this product. Use face or dust mask if environment is dusty.
USE RIGHT APPLIANCE – Do not use an appliance for any job
except that for which it is intended.
REMOVE THE BATTERY FROM THE STRING TRIMMER when not
in use or when servicing or cleaning. Do not leave unattended.
CHECK DAMAGED PARTS – Before further use of the trimmer, a
guard or other part that is damaged should be carefully checked to
determine that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving
parts, breakage of parts, mounting and any other condition that may
affect its operation. A guard or other part that is damaged should be
properly repaired or replaced. Call our customer service help line at
1 5111 for assistance.-800-313-
LIGHTING Only operate trimmer in daylight or good artificial light. -
DON T OVERREACH ’– Keep proper footing and balance at all
times.
WARNING: Do Not use the string trimmer with any type of accessory
or attachment. Such usage might be hazardous.
AVOID DANGEROUS ENVIRONMENTS – t use trimmer in Don’
rain, damp or wet locations. Do not operate trimmer in gaseous or
explosive atmospheres. Motors in these tools normally spark, and
the sparks might ignite fumes.
AVOID UNINTENTIONAL STARTING – t carry the string Don’
trimmer with finger on switch. Be sure switch trigger is in the locked
or off position before inserting battery pack.
DANGER: Risk of cut. Keep hands away from the line. Keep both
hands on handles when power is on.
DANGER: Don’t use tool if switch trigger does not turn on or off. Call
Customer Service at 1-800-313-5111 for assistance.
DANGER: Do not dispose of the batteries in a fire. The cell may
explode. Check with local codes for possible special disposal
instructions.
DANGER: Do not open or mutilate the batteries. Released
electrolyte is corrosive and may cause damage to the eyes or skin. It
may be toxic if swallowed.
CAUTION: Exercise care in handling batteries in order not to short
the battery with conducting materials such as rings, bracelets, and
keys. The battery or conductor may overheat and cause burns.
DO NOT ATTEMPT to remove cut material or hold material to be cut
when lines are moving. Make sure trimmer switch is off when clearing
jammed material from guard. Do not grasp the guard or lines when
picking up or holding the trimmer.
CAUTION: Lines coast after turned off.
DON T FORCE STRING TRIMMER ’– It will do the job better and with
less likelihood of a risk of injury at the rate for which it was designed.
STAY ALERT – Watch what you are doing. Use common sense. Do
not operate string trimmer when you are tired or under the influence of
drugs, alcohol or medications.
STORE IDLE STRING TRIMMER INDOORS – When not in use, the
string trimmer should be stored indoors in a dry and high or locked-up
place, out of reach of children.
MAINTAIN TRIMMER WITH CARE – Keep clean for best performance
and to reduce the risk of injury. Inspect extension cord periodically and
replace if damaged. Keep handles dry, clean and free from oil and
grease.
WARNING: Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear protective
footwear that will protect your feet and improve your footing on slippery
surfaces.
WARNING: Use only identical manufacturer s replacement parts. Use ’
of any other parts may create a hazard or cause product damage.
WARNING: Use only the manufacturer s replacement string in the ’
cutting head when using a string trimmer attachment. Do not use any
other cutting attachment, for example, metal wire, rope, or the like. To
install any other brand of cutting head to the string trimmer attachment
can result in serious personal injury.
CAUTION: Use only the following type and size battery (ies): BL82120.
WARNING: California Proposition 65: This product contains chemicals
known to the State of California to cause cancer, birth defects or other
reproductive harm.
WARNING: Some dust and debris created by this tool could contain
chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Some examples of these chemicals
are:
- chemicals in fertilizers
- compounds in insecticides, herbicides and pesticides
- arsenic and chromium from chemically treated lumber
Your risk of exposure to these chemicals varies depending on how
often you do this type of work. To reduce your exposure, work in a well
ventilated area and with approved safety equipment such as dust
masks that are specially designed to filter out microscopic particles.
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov.
2
Model LST02010
PRODUCT SPECIFICATIONS
0.065 Single Line Automatic Feed Edging Function Adjustable Cutting Head- - -
FEATURES
LST02010
Input….………………………….……………………...20V, DC Only
Battery V 2.0 Ah Lithium ion………………………………….…....20 -
Speed 00 RPM ………………………..….....................................90
Cutting Width in.………………………………………………........10
Ibs. Weight . ……… ………………………………………............. 4.2
No. Description No. Description
1 Handle 7 Protection Guard
2 Lock Off Button 8 Trimmer Head -
3 Switch Trigger 9 Auxiliary Handle
4 Locking Collar Battery Pack 10
5 Adjustable Cutting Head Charger 11
6 Edge Guide
ASSEMBLY
UNPACKING
This product requires some assembly.
PACKING LIST
• String Trimmer
• Protection Guard
• Auxiliary Handle, Wingnut, M6x80 Bolt
• Battery Pack
• Charger
• Instruction Manual
WARNING: Do not install battery until assembly is complete.
Failure to comply could result in accidental starting and
possible serious personal injury.
WARNING: If any parts are damaged or missing do not operate
this product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
Carefully remove the product and any accessories from the box.
Make sure that all items listed in the packing list are included.
Inspect the product carefully to make sure no breakage or damage
occurred during shipping.
Do not discard the packing material until you have carefully
inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call 1-800-313-5111
for assistance.
ATTACHING THE PROTECTION GUARD
WARNING: Do not operate the trimmer without the guard attached.
Slide the protection guard (A) as shown below in the direction of the
arrow onto the motor housing (B) until the latches lock in firmly.
Remove blade cover (C) on guard before use.
ATTACHING THE AUXILIARY HANDLE
Position the auxiliary handle (A) so that the holes are in alignment
with the holes in the handle support bracket (B).
Insert the M6X80 hex head bolt (C)
into the hex shaped bolt hole of the
bracket. Secure by tightening the
wing nut (D) onto the bolt (C).
Loosen the wing nut and adjust the
angle and height of the handle (A) to
a safe and comfortable position.
Secure into place by tightening the
wing nut (D) onto the bolt (C).
3
Model LST02010
C
A
B
C
D
