RTS Series Package 01, 02
Side load aluminum door and frame
Installation instructions
08280261 – 02-2020
| | EN
2RTS88 Closers 02-202008280261
dormakaba RTS88 Package 01, 02 Installation Instructions Table of Contents
Table of contents
1 Installation instructions 3
1.1 Prepare frame and install closer 3
1.2 Prepare top of door and install closer arm 4
1.3 Prepare bottom of door and install pivot 5
1.4 Install door 6
2 Adjustments 7
2.1 Door alignment 7
2.2 Clearance adjustments (if required) 8
3 Door removal 9
2.3 Adjust closing speeds 9
dormakaba RTS88 Package 01, 02 Installation Instructions
08280261 02-2020RTS88 Closers 3
Frame
Closer
1.1 Prepare frame and install closer
1 Installation instructions
Fig.1
Header
Side
jamb
Mounting
bracket
1/4-20 flat
head machine
screws
Angle bracket
Fillister head
machine
screws
Closer
Cover plate
1.1.1 Prepare header and side jamb according to
template.
1.1.2 Fasten mounting bracket to side jamb with 3
No. 8-32 pan head machine screws.
1.1.3 Fasten header to side jamb with two No. 10-32
flat head machine screws.
1.1.4 Fasten two 1/4-20 flat head machine screws to
header with lock washers and nuts.
1.1.5 Fasten angle bracket to closer with two hex
head machine screws and flat washers.
1.1.6 Install 2 fillister head machine screws into
mounting tabs on closer; make approximately
three turns.
NOTE: For RTS88 models only - do not remove spacer
washers in mounting tabs.
1.1.7 Install closer into header by inserting
mounting tabs into mounting bracket.
1.1.8 Raise end of closer with angle bracket onto
the two 1/4-20 screws.
1.1.9 Fasten angle bracket with the two remaining
1/4-20 nuts and lock washers.
1.1.10 Tighten the 2 fillister head machine screws
securely.
1.1.11 Install cover plate by sliding tab into frame.
1.1.12 Fasten opposite end to mounting bracket with
2 No.8-32 flat head machine screws provided.
