Analog High Definition 2MP Cameras
DWC-D4783WTIR
Dimensions (unit : mm [inch])
866.446.3595
Rev Date: 6/15 Copyright © Digital Watchdog 2015. All rights reserved. Specifications and pricing are subject to change without notice.
sales@dwcc.tv digital-watchdog.com
Summary
Groundbreaking STAR-LIGHT AHD™ High Definition Cameras use existing
coaxial cables to transmit crystal-clear detailed 1080p images. The
cameras oer 2.1MP resolution along with powerful features such as P-Iris
Lens, Double Shutter Wide Dynamic Range (WDR) and True Day/Night with
Mechanical IR Cut Filter. The STAR-LIGHT AHD cameras are engineered to
work with VMAX AHD DVRs, oering an easy upgrade from analog to high
definition surveillance using existing infrastructure for a cost-eective, high
resolution surveillance solution.
Features
• Analog High Definition (AHD) HD over Coax Technology
• STAR-LIGHT™ Super Low Light Technology
• Panasonic 1/3" CMOS Sensor
• 1080p Resolution at 30fps
• Wide Dynamic Range (WDR)
• Auto Focus P-Iris Lens from 2.8~12mm
• Smart IR™ with Intelligent Camera Sync. 70ft Range
• Smart DNR™ 3D Digital Noise Reduction
• Highlight Masking Exposure (HME)
• True Day/Night with Mechanical IR Cut Filter
• Auto Sensing 24VAC/12VDC with Line Lock
• Secondary Video-BNC Output
• Easy Icon Driven OSD Menu with Built-in Joystick
• Programmable Privacy Zones
• Auto Gain Control (AGC)
• Backlight Compensation (BLC)
• Dynamic Range Compressor (DRC) Reveals Low Light Detail
• Auto White Balance (AWB)
• UTP Built-In
• RS-485 Built-in
DWC-D4783WTIR
IM AGE
Image Sensor Panasonic 1/3" CMOS
Active Pixels 1944 (H) x 1092 ( V)
Scanning System Progressive Scan
Frequency 60Hz / 50Hz
Signal Technology 2.0 Megapixel AHD
Synchronization Internal
Resolution 1920x1080 (1080p)
Minimum Scene Illumination F1.4 (30IRE): 0.35Lux [Color]
F1.4 (30IRE): 0 Lux [B&W ]
S/N Ratio 55dB
Video Output AHD 1080p30fps / 720p60fps / 720p30fps
Alarm Output 1 Alarm Output
LEN S
Focal Length 2.8 ~ 12mm
Lens Type Auto Focus P-Iris
IR Distance 70ft
OPERATIONAL
Shutter Speed 1/30(25) – 1/30,000
Backlight O / On
STAR-LIGHT (Sense-up) O, x2 – x32
Wide Dynamic Range (WDR) O / On
Digital Noise Reduction O, Low, Middle, High
White Balance Auto / Auto-Ex / Preset / Manual
Day and Night Day / Night / Auto
Mirror / Flip Yes
Auto Gain Control Max 60dB
Motion Detection Yes
Privacy Zones 16 Privacy Zones
Sharpness 0 ~ 10
Gamma 0.45 ~ 0.75
RS485 / UTP Built-in PELCO D / PELCO C
Digital Zoom x1.0 ~ x16.0
ENVIRONMENTAL
Operating Temperature -20°C ~ 50°C (-4°F ~ 122°F)
Operating Humidity Less than 90% (Non-Condensing)
Other Certifications FCC, CE, ROHS
ELECTRICAL
Power Requirements DC12V / AC24V Dual Voltage
Power Consumption DC12V: 3.43W, 286mA, LED On: 6.45W, 537mA
AC24V: 3.3W, 137mA, LED On: 5.95W, 248mA
MECHANICAL
Material Plastic
Dimensions 108 x 96.8 mm (4.25 x 3.81 inch)
Weight 240 g (0.529 lbs)
Specifications
*Specifications subject to change without notice.
Ø108.0mm
[4.25"]
96.8mm
[3.81"]
56.3mm
[2.22"]
40.5mm
[1.59"]
