Daikin EKHBRD011ADV17 Bedienungsanleitung

Daikin Ketel & boiler EKHBRD011ADV17

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung fĂŒr Daikin EKHBRD011ADV17 (24 Seiten) in der Kategorie Ketel & boiler. Dieser Bedienungsanleitung war fĂŒr 8 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF
Seite 1/24
OPERATION MANUAL
EKHBRD011ADV17
EKHBRD014ADV17
EKHBRD016ADV17
EKHBRD011ADY17
EKHBRD014ADY17
EKHBRD016ADY17
Indoor unit for air to water heat pump system
and options
Operation manual
1
EKHBRD011~016ADV17+Y17
Indoor unit for air to water heat pump system and options
4P402192-1B – 2017.09
CONTENTS Page
Introduction ..................................................................................... 1
General information .................................................................... 1
Scope of this manual .................................................................. 1
Quick start-up of the unit ............................................................... 2
Space heating operation .................................................................... 2
Domestic water heating operation...................................................... 2
Operation of the unit....................................................................... 2
Remote controller buttons and icons .......................................... 3
Setting the clock.......................................................................... 4
Space heating operation ( ) ...................................................... 5
Room temperature control.................................................................. 5
Leaving water temperature control ..................................................... 5
Domestic water heating operation ( )....................................... 7
Automatic storage............................................................................... 7
Manual storage................................................................................... 8
Reheat................................................................................................ 9
Disinfection operation ......................................................................... 9
Emergency operation.................................................................. 9
Other operation modes ............................................................... 9
Start up operation ( ) ................................................................. 9
Defrost operation ( ) .................................................................. 9
Quiet mode operation ( )................................................................. 9
Simultaneous demand of space heating and
domestic water heating............................................................. 10
Temperature read-out mode ..................................................... 10
Schedule timer operation.......................................................... 10
Space heating .................................................................................. 10
Domestic water heating.................................................................... 12
Quiet mode....................................................................................... 12
Programming and consulting the schedule timer...................... 12
Programming space heating............................................................. 13
Programming quiet mode or domestic water heating....................... 14
Consulting programmed actions....................................................... 14
Tips and tricks .................................................................................. 15
Operating the remote alarm option ........................................... 15
Operating the optional remote controller .................................. 15
Field settings............................................................................. 16
Procedure......................................................................................... 16
Field settings table............................................................................ 17
Maintenance .................................................................................. 19
Maintenance activities ...................................................................... 19
Important information regarding the refrigerant used....................... 19
Troubleshooting ............................................................................ 19
Disposal requirements ................................................................. 19
The English text is the original instruction. Other languages are
translations of the original instructions.
This appliance is not intended for use by persons, including children,
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
INTRODUCTION
General information
Thank you for purchasing this unit.
The unit is the indoor part of the air to water ERSQ or ERRQ heat
pump. The unit is designed for ïŹ‚oor standing indoor installation and
used for heating applications. The unit can be combined with space
heating radiators (ïŹeld supply) and with an EKHTS* domestic hot
water tank (option).
A remote controller with room thermostat functionality is standard
supplied with this unit to control your installation.
Refer to the installation manual for the list of options.
Scope of this manual
This manual describes how to start up and switch off the unit, set
parameters and conïŹgure the schedule timer by means of the
controller, maintain the unit and solve operational problems.
EKHBRD011ADV17 EKHBRD011ADY17
EKHBRD014ADV17 EKHBRD014ADY17
EKHBRD016ADV17 EKHBRD016ADY17
Indoor unit for air to water heat pump system
and options Operation manual
CAREFULLY READ THIS OPERATION MANUAL
BEFORE USING THE UNIT. IT WILL TELL YOU HOW TO
USE THE UNIT PROPERLY AND HELP YOU IF ANY
TROUBLE OCCURS. AFTER READING THE MANUAL,
FILE IT AWAY FOR FUTURE REFERENCE.
■This unit contains electrical and hot parts.
■Before operating the unit, make sure the installation
has been carried out correctly by a professional
dealer.
If you feel unsure about operation, contact your dealer
for advice and information.
NOTE An EKHBRD indoor unit can only be connected to an
ERSQ or ERRQ outdoor unit.
Refer to the installation manual of the indoor unit for
installation procedures.
EKHBRD011~016ADV17+Y17
Indoor unit for air to water heat pump system and options
4P402192-1B – 2017.09
Operation manual
2
Q
UICK
START
-
UP
OF
THE
UNIT
In this chapter the step-by-step procedure is explained for starting up
both space heating and domestic water heating.
The more detailed information of how the unit must be operated is
explained in the chapter "Operation of the unit" on page 2.
The quick start-up offers the user the possibility to start up the
system before reading the entire manual.
Space heating operation
Domestic water heating operation
Manual storage
OPERATION OF THE UNIT
The remote controller offers full control over your installation. It can
control all heating applications which vary in capacity, electrical
supply and installed equipment (options). Operating the EKHBRD
unit comes down to operating the remote controller.
Push the or button
Display:
88888888....8888
starts
blinking Display: " "
Set desired room
temperature (e.g. 22°C)
The remote controller
room thermostat
function is not installed
Push the or
button
You have "room
temperature based"
control of your system
(remote controller
room thermostat is
installed)
You have "leaving water
temperature based" control
of your system
Set desired leaving water
temperature (e.g. 65°C)
If the display is blank,
automatic leaving water
temperature is enabled
Push the button
The LED will light up and the
unit will start
For further details and advised
settings, see "Space heating
operation ( )" on page 5.
Domestic water heating (only if domestic hot water tank option is installed)
Automatic storage (daily water heat-up, once during night and/or once during
day)
Turn on ïŹeld setting [1-00]
and or [1-02] and then push
the button.
See "Automatic storage" on
page 7.
The icon will display.
Hot water will be produced at next scheduled
action.
When water heat-up starts, the icon will
be blinking (1 second interval).
Manual storage (one time water heat-up)(refer to scheme below)
Push and hold the button
for 5 seconds.
See "Manual storage" on
page 8.
The icon will start blinking (1 second
interval).
Hot water will be produced.
Reheat (continuous, keeping the minimum water temperature)
Push the button 1 time.
See .
"Reheat" on page 9
Hot water will be produced if the domestic hot
water tank temperature is below the selected
value.
Water will be heated up until the selected
value is reached.
Push and hold the button for
5 seconds
Display: icon starts blinking Display: " "
Your water will be heated till
storage set point (one time action)
The domestic hot water tank is not
installed
For further details and advised
settings, see "Domestic water
heating operation ( )" on
page 7
NOTE It is advised to use the remote controller, which
includes room thermostat function, delivered with the
unit.
This will prevent excessive space heating and will stop
the outdoor and indoor unit when the room
temperature is above the thermostat set point. Based
on the request from the user there is an immediate
feedback to the compressor control which optimizes
the performance.
Refer to the typical application examples in the indoor
installation manual for more details.
■Never let the remote controller get wet. This may
cause an electric shock or ïŹre.
■Never press the buttons of the remote controller with a
hard, pointed object. This may damage the remote
controller.
■Never inspect or service the remote controller
yourself, ask a qualiïŹed service person to do this.
■Do not rinse the indoor unit. This may cause electric
shock or ïŹre.
■Do not climb, sit or stand on top of the unit.
■Do not place any objects or equipment on the unit top
plate.
