SY-P293
PC to HDMI (1080p) Scaler
OPERATION MANUAL
1. Introduction 1
2. Features 1
3. Package Contents 1
4. Operation Controls and Functions 2
4.1 Front Panel Diagram 2
4.2 Rear Panel Diagram 3
4.3 Connection Diagram 4
5. OSD Menu Reset 4
5.1 OSD Menu Operations 5
5.2 Supported Resolutions 6
6 Speciîcations 6
Table of Contents
1. Introduction
The SY-P293 is designed to upscale analogue video signal from a PC source to
a digital HDMI output boosting a wide-range of HDTV and PC resolutions up to
1080p/WUXGA. The SY-P293 also converts inputted audio signal from Optical
(Toslink) or analogue L/R to both digital and analogue audio outputs. Audio is
then combined with HDMI video output audio simultaneously. The SY-P293 has
a comprehensive OSD menu that allows the user to select a variety of output
resolutions and adjust for best picture quality.
2. Features
⢠v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant.
⢠Scales any PC resolutions to PC (VGA ~ WUXGA)/ HD (480i ~ 1080p)
resolutions.
⢠Automatic detection of the factory setting of the connected display and output
the corresponding resolution and refresh rate, when the NATIVE output is
selected (default setting).
⢠Provides output picture adjustment on contrast, brightness, hue, saturation,
sharpness, RGB (colour tone) level and aspect ratio size.
⢠Supports high resolution output (See section â6.2. Support Resolutionâ for
reference):
⢠PC: VGA, SVGA, XGA, SXGA, UXGA, WXGA, WSXGA, WUXGA.
⢠SD/HD: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p
⢠Supports stereo LPCM analogue/digital audio input and stereo LPCM
analogue/digital output. Simply select from the audio input sources in the OSD
menu, the audio is then outputted to HDMI, Optical (Toslink) and mini-jack
simultaneously.
3. Package Contents
⢠SY-P293
⢠5V DC power supply adaptor.
⢠Operation Manual.
Page 1
