Seite 1/4
Quick Installation Guide
Model: POE400
For support and warranty, please visit: http://www.cudy.com/.
Specifications are subject to change without notice. Cudy is a
registered trademark of Shenzhen Cudy Technologies Co., Ltd.
Other brands and product names are trademarks or registered
trademarks of their respective holders.Copyright©2020
Shenzhen Cudy Technology Co., Ltd. All rights reserved.
EU Address: Otto esser 2c, 65451 Kelsterbach, Germany
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The
original EU declaration of conformity may be found at
http://www.cudy.com/
810600066
CE Mark Warning
This is a class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
Indicators
System indicator: AC Power
User Indicator: Channel Power
Connectors
Protection
Shielded RJ-45, EIA 568A and 568B
Over voltage protection
Anti-interference protection
Operating Temperature: 0 to 45
Maximum 80%, Non-condensing
Storage Temperature:-20 to 70
Environmental
Conditions
Over current protection
Over load protection
Model
Output Voltage
PoE Power
Pin Polarity
POE400
Standard
1/2(-)3/6(+),4/5(+)7/8(-)
IEEE 802.3af (15.4W)/at (30W)/bt (90W)
Data Rates 10/100/1000Mbps
Input Power
Requirements
Dimensions 178.5mm x 80mm x 46mm
56VDC
90W max
IAC Input Voltage: 100 to 240 Vac
AC Input Current: 1A 100-240 Vac
AC Frequency: 50 to 60 Hz
Specifications
4
Power Socket
Ethernet Device
(switch, router, etc.)
1 2 3 4 5
PoE 400
Wireless AP Smart VoIPIP Camera
Powered Device (PD)
Hardware Connection
1
30W
POE
60W PWR
90W
D /ATA INPoE/DATA
30W
POE
60W PWR
90W
D /ATA INPoE/DATA
802.3bt PoE++Injecter
AC Socket
Physical Appearance
2
INPUT 100-240 VAC
PWR
30W
60W
90w
AC Socket
DATA/IN
PoE/DATA
Connect with AC cable
Connect to the Ethernet device with
CAT5E or CAT6 UTP cable to transmit data.
Connect to the camera with UTP cable
CAT5E or CAT6 supply power
LED and Interface Explanation
3
PoE injector got 100-240V power input
When the PoE output power is 0<P≤30W,
LED lights up
When the PoE output power is 30<P≤60W,
LED lights up
When the PoE output power is 60<P≤90W,
LED lights up
802.3bt PoE++Injecter
