Warranty & Product Registration: Register your new Crown ampliﬁer at http://warranty.harmanpro.com

Some models may be exported under the name Amcron®

XLS 1002

XLS 2002

XLS 1502

XLS 2502

XLS DriveCoreTM 2 Series

Operation Manual

5055568 - 04/15

XLS DriveCore 2 Series Power Ampliﬁers

Operation Manual

page 2

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other.

A grounding-type plug has two blades and a third grounding prong.

The wide blade or the third prong is provided for your safety. If the

provided plug does not ﬁt into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly

at plugs, convenience receptacles, and the point where they exit from

the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table speciﬁed by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13. Unplug this apparatus during lightning storms or when unused for

long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required

when the apparatus has been damaged in any way, such as power-

supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain

or moisture, does not operate normally, or has been dropped.

15. Use the mains plug to disconnect the apparatus from the mains.

16. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

17. DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING

AND ENSURE THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS

VASES, ARE PLACED ON THE EQUIPMENT.

18. THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN

READILY OPERABLE.

TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP OR BOTTOM

COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE

AC MAINS, DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE

AC RECEPTACLE. THE MAINS PLUG OF THE POWER SUPPLY CORD

SHALL REMAIN READILY OPERABLE.

WATCH FOR THESE SYMBOLS:

The lightning bolt triangle is used to alert the user to the risk of electric

shock.

The exclamation point triangle is used to alert the user to important

operating or maintenance instructions.

IMPORTANT

XLS Series ampliﬁers require Class 2 output wiring.

MAGNETIC FIELD

CAUTION! Do not locate sensitive high-gain equipment such as

preampliﬁers or tape decks directly above or below the unit. Because this

ampliﬁer has a high power density, it has a strong magnetic ﬁeld which can

induce hum into unshielded devices that are located nearby. The ﬁeld is

strongest just above and below the unit.

If an equipment rack is used, we recommend locating the ampliﬁer(s) in

the bottom of the rack and the preampliﬁer or other sensitive equipment at

the top.

Important Safety Instructions

FCC COMPLIANCE NOTICE

This device complies with part 15 of the FCC rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modiﬁcations not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment.

NOTE: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

XLS DriveCore 2 Series Power Ampliﬁers

page 3

Operation Manual

DECLARATION OF CONFORMITY

Issued By: HARMAN International Inc.

1718 W. Mishawaka Rd.

Elkhart, IN 46517 U.S.A.

FOR COMPLIANCE QUESTIONS ONLY:

Sue.Whitﬁeld@harman.com

European Representative’s Name and Address:

HARMAN International

Cranborne Road Potters Bar,

EN6 3JN United Kindgom

Equipment Type: Power ampliﬁers

Family Name: XLS DriveCore 2 Series

Model Names: XLS 1002, XLS 1502, XLS 2002, XLS 2502

EMC Standards:

EN 55103-1:2009 +A1:2012 Electromagnetic Compatibility – Product Family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control Apparatus for

Professional Use, Part 1: Emissions

Magnetic Field Emissions-Annex A @ 10 cm and 1 MEN 55103-1:2009 +A1:2012

Limits for Harmonic Current Emissions (equipment input current ≤16A per phase)EN 61000-3-2:2006 +A1:2008 +A2:2009

Limitation of Voltage Fluctuations and Flicker in Low-Voltage Supply Systems Rated Current ≤16AEN 61000-3-3:2013

Limits and Methods of Measurement of Radio Disturbance Characteristics of ITE: Radiated, Class B Limits; Conducted, Class BEN 55022:2012

EN 55103-2:2009 Electromagnetic Compatibility – Product Family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control Apparatus for

Professional Use, Part 2: Immunity

Electrostatic Discharge Immunity (Environment E2-Criteria B, 4k V Contact, 8k V Air Discharge)EN 61000-4-2:2009 Ed 9

Radiated, Radio-Frequency, Electromagnetic Immunity (Environment E2, Criteria A)EN 61000-4-3:2010 Ed 3.2

Electrical Fast Transient/Burst Immunity (Criteria B)EN 61000-4-4:2012 Ed 12

Surge Immunity (Criteria B)EN 61000-4-5:2014

Immunity to Conducted Disturbances Induced by Radio-Frequency Fields (Criteria A)EN 61000-4-6:2009

Voltage Dips, Short Interruptions and Voltage VariationEN 61000-4-11:2004

Safety Standard:

Safety Requirements - Audio Video and Similar Electronic Apparatus IEC 60065: 2002 +A12:2011, IEC 60065:2001 Ed 7 +A1:2010

Safety Requirements - Audio, Video, and Similar Electronic Apparatus CAN/CSA 60065-03 incl. A1

Safety Requirements - Audio, Video, and Similar Electronic ApparatusUL Std No. 60065-2007

I certify that the product identiﬁed above conforms to the requirements of the EMC Council Directive 89/336/EEC as amended by 92/31/EEC,
