PYNG-HUB
Crestron Pyng® Control Hub
crestron.com | 800.237.2041
>Communicates with the Crestron Pyng® App via an
internet connection
>Interfaces with wireless and wired lighting controls,
motorized shades, thermostats, security systems,
door locks, occupancy sensors, daylight sensors,
AV, and other equipment [2]
>Built-in infiNET EX® wireless network gateway [1,3]
>Cresnet® master port for wired devices [1]
>High-Speed LAN port for Ethernet devices and
internet connection
>Optional COM port expander adds an RS-232
interface for third-party devices [2]
>Stores system configuration settings onboard
>Cloud backup for reliability and serviceability
>Memory card slot for event logging (Micro SD card not included)
>Crestron “IFE” Integrator Friendly Enclosure
>Surface or DIN rail mountable using bracket provided
>Available rack mount and pole mount options
[2]
>PoE, Cresnet, or line powered
>External 100-240 VAC universal power pack included
The Crestron Pyng® Control Hub ( ) communicates with the PYNG-HUB
Crestron Pyng App ( ) via an internet connection to enable CRESTRON-PYNG
control and monitoring of AV, lights, shades, thermostats, security systems,
door locks, occupancy sensors, daylight sensors, and other equipment. It
also enables control of the equipment using Crestron
® touch screens
and keypads.
Built-in infiNET EX®, Cresnet®, and Ethernet provide both wireless and
wired connectivity to support a wide range of Crestron devices.
[1] A variety
of third-party devices and services can also connect to the control hub
via Ethernet and the Internet, or via RS-232 using the optional COM Port
Expander (PYNG-CONNECT-COM [2]).
System setup and configuration is accomplished by a Crestron authorized
installer using the Crestron Pyng App. Configuration settings are stored
onboard the control hub and backed up in the cloud to ensure reliable
operation and easy serviceability. Simplified internet access is enabled
using the .myCrestron Dynamic DNS Service
SPECIFICATIONS
Wired Communications
Ethernet: 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery,
full/half duplex, industry-standard TCP/IP stack, UDP/IP, CIP, DHCP,
IEEE 802.3at Type 1 compliant
Cresnet: Cresnet master mode [1]
Wireless Communications [1]
RF Transceiver: infiNET EX 2-way RF, 2.4 GHz ISM Channels 11-26 (2400
to 2483.5 MHz), default channel 15; IEEE 802.15.4 compliant
Range: 50 ft (15 m) to nearest mesh network device(s), subject to site-
specific conditions and individual device capabilities, range between floors
or ceilings is limited to one level
[3]
Note: Do not rackmount or stack multiple units when using wireless. Use
care when positioning the device to avoid interference from nearby RF
devices, obstructions, and metal surfaces.
Connectors
MEMORY: (1) Micro SD memory card slot;
Accepts one Micro SD card for storage of log files
COMPUTER: (1) USB Type Micro-B connector, female;
Service port for factory use only
NET: (1) 4-pin 3.5 mm detachable terminal block;
Cresnet master port [1];
Outputs power to Cresnet devices if the included power pack is connected
to the 24 VDC power input jack;
Alternately functions as a Cresnet power input to power the unit from a
Cresnet power supply [2];
See “Power” section below for additional specifications
G: (1) 4-40 screw;
Chassis ground lug
24 VDC 0.75A: (1) 2.1 x 5.5 mm DC power connector;
24 Volt DC power input (power pack included);
Passes through to the NET port to power Cresnet devices;
See “Power” section below for additional specifications
LAN PoE: (1) 8-pin RJ45 connector, female;
10Base-T/100Base-TX Ethernet port;
PoE PD port
PYNG-HUB Crestron Pyng
®
Control Hub
crestron.com | 800.237.2041
Controls & Indicators
PWR: (1) Green LED, indicates operating power is supplied via PoE, a
power pack, or Cresnet
NET: (1) Amber LED, indicates communication with Cresnet devices
PAIR: (1) Red LED, indicates when pairing with an infiNET EX
wireless device
HW-R: (1) Pushbutton, initiates hardware reset
SW-R: (1) Pushbutton, initiates software reset
LAN PoE (rear): (1) Green and (1) amber LEDs, green indicates Ethernet
link status, amber indicates Ethernet activity
Power
Power Source Options: PoE, power pack, or Cresnet; safe to connect PoE
simultaneously with either Cresnet or power pack
Power over Ethernet: IEEE 802.3at Type 1 (802.3af compatible) Class 0
(12.95 W) PoE Powered Device
Power Pack (included):
Input: 0.4 Amps maximum @ 100-240 Volts AC, 50/60 Hz;
Output: 0.75 Amps @ 24 Volts DC;
Model: PW-2407WU
Cresnet Power Usage: 4 Watts (0.17 Amp @ 24 Volts DC) when powered
by a Cresnet power supply [2]
Available Cresnet Power: 14 Watts (0.6 Amp @ 24 Volts DC) when
powered by the included power pack
Power Consumption: 4 Watts (not including any connected
Cresnet devices)
Environmental
Temperature: 41° to 113° F (5° to 45° C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 14 BTU/hr
Construction
Enclosure: IFE small form factor, white and blue plastic
Mounting: Freestanding, stackable, surface mount, or 35 mm DIN EN
60715 rail mount; occupies 8 DIN module spaces (144 mm); surface/DIN
rail mounting bracket included, optional rack mount and pole mount kits
sold separately
Dimensions
Height: 1.35 in (35 mm); 1.77 in (45 mm) with bracket
Width: 5.04 in (129 mm); 5.36 in (137 mm) with bracket
Depth: 5.04 (129 mm)
Weight
9.9 oz (281 g);
11.3 oz (321 g) with bracket
Compliance
UL Listed for US and Canada, CE, IC, FCC Part 15 Class B digital device
MODELS & ACCESSORIES`
Available Models
PYNG-HUB: Crestron Pyng® Control Hub
Included Accessories
PW-2407WU: 24 Volt DC Power Pack
Available Accessories
CRESTRON-PYNG: Crestron Pyng® App
PYNG-CONNECT-COM: COM Port Expander for PYNG-HUB
RMK-IFE-1U: IFE Rack Mount Kit
PLMK-IFE-101: IFE Pole Mount Kit
PWE-4803RU: PoE Injector
CEN-SW-POE-5: 5-Port PoE Switch
CEN-SWPOE-16: 16-Port Managed PoE Switch
MYCRESTRON-DDNS: myCrestron Dynamic DNS Service for
Crestron Systems
Rear View
PYNG-HUB Crestron Pyng
®
Control Hub
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
©2017 Crestron Electronics, Inc.
Specifications subject to change without notice. Revised 08/21/17
Notes:
1. The Cresnet port and infiNET EX transceiver are strictly for use with specific Crestron
devices that work with Crestron Pyng. For a list of compatible devices, please visit:
http://www.crestron.com/products/line/crestron-pyng-home-automation-ipad-app.
2. Item(s) sold separately.
3. The total range of an infiNET EX wireless network is dependent on the placement and
capabilities of each network device. A mesh network topology is employed so every “EX”
device on the network acts as a routing node or “expander,” which relays the signals it receives
on to other EX devices within range. This effectively extends the total range of the network and
provides multiple redundant signal paths for extra reliability. A maximum of six “hops” across
routing nodes is allowed, although a maximum of three is recommended. Please note that
battery-powered infiNET EX devices only operate as leaf nodes and do not provide expander
functionality. Up to 100 infiNET EX devices are permitted, although best practices suggest
a limit of 50. Up to three external gateways ( sold separately) may be added CEN-GWEXER
to support additional devices (RF conditions allowing). Refer to the “Installation and Setup of
Crestron RF Products, Best Practices” guide (Doc # 6689) for additional guidelines.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: .patents.crestron.com
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron Logo, Cresnet, Crestron Pyng, and infiNET EX are either trademarks or
registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries.
Other trademarks, registered trademarks, and trade names may be used in this document to refer
to either the entities claiming the marks and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others. Crestron is not responsible for errors in
typography or photography. Specifications are subject to change without notice.
©2017 Crestron Electronics, Inc.
