Crestron CNXRY-8
CNX Relay Output Expansion Card
Operations Guide
Crestron CNXRY-8 CNX Relay Output Expansion Card
Contents
CNX Relay Output Expansion Card: CNXRY-8 1
Description................................................................................................................................. 1
Functional Description ................................................................................................1
Physical Description....................................................................................................1
Leading Specifications............................................................................................................... 2
Setup..........................................................................................................................................2
Installation................................................................................................................... 2
Preparation for Use...................................................................................................... 3
Programming with SIMPL Windows ........................................................................................3
How the Program Works............................................................................................. 3
How to Create the Program......................................................................................... 4
Problem Solving ........................................................................................................................7
Troubleshooting .......................................................................................................... 7
Further Inquiries ..........................................................................................................7
Future Updates ............................................................................................................7
Return and Warranty Policies....................................................................................................8
Merchandise Returns / Repair Service ........................................................................ 8
CRESTRON Limited Warranty .................................................................................. 8
Operations Guide - DOC. 8121 Contents •
•
•
•• i
Crestron CNXRY-8 CNX Relay Output Expansion Card
CNX Relay Output Expansion
Card: CNXRY-8
Description
Functional Description
The CNXRY-8 Relay Output Expansion Card provides 8 isolated, normally open
relay closures. The maximum rating per contact measures 1A, 30 VAC/VDC. There
are MOV (metal oxide varistor) arc supression devices across the contacts for use
with “real world” loads. Refer to the schematic below.
CNXRY-8 Schematic
54321 876
Physical Description
The CNXRY-8, shown below, is a circuit board fastened to an aluminum faceplate.
The card is manufactured to easily fit into an unoccupied slot in a Crestron
 CNX
Generation Control System.
CNXRY-8 Faceplate
The faceplate contains one male, 16-pin connector. Each relay is isolated from the
others. Silk screening is applied to the faceplate; relay pin pairs are labeled 1 through
8. A supplied 16-position connector can be wired and attached to the card.
Operations Guide - DOC. 8121 CNX Relay Output Expansion Card: CNXRY-8 •
•
•
•• 1
