Seite 1/16
Crestron CAGE3
Control Card Expansion Cage for AV3
Installation Guide
Control Card Expansion Cage for AV3 Crestron CAGE3
Contents Installation Guide – A DOC. 7331
This document was prepared and written by the Technical Documentation department at:
Contents
Control Card Expansion Cage for AV3: CAGE3 1
Introduction 1...............................................................................................................................
Specifications .............................................................................................................. 1
Physical Description .................................................................................................... 1
I nstallation ................................................................................................................................. 4
Problem Solving ...................................................................................................................... 11
Troubleshooting ......................................................................................................... 11
Further Inquiries ........................................................................................................ 11
Future Updates ..........................................................................................................11
Return and Warranty Policies .................................................................................................. 12
Merchandise Returns / Repair Service ......................................................................12
Crestron Limited Warranty ........................................................................................ 12
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, 3- -Series, and 3 Series Control System are either trademarks or registered trademarks of Crestron
Electronics, Inc. in the United State and/or other countries. Other trademarks, registered trademarks and trade names may be
used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others.
©2012 Crestron Electronics, Inc.
Crestron CAGE3 Control Card Expansion Cage for AV3
Installation Guide – DOC. 7331A Control Card Expansion Cage for AV3: CAGE3 •
•
•
•• 1
Control Card Expansion Cage for
AV3: CAGE3
Introduction
The CAGE3 is a field installable accessory that adds three control card expansion
slots to the AV3 3-Series Control System
®. The CAGE3 enables installation of up to
three 3-Seriesâ„¢ control cards to expand the number and types of control ports in the
AV3 chassis.
Specifications
Specifications for the are listed in the follCAGE3 owing table.
CAGE3 Specifications
SPECIFICATION DETAILS
Dimensions
Height 3.18 in (81 mm)
Width 9.00 in (229 mm)
Depth 7.22 in (184 mm)
Weight (0 8 oz .23 kg)
Physical Description
The CAGE3, shown on the following page, contains three 98-pin connectors that
accept the plug-in expansion cards and card guides to support each side of the
individual cards. A single 98-pin connector provides signal interconnect between the
CAGE3 and the AV3 processor board. Two blank faceplates are attached to the
CAGE3 -when shipped. If more than one plug in expansion card is to be utilized in
the AV3, additional faceplate(s) must be removed. The expansion cards contain two
thumbscrews that secure the card faceplate faceplate through the CAGE3 mounting
brackets.
