Crestron AirBoard™ – Whiteboard Capture System
crestron.com | 800.237.2041
>Turns your dry-erase board into an electronic whiteboard
>View whiteboard content on any video display in real time
>View remotely in a web browser [1]
>Open-platform compatible with any UC or VTC solution
>More intuitive to use and cost-effective compared to an
interactive display or document camera solution
>Ideal for enterprise, education, and conference
center applications
>Produces a high-contrast, full-color video image of
the whiteboard
>Eliminates distortions, shadows, reflections, backgrounds,
and body parts from the video image
>Works with any white or coated glass dry-erase board up
to 6 x 4 ft (1.8 x 1.2 m) [2]
>No special markers required
>Automatically saves a snapshot of each change as you draw
>Produces a complete slide deck of session content
[1]
>HDMI® output via a DGE-100 Digital Graphics Engine
(sold separately)
>Touch screen controllable via a Crestron® control system [3]
>Secure, encrypted network communications
>PoE or 100-240V AC line powered
The Crestron AirBoard™ whiteboard capture system ( ) turns any CCS-WB-1
dry-erase board into an electronic whiteboard. Crestron AirBoard lets you
use your whiteboard like normal, and share it in real time on video displays
and web browsers. As you draw on the board, each change you make is
captured and saved as a snapshot. A complete slide deck of snapshots
can be downloaded or emailed at the end of the session. Crestron AirBoard
perfectly preserves the intuitive whiteboard experience while extending its
capabilities to accommodate large audiences and remote viewers.
[1]
Advanced optics and image processing
Crestron AirBoard technology employs advanced optics and image
processing to produce a crisp and colorful digital whiteboard image.
A compact camera mounted above the whiteboard captures each stroke
you make, while enhancing the ink colors and contrast for a clean, vibrant
image. No special markers are required. Shadows, reflections, backgrounds,
and body parts are automatically removed, so the onscreen video image
looks just like you’re standing square in front of the whiteboard.
Powerful and practical presentation
Crestron AirBoard doesn’t rely on expensive large-screen touch displays,
and won’t lock you into a single-manufacturer collaboration platform. It
simply works with any dry-erase board (white or coated glass
[2]) up to 6 ft
wide x 4 ft high (1.8 m wide x 1.2 m high). This affords a writing surface
equivalent to an 86.5 inch (220 cm) diagonal electronic whiteboard. The
great thing is, since the whiteboard image is flawlessly reproduced on any
video screen, there’s no need for the physical whiteboard to be positioned
where it can be seen by the whole audience. Just put it wherever it’s
practical to use and present from, and let the audience view the whole
thing on the big screen.
Video presentation and conferencing system integration
Crestron AirBoard can function alone or as part of any AV presentation
system, collaboration system, or videoconferencing system. Composed of a
sleek, unimposing camera unit and separate control pad, Crestron AirBoard
is easy to install. The camera mounts to the wall above the whiteboard, the
control pad mounts to the wall at either side of the whiteboard, and a 6 ft
(1.8 m) cable connects them together. The control pad connects to the LAN
via Ethernet, and the complete system can be powered using PoE or the
included 100-240V power pack.
Connection to the room display, AV system, or conferencing codec is
handled by a Crestron® Digital Graphics Engine (sold separately). DGE-100
The captured presentation is streamed to the DGE-100 over the network
and fed to the room system via the DGE-100’s HDMI® output.
Basic operation is provided via the control pad or a web browser. Enhanced
touch screen operation is enabled through integration with a Crestron
control system. From the (sold separately), anyone can easily touch screen
start a session, route the signal to the room display(s), and distribute
summary content to email recipients when the session has ended.
[1,3]
Remote viewing and content distribution
Remote participants can view a whiteboard session from any location
using just the web browser on their computer or mobile device. No extra
downloads, apps, or plugins are required. At the end of the session, the
remote viewers can download the session content as a multi-page PDF
timeline, or as individual PNG snapshots. Content may also be sent out to
any email recipient using a touch screen or computer within the room.
[1]
CCS-WB-1 Crestron AirBoard
™
– Whiteboard Capture System
crestron.com | 800.237.2041
Safe, secure, and private
Whatever you write or draw on your whiteboard, you decide who to share
it with. To keep your content private, all network communications are
encrypted. A capture session can only be initiated from within the room
(unless otherwise programmed via a control system). The secure cloud
service ensures only authorized viewers can access the live stream or
download the session content. No one outside the session can access your
session content without an invitation or approval. Content is stored locally
on the Crestron AirBoard device, not in the cloud, and is available for a
maximum of 30 minutes (or less if desired) after the session ends.
SPECIFICATIONS
Whiteboard Support
Type: White or coated glass dry-erase board [2]
Size: Up to 6 ft wide x 4 ft high (1.8 m wide x 1.2 m high)
Communications
Ethernet: 100 Mbps, auto-switching, auto-negotiating, auto-discovery,
full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, IPv4, TLS, HTTPS, HTTPS web
browser setup, IEEE 802.3at & 802.3af compliant
Hardware Device Options: Compatible with Crestron DGE-100 [3]
Web Client Options: Web browser-based application, no downloads or
plugins required, use any computer or mobile device, supports up to 15
users (inclusive of all web browsers and DGE-100 devices) [1]
Controls & Indicators
Control Pad Display: (1) Backlit text, directs presenter to the online
session portal
Control Pad Button: (1) Pushbutton, blue LED backlit; flashing blue
indicates a request to start a capture session via the online session portal,
press to enable capture and sharing (or wait 30 seconds for request to
time out), solid blue indicates session in progress, press to end session;
press and hold to enter setup mode
Control Pad Indicator: (1) Bi-color red/green LED, alternating red/green
indicated system is ready to be set up via a web browser, solid green
indicates system is ready for use, solid red indicates no
network connection
Camera Indicator: (1) Blue LED, flashing blue indicates a request to start
a capture session, solid blue indicates session in progress
Reset: (1) Recessed pushbutton behind pinhole on bottom of control pad
for factory reset
Connectors (On Control Pad)
LAN PoE: (1) 8-pin RJ45 connector, female;
100Base-TX Ethernet and PoE PD port;
6 ft (1.8 m) LAN cable included
DC Power: (1) 2.5 mm DC power connector;
5 Volt DC power input;
Power pack included;
Connect only if PoE is not used
Camera: (1) 6 ft (1.8 m) proprietary USB wired connection from camera;
Note: This cable cannot be extended.
Power
Power Pack (included): Input: 100-240 Volts AC, 50/60 Hz;
Output: 1 Amp @ 5 Volts DC
Power over Ethernet: IEEE 802.3at compliant (802.3af compatible) PoE
PD (Powered Device);
• Requests 7 Watts (PoE Class 2) from an 802.3af or 802.3at Type 1
PoE PSE;
• Requests 7 Watts from an 802.3at Type 2 PoE+ PSE with LLDP
power management;
• Requests 30 Watts from an 802.3at Type 2 PoE+ PSE without LLDP
Environmental
Temperature: 32° to 104° F (0° to 40° C)
Humidity: 5% to 95% RH (non-condensing)
Construction
Camera Housing: Plastic, black and white finishes, includes mounting
plate and screws
Control Pad: Plastic, black and white finishes, includes mounting plate
and screws
Dimensions
Camera: Height: 8.92 in (227 mm)
Width: 2.44 in (62 mm)
Depth: 19.83 in (504 mm)
Control Pad: Height: 4.02 in (102 mm)
Width: 4.02 in (102 mm)
Depth: 1.07 in (27 mm)
Weight
Camera: 13.1 oz (370 g)
Control Pad: 5.6 oz (157 g)
Compliance
CE, IC, FCC Part 15 Class B digital device
MODELS & ACCESSORIES
Available Models
CCS-WB-1: Crestron AirBoard™ – Whiteboard Capture System
Available Accessories
DGE-100: Digital Graphics Engine 100
PWE-4803RU: PoE Injector
CEN-SW-POE-5: 5-Port PoE Switch
CEN-SWPOE-16: 16-Port Managed PoE Switch
CCS-WB-1 Crestron AirBoard
™
– Whiteboard Capture System
Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647
Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903
www.crestron.com
All brand names, product names and trademarks are the property of their respective owners.
©2019 Crestron Electronics, Inc.
Specications subject to change without notice. Revised 03/11/19
Notes:
1. Internet access and a subscription to the Crestron AirBoard cloud service are required to
enable remote viewing via a web browser, downloading session content via a web browser,
and distribution of session content via email. The CCS-WB-1 includes a free license for
subscription to the cloud service.
2. If using a glass-surface board, the back of the glass should be coated to prevent “echoes” in
the captured image. Clarus brand glassboards are recommended.
3. AV and control system integration requires additional equipment and services provided by a
Crestron authorized systems integrator.
This product may be purchased from an authorized Crestron dealer. To find a dealer, please contact
the Crestron sales representative for your area. A list of sales representatives is available online at
https://www.crestron.com/How-To-Buy/Find-a-Representative or by calling 855-263-8754.
The specific patents that cover this and other Crestron products are listed online at
https://www.crestron.com/legal/patents.
Certain Crestron products contain open source software. For specific information, please visit
https://www.crestron.com/opensource.
Crestron, the Crestron logo, and Crestron AirBoard are either trademarks or registered trademarks
of Crestron Electronics, Inc. in the United States and/or other countries. HDMI is either a trademark
or registered trademark of HDMI Licensing LLC in the United States and/or other countries. Other
trademarks, registered trademarks, and trade names may be used in this document
to refer to either the entities claiming the marks and names or their products. Crestron disclaims
any proprietary interest in the marks and names of others. Crestron is not responsible for errors in
typography or photography. Specifications are subject to change without notice.
©2019 Crestron Electronics, Inc.
19.83 in
504 mm
1.07 in
27 mm
4.02 in
102 mm
4.02 in
102 mm
2.44 in
62 mm
8.92 in
227 mm
Produktspezifikationen
| Marke: | Crestron |
| Kategorie: | Whiteboard |
| Modell: | AirBoard CCS-WB-1 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Crestron AirBoard CCS-WB-1 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Whiteboard Crestron
20 August 2024
Bedienungsanleitung Whiteboard
- Whiteboard Samsung
- Whiteboard BenQ
- Whiteboard Sharp
- Whiteboard Hitachi
- Whiteboard United Office
- Whiteboard ViewSonic
- Whiteboard Maul
- Whiteboard ELO
- Whiteboard Iiyama
- Whiteboard IPEVO
- Whiteboard Promethean
- Whiteboard Legamaster
- Whiteboard Nobo
- Whiteboard Chief
- Whiteboard Dahua Technology
- Whiteboard I3-Technologies
- Whiteboard Conen Mounts
- Whiteboard V7
- Whiteboard Franken
- Whiteboard EInstruction
- Whiteboard MooreCo
- Whiteboard Starboard
Neueste Bedienungsanleitung für -Kategorien-
20 September 2024
9 September 2024
4 September 2024
3 September 2024
3 September 2024
2 September 2024
2 September 2024
1 September 2024
1 September 2024
1 September 2024
