• Ultra-compact passive two-way loudspeaker
• Premium 6.5” woofer, 1.2“ voice coil
• 1” Compression driver, 1“ voice coil
• Continuous power handling: 75 Watts
• Nominal impedance: 16 Ohms
• Coverage pattern (HxV): 90° x 60°
• Connectors: 2 x 4-pin twist-lock & 4-pin Euroblock
• 2+/2- Loop Through
• Advanced crossover network
• Tweeter protection
• 12 mm Plywood construction
• Textured polyurea paint
• 9 x M8 suspension points (2 top, 2 bottom, 2 each side, 1 rear)
• 4 x M6 suspension points for Peavey® Versamount™ 35
• Available in Black and White
Features
The Crest Audio® CPL™ 6+ is an ultra-compact passive
two-way loudspeaker designed for music playback,
public address and live performance reinforcement
applications where space is at a premium.
The CPL 6+ can be utilized for both permanent
installations and portable live sound applications.
Perfect for public address, monitoring and background
audio reinforcement purposes typically required in
houses of worship, clubs, bars/restaurants, retail outlets
plus education and corporate meeting facilities or
anywhere high quality discrete audio distribution is
required.
The CPL 6+ is equipped with a premium 6.5 inch woofer
having a 1.2 inch voice coil together with a 1 inch exit
compression driver known for its smooth frequency
response and non-fatiguing mid range. Directivity
pattern of the loudspeaker is measured at 90° horizontal
and 60° vertical providing a wide yet well controlled
audio coverage. An internal advanced crossover
network maintains EQ and driver protection. Impedance
of the loudspeaker is 16 Ohms allowing for easy daisy
chaining. Connectivity is made via either looping 4-pin
twist-lock or 4-pin Euroblock connectors.
The CPL 6+ enclosure is built from prime-grade 12 mm
plywood that offers sturdy mechanical and low resonant
electro-acoustic characteristics together with a heavy-
duty steel grille backed with acoustic foam to ensure
maximum protection of the internal components. The
loudspeaker is equipped with a total of 13 threaded
suspension points offering multiple mounting options for
various applications. Available in durable black and
white finish.
Description
CPL™ 6+ - 2-way Passive Speaker
CPL™+ Series
Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian, MS 39305
Phone: (601) 483-5365 • Fax: (601) 486-1278 • www.peaveycommercialaudio.com
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/de/crest-audio/cpl-6-plus/html/bg2.png)
Features and specifications subject to change without notice.
Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian, MS 39305
Phone: (601) 483-5365 • Fax: (601) 486-1278 • www.peaveycommercialaudio.com
© 2023 - Rev P3-2023-01-23
The ultra-compact loudspeaker shall consist of a 6.5 inch (165 mm) low frequency transducer with 1.2 inch (30 mm) voice
coil and a 1 inch (25.4 mm) exit compression driver with a 1 inch (25.4 mm) voice coil and a frequency dividing network
installed within the enclosure.
Performance specifications of a typical production unit shall be: Measured sensitivity SPL at 1 m (3.3ft) with 4.0V input,
shall be 92 dB-SPL. Usable frequency response shall extend from 73 Hz to 19 kHz (10 dB below rated sensitivity, in full
space, with no external equalization). Nominal impedance shall be 16 Ohms. Rated power capacity shall be at least 75
Watts continuous power and 300 Watts peak power, defined as 6 dB above a test signal of filtered random noise.
The system shall be protected against damage from occasional over-powering limiting the power to the network and
transducers. The compression driver shall be capable of even coverage at a nominal 90° horizontal through 60° vertical
distributed pattern.
The enclosure shall be constructed from prime-grade 12 mm plywood. The loudspeaker shall be equipped with a total of
thirteen (13) suspension points. The grille shall be of heavy-duty steel backed with acoustically transparent foam. The
external wiring shall be via either two 4-pin twist-lock or one 4-pin Euroblock connectors. The loudspeaker shall be 12.52
inches (318 mm) high by 8.78 inches (223 mm) wide by 8.98 inches (228 mm) deep weighing 14.3 pounds (6.5 kg). The
finish shall be a paintable lightly textured black or white.
The ultra-compact loudspeaker shall be the Crest Audio CPL 6+.
Architect’s & Engineer’s Specifications
Dimensions Accessories
Specifications
CPL™ 6+
223
318
318
237.5
228
223
50.8
28
108
146.5 139 18
100
45 Optional Versamount 35
Ceiling & Wall-mount Bracket
Available in Black & White
Optional
U-Bracket
Optional
Pole Mount Adapter
Con gura on: 2-way Passive Speaker Pole Mount: Op onal with special adapter
Power Con nuous (Wa s): 75 U-Bracket: Op onal
Power Peak (Wa s): 300 Enclosure Design: Trapezoidal
Sensi vity (1W/1m): 92 dB Enclosure Material: 0.47" (12 mm) Plywood
Max SPL Peak: 117 dB Black Finish: Textured Polyurea Paint
LF Driver: 1 x 6.5" (165 mm) - Crest Audio GYKW-0630A-1 RAL #: 9004 Signal Black (Pantone: Black 6)
Woofer Voice Coil: 1.2" (30 mm) White Finish: Textured Polyurea Paint
HF Driver: 1 x 1" (25.4 mm) - Crest Audio CPL69081 RAL #: 9003 Signal White (Pantone: 705)
HF Driver Voice Coil: 1" (25.4 mm) Tweeter Protec on: Yes
Nominal Coverage (HxV): 90° x 60° Rubber Feet: Yes (not mounted)
Frequency Range (-10 dB): 73 Hz - 19 kHz Handles: No
Frequency Response (±3 dB): 130 Hz - 17 kHz Loop Thru (2+/2-): Yes
Nominal Impedance: 16 Ohms Logo Posi on on Grille: Bo om Center
Input Connectors 1: 2 x 4-pin twist-lock (NL-4 style) Logo Size: 25 x 25 mm
Input Connectors 2: 1 x 4-pin Euroblock Grille Foam Backing: Yes (acous cally transparent)
Suspension Points: 9 x M8 Grille Mesh Size (mm): 3 x 12
Suspension Points Locaon: 2 x Top, 2 x Bo om, 2 x Le , 2 x Right, 1 x Rear Monitor Tilt Angle: No
Suspension Points Rear: 4 x M6 (for op onal Versamount 35) Net Weight: 14.3 lbs (6.5 kg)
Moun ng Points for U-Bracket: Yes (2 x M8 - Top & Bo om) Dimensions (HWD): 12.52" x 8.78" x 8.98" (318 x 223 x 228 mm)
