Seite 1/24
Operator Manual
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: 502.425.4776 Toll Free: 800.695.4500
Fax: 502.425.4664
Web: gmcw.com Email: info@gmcw.com
Safety Information........................2
Specifications.................................3
Installation and Set-Up.................4
Product Preparation & Use...........7
Daily Cleaning ...............................8
Troubleshooting..........................11
Basic Machine Parts ....................14
Thank you for purchasing this quality cold beverage dispenser. For your safety and the safety of
others, read all warnings and the operator’s manual before installing or using the product. Properly
instruct all operators. Keep training records. For future reference, record serial number here:
Table of Contents
Simplicity™Bubbler
Crathco®Cold Beverage Dispensers
Grindmaster-Cecilware provides the industry’s
BEST warranty. Visit gmcw.com for warranty
terms and conditions.
Model CS-2D-16
Model CS-2E-16
©2017 Grindmaster-Cecilware
Printed in Thailand
0617 Form # CC-330-04
Part # 390-00003
(cULus certification applies only to
United States and Canada models.)
Model CS-3L-16
Activate your warranty now at
http://gmcw.com/warranty-registration
2 Crathco®Simplicity Bubbler
Lifting hazard. Single person lift could cause injury. Use assistance when moving or lifting.
Sharp edges can cause personal injury. Handle with care.
The appliance is not to be used by persons (including children 8 years and above) with reduced physical, sen-
sory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction. Be sure to provide supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children must be supervised to ensure they do not play with the appliance.
For safe and proper operation the appliance has to be placed in a stable horizontal position.
The appliance is only to be installed in locations where it can be overseen by trained personnel.
Safety Information
Observe machine voltage configuration. Do not apply improper voltage to machine or damage to machine will
occur.
Do not use extension cord.
Do not operate the appliance below 1.7°C (35°F) or above 40°C (104°F).
Clean and sanitize unit before first use.
NOTICE/ AVIS/ AVISO
The appliance is not intended for outdoor use.
Do not clean with a water jet or use in an area where a water jet may be used.
Cleaning and maintenance shall be made only by properly trained persons with supervision.
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator manual before installing or using
the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death.
WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death.
CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury.
NOTICE: This term refers to information that needs special attention or must be fully understood.
CAUTION/ ATTENTION/
ATENCIÓN
WARNING/ AVERTISSEMENT/ ADVERTENCIA
Simplicity Bubbler Crathco®3
Specifications
Northern America
Export
Model Description Electrical Certifications/Dimensions (H x W x D)
Declarations
CS-2E-10 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 100V / 50/60 HZ / 3.6A NSF
agitator model. 70 cm x 27 cm x 45 cm
CS-2E-10-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 100V / 50/60 HZ / 3.6A NSF
spray model. 70 cm x 27 cm x 45 cm
CS-2E-22 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 70 cm x 27 cm x 45 cm
CS-2E-22-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 70 cm x 27 cm x 45 cm
CS-4E-22 (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 65 cm x 52 cm x 45 cm
CS-4E-22-S (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 70 cm x 52 cm x 45 cm
CS-1D-22 (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 70 cm x 27 cm x 45 cm
CS-1D-22-S (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 70 cm x 27 cm x 45 cm
CS-2D-22 (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 70 cm x 52 cm x 45 cm
CS-2D-22-S (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 65 cm x 52 cm x 45 cm
CS-3D-22 (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 70 cm x 52 cm x 45 cm
agitator model.
CS-3D-22-S (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 70 cm x 52 cm x 45 cm
spray model.
CS-3L-22 (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 80 cm x 52 cm x 45 cm
CS-3L-22-S (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 80 cm x 52 cm x 45 cm
Model Description Electrical CertificationsDimensions (H x W x D)
CS-2E-16 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-2E-16-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-4E-16 (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-4E-16-S (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-1D-16 (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-1D-16-S (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-2D-16 (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-2D-16-S (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-3D-16 (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
agitator model.
CS-3D-16-S (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
spray model.
CS-3L-16 (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-3L-16-S (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.
